Technical Information
Resistor &
Rectifier
RE1 & R
RE1
&
R
is mounted behind the panel by machined screws
RE1
R
There are two rectifiers at this location, the top one
RE1
is for excitation.
RE1
(Diode Rectifier)
( MQ part# 0601823204 )
prevents voltage spikes or back feed in the circuit.
R
(Resistor)
( MQ part# 0601842463 )
opposes the electrical current by producing a voltage drop
between it's terminals in proportion to the current. (controls the flow of electrical current)
