Printed Matter No. 9839 0664 01
Publication Date 2020-09-24
Valid from Serial No. C0580001
EP8PTI70 HR10-MT
(40-70 Nm)
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
EP8PTI70 HR10-MT
8431038155
WARNING
Impulse Nutrunner
Product Instructions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Atlas Copco EP8PTI70 HR10-MT
Summary of Contents for Atlas Copco EP8PTI70 HR10-MT
- Page 1 EP8PTI70 HR10-MT Printed Matter No. 9839 0664 01 Impulse Nutrunner Publication Date 2020-09-24 Valid from Serial No. C0580001 Product Instructions EP8PTI70 HR10-MT 8431038155 (40-70 Nm) WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
Setting of Tightening Torque When Using AutoTrim Function .... 15 Setting of Tightening Torque When Using Trim Function.... 16 Service ........................ 18 General Service Information ................ 18 Tightening of Threaded Connections.............. 18 Maintenance Instructions................ 18 Daily Inspection ................... 18 © Atlas Copco Industrial Technique AB - 9839 0664 01... - Page 3 Oil Level in the Pulse Unit .............. 28 Test After Service ................... 28 Tool Condition Test ................ 29 Torque Check - Residual Torque Measurement on Actual Joint.. 30 Troubleshooting.................... 31 Troubleshooting Guide ................... 31 Recycling ....................... 33 Environmental Regulations................ 33 Recycling Instruction.................. 33 © Atlas Copco Industrial Technique AB - 9839 0664 01...
-
Page 4: Product Information
■ Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the warranty. ■ To avoid damage or destruction of tool parts, service the tool according to the recommended mainte- nance schedules and follow the correct instructions. -
Page 5: Servaid
Please visit: https://servaid.atlascopco.com. For further Technical Information, please contact your local Atlas Copco representative. Safety Data Sheets MSDS/SDS The Safety Data Sheets describe the chemical products sold by Atlas Copco. Please consult the Atlas Copco website for more information www.atlascopco.com/sds. Special Precaution ■... -
Page 6: Overview
This pneumatic shout-off impulse tool is used for various applications where reaction free tightening and/ or high productivity is needed. Technical Product Data Technical Product Data can be found on either ServAid, or the Atlas Copco website. Please visit: https://servaid.atlascopco.com or www.atlascopco.com. -
Page 7: Installation
Air Quality ■ For optimum performance and maximum product life we recommend the use of compressed air with a maximum dew point of +10°C (50°F). We also recommend to install an Atlas Copco refrigeration type air dryer. ■ Use a separate air filter which removes solid particles larger than 30 microns and more than 90% of liquid water. -
Page 8: Operation
It is possible to connect the tool to a pressure monitoring equipment to monitor the tightening. The pres- sure signal from the tool (differential pressure over the motor) can be used to detect: ■ Missed fasteners ■ Trigger release before set torque is reached © Atlas Copco Industrial Technique AB - 9839 0664 01... -
Page 9: Optimizing Performance Of The Tool
The tightening time can also be used as a guide, to know if the tool is appropriate for your applica- tion: ■ ≤ 1 second for tools up to 30 Nm ■ ≈ 1 second for tools up to 80 Nm ■ ≈ 2 seconds for tools up to 150 Nm © Atlas Copco Industrial Technique AB - 9839 0664 01... -
Page 10: Multitrim Function
For applications where the tool is used for tightening joints with similar characteristics. Position of the Set Screw with AutoTrim or Trim Setting Relevant Information 2 Switching to Trim Function [11] 2 Switching to AutoTrim Function [11] © Atlas Copco Industrial Technique AB - 9839 0664 01... -
Page 11: Switching To Trim Function
Check that the tool works properly. Relevant Information 2 Setting of Tightening Torque When Using Trim Function [16] Adjusting the Trim Valve Switching to AutoTrim Function When the tool has been used with Trim function: © Atlas Copco Industrial Technique AB - 9839 0664 01... -
Page 12: Adjusting The Autotrim Valve
Check the recommended reduced (free) speed, according to the table AutoTrim Settings for Regular Pressure Tools or AutoTrim Settings for Low Pressure Tools. Adjust if needed. Adjusting the Reduced (free) Speed Adjust the switching point valve. Adjusting the Switching Point Valve © Atlas Copco Industrial Technique AB - 9839 0664 01... - Page 13 Model Reduced (free) speed (rpm) EP5PTI15 HR10-MT-L / HR42-MT-L 2600-3100 EP6PTI25 HR10-MT-L / HR42-MT-L 2600-3100 EP7PTI35 HR10-MT-L 2650-3050 EP8PTI45 HR10-MT-L 2650-3050 EP9PTI65 HR13-MT-L 2450-2850 EP11PTI80 HR13-MT-L 2300-2600 EP13PTI110 HR13-MT-L 2150-2550 © Atlas Copco Industrial Technique AB - 9839 0664 01...
-
Page 14: Setting Of Tightening Torque
Torque transducer IRTT Test joint ST Analyzer Make sure to always verify the torque settings on your actual joint. © Atlas Copco Industrial Technique AB - 9839 0664 01... -
Page 15: Torque Check - Residual Torque Measurement On Actual Joint
When using a tool with AutoTrim function make sure that it is correctly adjusted. When correctly adjusted the AutoTrim reduces the speed during rundown and will automatically switch to full speed/power after ap- proximately 1-2 pulses. © Atlas Copco Industrial Technique AB - 9839 0664 01... -
Page 16: Setting Of Tightening Torque When Using Trim Function
When using the tool with Trim function make sure that it is adjusted correctly. The Trim valve can be used to reduce the speed to improve the accuracy, especially on low torque settings on hard joints. © Atlas Copco Industrial Technique AB - 9839 0664 01... - Page 17 EP8PTI70 HR10-MT Operation Relevant Information 2 Adjusting the Trim Valve [11] © Atlas Copco Industrial Technique AB - 9839 0664 01...
-
Page 18: Service
If the tool is not working properly, take it out of operation for inspection. Preventive maintenance is recom- mended at regular intervals. See detailed information on Preventive Maintenance. ■ Make sure to use the service tools, service kits and spare parts recommended by Atlas Copco. ■ Make sure to follow the Service instructions provided by Atlas Copco. -
Page 19: Preventive Maintenance Level 1
Carry out maintenance after 200 000 - 250 000 tightening, see table Reference Tightening, or once a year whichever comes first. For maximum tool performance follow below instructions and use recommended service tools and service kits from Atlas Copco. Always use tightening torque and lubrications as recommended by Atlas Copco. Tool Handle ■... -
Page 20: Assembling The Pulse Unit
It is important that the camshaft and the separator washer pin is lined up with the groove in the cylinder front piece. If not, the cylinder end piece will not be correctly fastened, and the Pulse unit will not function properly. © Atlas Copco Industrial Technique AB - 9839 0664 01... -
Page 21: Assembling The Autotrim Valve
EP8PTI70 HR10-MT Service Assembling the AutoTrim Valve When re-assembling the AutoTrim after inspection or service, make sure to protect the piston sealing from the housing thread. © Atlas Copco Industrial Technique AB - 9839 0664 01... -
Page 22: Assembling Motor In Housing
Press the inertia body to open the hole for the gauge. Place a gauge, for instance a drill bit, with the correct diameter of D (see table Gauge Diameter) in the hole. © Atlas Copco Industrial Technique AB - 9839 0664 01... - Page 23 Check that the gauge is correctly inserted by repeatedly pressing and releasing the inertia body. The gauge should return to the correct position in line with the Pulse unit. Apply Loctite 290 to the adjustment screw. Gauge Diameter D (mm) 1.5 mm © Atlas Copco Industrial Technique AB - 9839 0664 01...
-
Page 24: Lubrication Instructions
4 x Hose length 540 mm ■ 2 x Hose length 50 mm ■ 1 x Hose length 120 mm ■ 1 x Syringe 50 ml ■ 1 x Syringe 1 ml © Atlas Copco Industrial Technique AB - 9839 0664 01... - Page 25 16. Put the screw covering the inlet opening back in position. Oil Filling Oil reduction (X) from 100% full Pulse unit Approximate oil volume in Pulse unit 0.5 ± 0.05 ml 9 ml © Atlas Copco Industrial Technique AB - 9839 0664 01...
- Page 26 Service EP8PTI70 HR10-MT © Atlas Copco Industrial Technique AB - 9839 0664 01...
- Page 27 EP8PTI70 HR10-MT Service © Atlas Copco Industrial Technique AB - 9839 0664 01...
-
Page 28: Oil Level In The Pulse Unit
2 Torque Check - Residual Torque Measurement on Actual Joint [30] 2 Tool Condition Test [29] Test After Service Perform a Tool Condition Test to make sure that the tool is working properly. © Atlas Copco Industrial Technique AB - 9839 0664 01... -
Page 29: Tool Condition Test
Correct pulse frequency indicates that the air motor and the Pulse unit are in good condition. If the pulse frequency is too high - add more oil. If the pulse frequency is too low - reduce the oil level. © Atlas Copco Industrial Technique AB - 9839 0664 01... -
Page 30: Torque Check - Residual Torque Measurement On Actual Joint
* Torque required to cause the threads of the fastener (including its head) on which torque is applied, to move relative to the mating thread. The actual joint Torque wrench with monitoring Perform a tightening. Measure the result with the Torque wrench with monitoring. © Atlas Copco Industrial Technique AB - 9839 0664 01... -
Page 31: Troubleshooting
Malfunctioning AutoTrim. Check the AutoTrim function. The joint is too soft and max torque Reduce the torque setting slightly, setting. or use a bigger tool with more power. © Atlas Copco Industrial Technique AB - 9839 0664 01... - Page 32 Valve. Dirt or damaged parts in the Au- Inspect and replace any worn toTrim. parts. The wrong auto-trim part has been Check Spare Part for to use, see used. https://servaid.atlascopco.com. © Atlas Copco Industrial Technique AB - 9839 0664 01...
-
Page 33: Recycling
Screw ring Metal, steel Sleeve Metal, steel Ball bearing Metal, steel End plate Metal, aluminum Cylinder Metal, aluminum Rotor Metal, steel 7 vanes Plastics, other, POM 7 plugs Plastics, other, POM © Atlas Copco Industrial Technique AB - 9839 0664 01... - Page 34 Metal, steel Support washer Metal, aluminum Inlet washer Metal, aluminum Trigger Metal, steel Motor casing Metal, aluminum Valve Metal, brass Silencer Metal, steel Adapter Metal, aluminum/steel Protective cover Plastics, other, PUR © Atlas Copco Industrial Technique AB - 9839 0664 01...
- Page 36 Original instructions © Copyright 2020, Atlas Copco Industrial Technique AB. All rights reserved. Any unauthorized use or copying of the contents or part thereof is prohibited. Atlas Copco Industrial This applies in particular to trademarks, model denominations, part numbers Technique AB and drawings.
