Printed Matter No. 9839 1800 01
Publication Date 2019-11-07
Valid from Serial No. A1690001
W2610 (4- 40 Nm)
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
8431035010
WARNING
W2610
Ratchet wrench
Product Instructions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Atlas Copco W2610
Summary of Contents for Atlas Copco W2610
- Page 1 Printed Matter No. 9839 1800 01 Ratchet wrench Publication Date 2019-11-07 Valid from Serial No. A1690001 Product Instructions W2610 (4- 40 Nm) 8431035010 WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
Air Quality .................... 6 Air Lubrication Guide ................ 6 Compressed Air Connection.............. 6 Operation ......................... 7 Ergonomic guidelines .................. 7 Service ........................ 8 Maintenance Instructions.................. 8 Service recommendations .............. 8 Lubrication Instructions.................. 8 Lubrication guide ................... 8 Recycling ......................... 9 Environmental Regulations................ 9 © Atlas Copco Industrial Technique AB - 9839 1800 01... -
Page 3: Product Information
■ Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the warranty. ■ To avoid damage or destruction of tool parts, service the tool according to the recommended mainte- nance schedules and follow the correct instructions. -
Page 4: Website
Dimensions Drawings can be found either in the Dimensional Drawings Archive, or on ServAid. Please visit: http://webbox.atlascopco.com/webbox/dimdrw or https://servaid.atlascopco.com. Overview Technical Product Data Technical Product Data can be found on either ServAid, or the Atlas Copco website. Please visit: https://servaid.atlascopco.com or www.atlascopco.com. © Atlas Copco Industrial Technique AB - 9839 1800 01... -
Page 5: Service Overview
If the product is not working properly, take it out of service and inspect it. If no detailed information about preventive maintenance is included, follow these general guidelines: ■ Clean appropriate parts accurately ■ Replace any defective or worn parts © Atlas Copco Industrial Technique AB - 9839 1800 01... -
Page 6: Installation
Air Quality ■ For optimum performance and maximum product life we recommend the use of compressed air with a maximum dew point of +10°C (50°F). We also recommend to install an Atlas Copco refrigeration type air dryer. ■ Use a separate air filter which removes solid particles larger than 30 microns and more than 90% of liquid water. -
Page 7: Operation
Adapt the torque setting to the operator's strength and posture and use a torque arm or reaction bar if the torque is too high. ■ Use dust extraction system or mouth protection mask in dusty environments. © Atlas Copco Industrial Technique AB - 9839 1800 01... -
Page 8: Service
Mobil Mobilegrease XHP 222 NLG 2 Klüber Lub. Klübersynth UH 1 14-151 Texaco Multifak EP2 Molykote BR2 Plus * Not for angle gears. Brand Angle gears Molykote Longterm 2 Plus © Atlas Copco Industrial Technique AB - 9839 1800 01... -
Page 9: Recycling
When a product has served its purpose it has to be recycled properly. Dismantle the product and recycle the components in accordance with local legislation. Batteries shall be taken care of by your national battery recovery organization. © Atlas Copco Industrial Technique AB - 9839 1800 01... - Page 12 Original instructions Atlas Copco Industrial © Copyright 2019, Atlas Copco Industrial Technique AB. All rights reserved. Any Technique AB unauthorized use or copying of the contents or part thereof is prohibited. This SE-10523 STOCKHOLM applies in particular to trademarks, model denominations, part numbers and drawings.
