Compaq Netelligent 1005 User Manual page 10

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmission Technique
Topology
Access Method
Standard Conformance
Media Supported
Interfaces
Hub-to-Workstation Distance
Dimensions
Power Requirements:
Temperature:
Humidity:
Certification:
Emissions:
Immunity:
Safety:
:
:
:
:
:
:
:
:
Baseband
Tree or Star
CSMA/CD, 10 Mb/s
IEEE 802.3 10Base-T
Category 3, 4, 5 twisted-pair cable
Five RJ-45 station ports, One RJ-45
uplink port
100m max cable length
4.72 x 3.78 x 1.10 Inches
(12.1 x 9.7 x 2.82 cm)
8VAC, 50/60 Hz, 5 watts
Power Adapter: External power
adapter - 8 VAC, 8VA for
100V/120V/220-230V/240V AC input
0°C to 50°C (Standard Operating)
5% to 95% (Noncondensing)
CE Mark
FCC Class B, VCCI Class 2,
CISPR Class B
IEC 801-2,3,4, EN60555-2 Class D,
EN60555-3
UL, CSA, TÜV/GS
