Log Placement Instructions

Model: AVFL42(N/P)TSC
WARNING: Turn off fireplace and allow to cool complete-
ly before beginning installation.

Kit Contents:

• Two (2) ceramic fiber driftwood logs
• Four (4) log support pin brackets
• Eight (8) #8 bracket mounting screws
NOTE — Do not handle logs with your bare hands. Always
wear gloves to prevent skin irritation from ceramic fibers.
After handling the logs, wash your hands with soap and water
to remove any traces of fibers.
NOTE: Prior to installing the log set, you must first install
the pin brackets on the burner. The air deflection glass and
fireglass should only be installed after the pin brackets are
in place. The air deflection glass should be installed prior to
placing and fireglass on the burner. The logs must then be
placed in the unit after the fireglass and air deflection glass. If
the optional logs are added after the air deflection glass and
fireglass are in use, move the fireglass away from the areas
in Figure 1 and install the support brackets, then arrange
fireglass evenly across burner again.
Figure 2 –

Alternative Log Placement

Pin placement
Log #1 (Rear)
Pin placement
Pin placement
Log #2 (Front)
Log #2 (Front)
Option 1
Figure 1 –
Log Pin Assembly
Option 2
Air Deflection
Glass
20306076 8/21 Rev. A
