Installation instructions
Please read and follow the
your dryer!
Moving your appliance
If the dryer needs to be placed at an angle for moving, only tip towards the right hand side (when viewed from the
front). If the dryer has not been transported as described, leave it standing upright for at least one hour before
turning on.
Accessories
Please check you received the following accessories with your Fisher & Paykel dryer. You will find them inside
the drum:
• 1 x Drying rack
• 1 x Drain hose
• 1 x Installation instructions and user guide
Unpacking
To ensure the best performance from your new dryer please follow the instructions below.
Removing the packaging
1. Remove the outer packaging (including the polystyrene packer and plastic wrapping). All packaging must be
removed prior to use.
2. Tilt the machine backwards and 'walk' it off the base one foot at a time. Not doing so may cause damage to
your floor and dryer.
3. Remove all packaging and accessories from inside the drum and ensure you remove protective covers from
door and console.
https://producthelp.fisherpaykel.com/Manuals/Dryer_Manuals/User_Guides/428104B_Dryer/03_Installation_instructions
'Safety and
warnings' and 'installation instructions' sections carefully before using
Updated: Sun, 09 Apr 2023 02:45:01 GMT
Powered by
1
Advertisement
Table of Contents
Related Manuals for Fisher & Paykel 428104B
Summary of Contents for Fisher & Paykel 428104B
- Page 1 Installation instructions Please read and follow the ‘Safety and warnings’ and ‘installation instructions’ sections carefully before using your dryer! Moving your appliance If the dryer needs to be placed at an angle for moving, only tip towards the right hand side (when viewed from the front).
- Page 2 Ensure packaging materials are kept out of reach of children. • Please help protect the environment and dispose of the packaging from around the • dryer in an environmentally friendly manner. Location • The dryer must be installed in a well-ventilated, dust- free environment.
- Page 3 1. Move the machine into the desired position. Do not lift the dryer by the top panel. 2. Have a minimum clearance on all sides of at least 20 mm. 3. Install the machine on a stable and level floor (if not stacking on top of a front loading washer). •...
- Page 4 Draining The dryer is equipped with a condenser unit which accumulates water during the drying cycle. This water is collected in the removable water tank located at the top left of the dryer. The accumulated water must be emptied after each drying cycle. However you can also set up your dryer to drain automatically using the drain hose provided.
- Page 5 ◦ Check the power cord for damage and make sure it is not squashed or twisted when installing the dryer. ◦ Always remove the power cord from the power socket by the plug, not by the cord. If you are using an extension cord or a portable electrical outlet device (eg multi- socket outlet box), ensure that it is positioned so that it does not come into contact with water or moisture.
- Page 6 4. At the completion of the cycle open the door and check that there is warmth inside the dryer. This indicates the dryer is operating normally. If there are any problems, you must address these before proceeding with normal use. The dryer will automatically turn off at the end of the cycle if there are no problems.
- Page 7 *Capacity refers to the maximum dry weight of items the machine can dry at any one time. Some cycles have a lower maximum capacity (see the ‘Drying cycles’ section). ** The exact height of your dryer is dependent on how far the feet are extended from the base of the machine.
