ETV STB63-50-10-BCR-IRC-W
Printed Matter No. 9836 8982 01
Publication Date 2020-01-15
Valid from Serial No. B0590001
ETV STB63-50-10-BCR-W
(15-50 Nm)
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
8433301960
WARNING
Battery-Powered Nutrunner
Product Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ETV STB63-50-10-BCR-IRC-W and is the answer not in the manual?

Questions and answers

Summary of Contents for Atlas Copco ETV STB63-50-10-BCR-IRC-W

  • Page 1 ETV STB63-50-10-BCR-IRC-W Printed Matter No. 9836 8982 01 Battery-Powered Nutrunner Publication Date 2020-01-15 Valid from Serial No. B0590001 Product Instructions ETV STB63-50-10-BCR-W 8433301960 (15-50 Nm) WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
  • Page 2: Table Of Contents

    Service recommendations .............. 8 Preventive maintenance ................ 8 Overhaul .................... 8 Lubrication instructions .................. 9 Lubricating guide ................... 9 Lubrication ..................... 9 Troubleshooting.................... 10 If the tool becomes abnormally hot.............. 10 Recycling ....................... 11 Recycling instruction.................. 11 Recycling information ETV STB .............. 11 © Atlas Copco Industrial Technique AB - 9836 8982 01...
  • Page 3: Product Information

    ■ Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the warranty. ■ To avoid damage or destruction of tool parts, service the tool according to the recommended mainte- nance schedules and follow the correct instructions.
  • Page 4: Website

    You can find information concerning our products, accessories, spare parts and published matters on our website. Safety Data Sheets MSDS/SDS The safety data sheets describes chemical products sold by Atlas Copco. For more information, consult the website: www.atlascopco.com/sds Country of origin Please refer to the information on the product label.
  • Page 5 ETV STB63-50-10-BCR-IRC-W Product information ■ Replace any defective or worn parts © Atlas Copco Industrial Technique AB - 9836 8982 01...
  • Page 6: Operation

    ETP: Check that the tool is in the correct running direction by pushing the revers switch. The soft-start function facilitates entering the screw head and thread. The duration of the soft start is adjustable, see the manual for the POWER FOCUS/ drive unit. © Atlas Copco Industrial Technique AB - 9836 8982 01...
  • Page 7 Connection LED: Indicates connection to Power Focus ■ Battery LED: Indicates battery status (flashing light for low and fixed light for empty battery) ■ Batch LED: Indicated Batch done ■ Alarm LED: A failure/event is detected © Atlas Copco Industrial Technique AB - 9836 8982 01...
  • Page 8: Service

    If it is judged that the electric motor is defect or in need of service, the complete motor unit should be re- turned to Atlas Copco Tools for exchange. Motors which have been opened by anyone else than Atlas Copco Tools will not be serviced. Overhaul and preventive maintenance is recommended at regular intervals once per year or after maxi- mum 250.000 tightening depending on which occurs sooner.
  • Page 9: Lubrication Instructions

    LE 3751 Lubrication Lubricate specially gears and clutch with grease containing molybdenum disulphide (e.g. Molykote BR2 Plus). Please see exploded views. Lubricate o-rings and threaded connections with grease before assem- bling. © Atlas Copco Industrial Technique AB - 9836 8982 01...
  • Page 10: Troubleshooting

    ■ torque above rated ■ too low speed ■ very high prevailing torque ■ very soft joints ■ short cycle time © Atlas Copco Industrial Technique AB - 9836 8982 01...
  • Page 11: Recycling

    Metal, Steel Planetary gear Metal, Steel Metal, Steel Planetary gear Metal, Steel Planetary gear Metal, Steel Torque transducer Electronic Motor Electronic Metal, Steel Insulation hose Plastic, Other, TPU Metal, Steel © Atlas Copco Industrial Technique AB - 9836 8982 01...
  • Page 12 Trigger button Metal, Steel Handle Plastic, Other PA Metal, Steel Metal, Steel Battery holder Metal, Aluminum Electronics module Electronic Battery (and back up bat- Battery, Li-lon tery for STB 34/ 64) © Atlas Copco Industrial Technique AB - 9836 8982 01...
  • Page 16 Original instructions © Copyright 2020, Atlas Copco Industrial Technique AB. All rights reserved. Any unauthorized use or copying of the contents or part thereof is prohibited. Atlas Copco Industrial This applies in particular to trademarks, model denominations, part numbers Technique AB and drawings.
