Compresor de aire
A. Filtro de entrada de aire de la bomba
B. Interruptor ENCENDIDO [AUTO(-)] / Off (APAGADO(O)]
C. Manómetro del tanque de aire
D. Manómetro regulado
E. Pressure Regulator
F. Conexión rápida
G. Válvula de seguridad
H. Válvula de drenaje del tanque de aire
I.
Válvula reguladora
J. Rueda
K. Aislador
Specificaciones de bomba / motor
Sin aceite
Mando directo
0.11 m
/ min. @ 621 kPa
3
VOLTAJE: MONOFÁSICO 120V
EXIGENCIA MÍNIMA - CIRCUITO DE DERIVACIÓN: 15A
TIPO DE FUSIBLE: ACCIÓN RETARDADA
Especificaciones
MODELO
PESO
ALTURA
ANCHO
LONGITUD
CAPACIDAD DEL TANQUE DE AIRE 98,4 liters (26 gallons)
PRESIÓN APROXIMADA DE ALIVIO 1207 kPa (175 PSI)
DXCMSAC260
55,4 kg
124,46 cm
51,05 cm
58,42 cm
49
FIG. 1
A
B
