Note:
-
This product has been designed for use with electric animal fences.
-
Keep these instructions in a handy location.
Using the energizer with internal
batteries
Recommended batteries
Use 4 x D size, 1.5 V, 15 Ah, dry cell, alkaline batteries. The
batteries will last 30-40 days* with the energizer set to 1
(slow), or 20-25 days* when the energizer is set to 2 (fast).
*energizer operating continuously
Notes:
-
Do not mix battery brands, types or ages and always
replace complete set with new batteries, all of the
same brand and type.
-
Nickel Cadmium (NiCd) or Nickel Metal Hydride (NiMH)
rechargeable batteries are not recommended, as the
energizer's pulse speed will be slower and operation
between recharges may be as short as a few days. If
rechargeable batteries are used, then they must be
removed from the energizer before being recharged.
Installing the internal batteries
Warning! Switch off the energizer before installing
batteries.
1 Press the two side catches and pull to remove the
black battery compartment from the outer case.
2 Insert the batteries, making sure that the polarity is
correct (positive to +, negative to -)
3 Refit the battery compartment. The battery
compartment will only fit correctly one way.
Caution!
When inserting the batteries, be careful not to
short-circuit the tab terminals at the bottom end of the
battery compartment.
Using the energizer with an external
battery
Recommended batteries
Any one of the following batteries may be used with the
energizer:
Battery Type
Rechargeable
6 V, 12 Ah,
Wet cell
external
Lead acid
Rechargeable
12 V, 7 Ah,
Wet cell
external
Lead acid
Rechargeable
12 V,
Wet cell
50 Ah,
Lead acid
external
Deep cycle
* with energizer operating continuously.
Connecting the energizer to an external
battery
Warning! Switch off the energizer before connecting a
battery.
Connect the energizer to the external battery using the
battery leads supplied. Connect the red lead to the positive
terminal (+) on the underside of the energizer and clip the
other end to the positive terminal on the battery. Connect
the black lead to the negative terminal (-) on the underside
of the energizer and clip the other end to the negative
terminal on the battery.
Caution!
When connecting the battery, be careful not to
short-circuit the supply terminals.
Warning!
-
Ensure that the battery is disconnected from the
energizer before connecting the battery to any mains-
operated battery charging device. Failure to observe
this precaution could result in damage to the
energizer and possible electrocution.
-
When a polyvinyl chloride (PVC) sheathed cord is used
to connect the energizer to an external battery, the
equipment must be located in a shelter and must not
be handled when the ambient temperature is below
+5 °C.
Battery life
expectancy*
(1) Slow (2) Fast
30-40 days 20-25 days
33-40 days 22-27 days
8-10 5-7
months months
3
