Follow these steps to connect the hub to devices in your network.
1.
2.
3.
Select an appropriate location.
Connect a workstation to any available RJ-45 station port (1-5) on the
hub using unshielded twisted-pair (UTP) cable. All connected devices
must be within 100 meters of the hub. You can connect up to five
workstations if you use the hub in a stand-alone configuration.
Uplinking Hubs
To uplink hubs, connect one hub's UPLINK port to a normal
workstation port of another 1005 or compatible hub.
To limit the number of hubs in a path (when cascading more than two
hubs), link several hubs to one central hub. Be sure there is only one
path between any two stations on the network.
Plug the power adapter into the hub, and connect it to a grounded
electrical outlet.
