- Page 1 OFFLIP HOT USER INSTRUCTIONS READ CAREFULLY AND KEEP WITH THE CABINET N° DOC.IA0010124 REV. “B” CAUTION Read the instructions before using the machine...
-
Page 2: Safety Advice
OFFLIP HOT Model IARP ASIA CO., LTD. Manufacturer 231 Moo 6, Kao Yai, Cha-Am, Phetchaburi, 76120, Thailand Tel: +66 32 453 220-1 INTRODUCTION The present booklet has been formulated in a simple and rational way, in order for the reader to get deeply acquainted with his showcase. -
Page 3: Putting Into Operation
Disconnection from the supply mains having a contact separation in all poles that provide full disconnection and must be incorporated in the fixed wiring in accordance with the wiring rules FOR OFFLIP HOT 70, 93 and 125 Power input Connection, Cabinet is Appliance with Fix Wiring type. So, it must be connected power in by professionally qualified personnel with wiring type H05VV-F size 4 sq. -
Page 4: General Description
(Inside) Marking of Protective Earthing Terminals Rating plate Power cord Casters (4 pcs.) (Optional) CAUTION! The surface will become hot, temperature above 100°C At maximum adjustment condition fig. 2 Length Offlip Hot : 700 - 937 - 1250 UM000001 IA0010124.B... -
Page 5: Climate Conditions
CABINET HANDLING tab. I Weight incl. Cabinet Weight Packing (Wooden Lifting (kg) Crate Heavy Duty) point OFFLIP 1250 fig. 4 CLIMATE CONDITIONS fig. 5 fig. 6 fig. 7 tab. II Type of room Closed Temperature 25°C Relative humidity < 60% UM000001 Lighting 600 lx... -
Page 6: Technical Features
TECHNICAL FEATURES OFFLIP HOT 700 Rating plate Rating plate fig. 8 tab. III Rated voltage Rated power Rated current Climate class Lamp power Serial number Code Barcode CONTROL fig. 9 fig. 10 UM000001 IA0010124.B... - Page 7 USE OF CABINET fig. 11 fig. 12 fig. 13 Temperature Display Temperature display fig. 14 fig. 16 fig. 13 fig. 15 IA0010124.B...
-
Page 8: Maintainance Cleaning
MAINTAINANCE CLEANING fig. 18 fig. 17 fig. 20 fig. 19 UM000001 IA0010124.B... -
Page 9: Delivery And Storage
1. DESCRIPTION The hot display case is meant for hot food. Its main features and dimensions are clearly illustrated in drawings 1, 2 on page 4. As for its weights, crating included and excluded, see table I on page 5. A wide variety of optional accessories enabling enhanced functions is also available. -
Page 10: Technical Specifications
of the equipment. Consider also that the maximum allowable power voltage variation is +/-6%. IMPORTANT: THE EQUIPMENT MUST BE PROPERLY EARTHED. The manufacturer assumes no responsibility for any damage resulting from non-observance of this safety principle. If the cabinet must be installed far from electric power source, make certain that the connection complies with the standards in force. -
Page 11: Ordinary Maintenance
KNOB AND SWITCH INSTRUCTIONS: Temperature Controller top shelf: Turn the knob to adjust the heat for the top shelf in this row. The maximum adjustment is limited to “max”. Temperature Controller second shelf: Turn the knob to adjust the heat for the second shelf in this row. -
Page 12: Emergency Situations
IN CASE OF DAMAGE: keep the unit away from flames or ignition sources. Ventilate the premises well for a few minutes. Switch the unit off, pull out the power plug. Inform an Authorized Service Centre. Repairs are carried out only by persons trained or recommended by the manufacturer CAUTION: maintenance should be carried out only by qualified personnel. -
Page 13: After Sales Service
• The wall main switch may be off. If power failure is not due to any of the above causes, call the nearest after-sales service immediately, empty the display case and store the foods in surfaces that may ensure preservation temperature.
