Technical Information
TB2 and Fuse Box
J & K
U & N
TI_DA7000_Voltage_Diagnostic
TB1
U & N
provides 120V AC to the receptacles
N & V
provides 120V AC to the receptacles
Output Windings
F4 – 5amp
( MQ part# )
0601806642
Inspect fuse with multi-meter, ensure
inside filament is intact.
3
Excitation &
N & V
05/19/2011
