Control 4 C4-4SF120 Series Installation Manual

Supported Model
C4-4SF120 Fan Speed Controller
Introduction
The Control4® Fan Speed Controller operates independently or as part of a
Control4 home automation system to provide four (4) quiet speeds plus an Off
setting for standard paddle-type ceiling fans. It installs in a standard back box
using typical wiring standards and communicates to the Control4 system using a
wireless connection.
Box Contents
Fan Speed Controller
Wire Nuts
Warranty Card
Specifications and Supported Load Types
The specifications are described below.
Model Number
Power Requirements
Power Consumption
Load Types and Ratings
Supported Load Types
Maximum Load
Operational Temperature
Humidity
Storage
Control Communications
Wallbox Volume
Weight
Shipping Weight
Fan Speed
Controller
Installation Guide
(this document)
C4-4SF120-xx
120VAC +/-10%, 50/60Hz
This device requires a neutral connection. See
the "Sample Wiring Configurations" later in this
guide.
500mW
Single, paddle-type ceiling fan
2A
Environmental
32˚ F - 104˚ F (0˚ C - 40˚ C)
5% to 95% non-condensing
-4˚ F - 158˚ F (-20˚ C - 70˚ C)
Miscellaneous
ZigBee, IEEE 802.15.4, 2.4 GHz, 15-channel
spread spectrum radio
5.75 cubic inches
0.12 lb. (0.05 kg)
0.18 lb. (0.08 kg)
™
Warnings and Considerations
WARNING! Turn OFF electrical power before installing or servicing this
product. Improper use or installation can cause SERIOUS INJURY, DEATH
or LOSS/DAMAGE OF PROPERTY.
ATTENTION! Coupez l'alimentation électrique avant d'installer ou de
réparer ce produit. Une mauvaise installation ou utilisation peut entraîner
des blessures graves, décès ou perte / dommages à la propriété.
WARNING! This device must be protected by a circuit breaker (20A max).
Cet appareil doit être protégé par un disjoncteur (20A max.)
ATTENTION!
WARNING! Ground this device in accordance with the National Electric
Code (NEC) requirements. DO NOT rely solely upon the yoke plate's
contact with a metal back box for adequate grounding. Use the device's
ground wire to make a secure connection to the safety ground of the
electrical system.
ATTENTION! Cet appareil doit être en conformité avec le Code national
de l'électricité (NEC). Ne comptez pas uniquement au contact de la
plaque avant avec un boîtier mural métallique pour la mise à la terre
adéquate. Utilisez cet appareil à la terre de l'appareil pour établir une
connexion sécurisée au système électrique.
This device must be installed by a licensed electrician in
IMPORTANT!
accordance with all national and local electrical codes.
IMPORTANT! If you are unsure about any part of these instructions,
consult a qualified electrician.
IMPORTANT! Use this device only with copper or copper-clad wire. Do
not use aluminum wiring. This product has not been approved for use with
aluminum wiring.
IMPORTANT! Using this product in a manner other than outlined in this
document voids your warranty. Further, Control4 is NOT liable for any
damage incurred with the misuse of this product. See "Troubleshooting."
IMPORTANT! Do NOT use a power screwdriver to install this device. If you
do, you may overtighten the screws and strip them. Also, overtightening
the screws may interfere with proper button operation.
IMPORTANT! This is an electronic device with intricate components.
Handle and install with care!
Installation Instructions
1 Ensure that the location and intended use meet the following criteria:
If the ceiling fan being controlled is a fan/light combination, there must be
separate load wires for the fan and light from the control location. A separate
Control4 dimmer or switch must be used if the light is to be controlled. Do
not use the Fan Speed Controller to control the light.
Do not exceed the load capacity requirements of the Fan Speed Controller.
Refer to the load ratings in the specifications above for details.
Install in accordance with all national and local electrical codes.
The range and performance of the wireless control system is highly
dependent on the following: (1) distance between devices; (2) layout of the
home; (3) walls separating devices; and (4) electrical equipment located near
devices.
2 Turn off the local electrical power by either switching off the circuit breaker or
removing the fuse from the fuse box. To ensure the wires do NOT have power
running to them, use an inductive voltage detector.
NOTE: The back box wiring shown in this document is an example. Your
wire colors and functions may differ. If you are not sure which wires
are the Hot, Neutral, Load, Traveler, and Ground wires, have a trained
electrician perform the installation.
