Unverferth Killbros 1135 Manual

Grain handling, corner auger grain cart
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Grain Handling
CORNER AUGER GRAIN CART
MODEL 1135
Serial Number B36620100 & Higher
Part No. 287969

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Killbros 1135 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unverferth Killbros 1135

Summary of Contents for Unverferth Killbros 1135

  • Page 1 Grain Handling CORNER AUGER GRAIN CART MODEL 1135 Serial Number B36620100 & Higher Part No. 287969...
  • Page 2 — Introduction Killbros 1135 Foreword This symbol identifies important safety messages. When you see it, read the message that follows and be alert to the possibility of personal injury. Remember, safety instructions stated in this manual are for your protection. Read them care- fully and follow them closely when working around or using this machine.
  • Page 3 The information, specifications, and illustrations in the manual are based on information available at the time it was written. Due to continuing improvements in the design and manufacture of Unverferth products, all specifications and information contained herein are subject to change without notice.

  • Page 4: Table Of Contents

    — Introduction Killbros 1135 Table of Contents Section I Safety General Hazard Information ......................1-2 Safety Decals ..........................1-3 Following Safety Instructions ......................1-5 Before Operating ..........................1-6 Before Servicing..........................1-6 During Operation ..........................1-7 Before Transporting ......................... 1-8 During Transport..........................1-8 Driveline Safety ..........................
  • Page 5 — Introduction Killbros 1135 Table of Contents Section II Set Up Set Up Checklist ..........................2-2 Basic Set Up........................... 2-3 Sideboard and End Caps ......................2-4 Tarp Installation ........................2-11 SMV Emblem and SIS Decals....................2-18 Auger Rest Retainer Removal ....................2-19 Auger Rotational Spout Stop Removal..................
  • Page 6 — Introduction Killbros 1135 Table of Contents Section III Operation Operating Checklist ......................... 3-2 Preparing Tractor..........................3-3 Preparing Cart Hardware ..........................3-3 Pivot Pins ..........................3-3 Hitch ............................3-3 Auger ............................3-3 Auger Driveline Assembly......................3-4 Soft Start System........................3-5 Hydraulic System........................
  • Page 7 — Introduction Killbros 1135 Table of Contents Section IV Maintenance Lubrication............................4-2 Gearbox Lubrication ........................4-4 Seasonal Storage ..........................4-4 Auger System..........................4-5 Lower Auger Disassembly ......................4-5 Lower Auger Assembly......................4-6 Upper Auger Disassembly......................4-8 Upper Auger Assembly ......................4-9 Auger Flow Door Cylinder Replacement ..................
  • Page 8 — Introduction Killbros 1135 Table of Contents Section V Parts Touch-Up Paint........................... 5-2 Final Assembly ........................... 5-2 Rigid Axle........................... 5-4 Adjustable Axle........................... 5-6 Track Axle Components with 5 Point Scale System ..............5-8 Hub Components........................5-10 Wheels & Tires ........................5-12 Decals ............................
  • Page 9 — Safety Killbros 1135 Section I Safety General Hazard Information ......................1-2 Safety Decals ..........................1-3 Following Safety Instructions ......................1-5 Before Operating ..........................1-6 Before Servicing..........................1-6 During Operation ..........................1-7 Before Transporting ......................... 1-8 During Transport..........................1-8 Driveline Safety ..........................1-9 Pressurized Oil ..........................

  • Page 10: Safety

    It is true that the designer, the manufacturer, and the safety engineer can help; and they will help, but their combined efforts can be wiped out by a single careless act of the operator. It is said that, “the best kind of a safety device is a careful operator.” We, at Unverferth Mfg.

  • Page 11: Safety Decals

    — Safety Killbros 1135 Safety Decals • REPLACE LOST, DAMAGED, PAINTED, OR UNREADABLE DECALS IMMEDIATELY. IF PARTS THAT HAVE DECALS ARE REPLACED, ALSO MAKE SURE TO INSTALL NEW DECALS. THESE DECALS INFORM AND REMIND THE OPERATOR WITH OPERATIONAL INFORMATION AND SAFETY MESSAGES.
  • Page 12 — Safety Killbros 1135 Safety Decals (continued) 95839 TA510514 9008714 95445 9008720 REFLECTORS 9003125 (Fluorescent) 9003126 (Red) 9003127 (Amber) 9003475 Always consult your operator’s manual for correct tire pressure and wheel hardware torque specifications. 94754 94754...

  • Page 13: Following Safety Instructions

    — Safety Killbros 1135 Following Safety Instructions • Read and understand this operator’s manual before operating. • All machinery should be operated only by trained and authorized personnel. • To prevent machine damage, use only attachments and service parts approved by the manufac- turer.

  • Page 14: Before Operating

    — Safety Killbros 1135 Before Operating • Do not stand between towing vehicle and implement during hitching. • Always make certain everyone and everything is clear of the machine before beginning operation. • Verify that all safety shields are in place and properly secured.

  • Page 15: During Operation

    — Safety Killbros 1135 During Operation • Regulate speed to field conditions. Maintain complete control at all times. • Never lubricate equipment when in operation. • Keep away from overhead power lines. Electrical shock can cause serious injury or death.

  • Page 16: Before Transporting

    — Safety Killbros 1135 Before Transporting • Secure transport chains to towing vehicle before transporting. DO NOT transport without chains. • Check for proper function of all available transport lights. Make sure that all reflectors are clean and in place on machine. Make sure the SMV emblem and SIS decals are clean and visible to ap- proaching traffic.

  • Page 17: Driveline Safety

    — Safety Killbros 1135 Driveline Safety • Do not allow children near equipment that is running or engaged. • Do not exceed 1000 r.p.m. PTO speed. • Disengage the PTO, stop the tractor engine, and remove key from ignition before making inspec- tions, or performing maintenance and repairs.

  • Page 18: Pressurized Oil

    — Safety Killbros 1135 Pressurized Oil • Relieve the hydraulic system of all pressure before adjusting or servicing. See hydraulic power unit manual for procedure to relieve pressure. • High-pressure fluids can penetrate the skin and cause serious injury or death. Use cardboard or wood to detect leaks in the hydraulic system.

  • Page 19: Preparing For Emergencies

    — Safety Killbros 1135 Preparing for Emergencies • Keep a first aid kit and properly rated fire extinguisher nearby. • Keep emergency numbers for fire, rescue, and poison control personnel near the phone. Wearing Protective Equipment • Wear clothing and personal protective equipment appropriate for the job.
  • Page 20 — Safety Killbros 1135 Notes 1-12...

  • Page 21: Set Up

    — Set Up Killbros 1135 Section II Set Up Set Up Checklist ..........................2-2 Basic Set Up........................... 2-3 Sideboard and End Caps ......................2-4 Tarp Installation ........................2-11 SMV Emblem and SIS Decals....................2-18 Auger Rest Retainer Removal ....................2-19 Auger Rotational Spout Stop Removal..................

  • Page 22: Set Up Checklist

    — Set Up Killbros 1135 Set Up Checklist After the cart has been completely assembled, use the following checklist and inspect the cart. Check off each item as it is found satisfactory or after proper adjustment is made. o Torque wheel nuts and check tire pressure as specified in MAINTENANCE section.

  • Page 23: Basic Set Up

    — Set Up Killbros 1135 Basic Set Up FIG. 2-1 Tractor Electrical & Hydraulic Hook-Up Spout Jack “Transport Position” Jack “Parked Position” Due to shipping requirements and various dealer-installed options, some initial cart set up will be required after it arrives from the factory. Use the following procedures as needed for initial cart set up.

  • Page 24: Sideboard And End Caps

    — Set Up Killbros 1135 Basic Set Up (continued) Sideboards and End Caps 1. Park the empty grain cart on a firm, level sur- face. Block the tires/tracks on the machine to keep it from moving. 2. Remove the crank handle and the crank handle holder from inside the cart.
  • Page 25 — Set Up Killbros 1135 Basic Set Up (continued) 5. Lift the left-hand sideboard into position. NOTE: Hinge brackets WILL support the sideboard and tarp if included. NOTE: On some models, shocks are attached FIG. 2-5 to the left-hand sideboard, FIG 2-5.
  • Page 26 — Set Up Killbros 1135 Basic Set Up (continued) 7. Install brace tubes. Install The Sideboard ONE PIECE BRACE TUBE: Brace Tube Install sideboard brace tubes on each cross tube weldment. Each weldment will have one left-hand and one right-hand sideboard brace tube.
  • Page 27 — Set Up Killbros 1135 Basic Set Up (continued) 8. If included, remove and discard the shocks and associated brackets from the left-hand sideboard. 9. Lift the large rear sideboard up into position and loosely secure with 3/8” flange screws and flange nuts along the bottom.
  • Page 28 — Set Up Killbros 1135 Basic Set Up (continued) 11. If included, remove and discard the shipping bracket from the small rear panel. 12. Connect the large rear sideboard to the left-hand sideboard using the small rear panel. Loosely secure using 3/8” hardware. See Figure 2-10.
  • Page 29 — Set Up Killbros 1135 Basic Set Up (continued) 13. Attach smaller end cap on top of rear side- Small boards using 3/8” hardware and one 1/4” self- End Cap drilling screw. See Figure 2-11. 1/4” Self- Drilling NOTE: The small end cap tab will fit underneath Screw the large end cap.
  • Page 30 — Set Up Killbros 1135 Basic Set Up (continued) 15. Remove and discard the shipping bracket from the front sideboard. 16. Lift large front sideboard into position and loosely secure with 3/8” flange screws and flange nuts along the bottom. See Figure 2-13.

  • Page 31: Tarp Installation

    — Set Up Killbros 1135 Basic Set Up (continued) Tarp Installation NOTE: For carts SN B41380099 & lower, skip to step 2 on next page. NOTE: Ensure RH and LH doublers are inside the sideboard lip. See Figure 2-15. 1. For carts SN B41380100 & higher, install six long tarp bows (287400B) across top of the cart, us- ing bracket (283425B), RH doubler (289986B), LH doubler (281936B), 3/8”-16UNC x 3”...
  • Page 32 — Set Up Killbros 1135 Basic Set Up (continued) 2. Install six long tarp bows (287400B) across the top of the cart, using bracket (283425B), 3/8”-16UNC x 3” capscrew (902703-046), 3/8”-16UNC (91263), 5/16”-18UNC x 3/4” flange screw (91256) and 5/16”-18UNC flange nut (91257). See Figure 2-16 and 2-17.
  • Page 33 — Set Up Killbros 1135 Basic Set Up (continued) NOTE: Ensure capscrew head (902703-046) is flush with the top of bow weldment (287400B). Capscrew See Figure 2-18. (902703-046) 3. Tighten all hardware. Tarp Bow (287400B) Fig. 2-18 2-13...
  • Page 34 — Set Up Killbros 1135 Basic Set Up (continued) 4. Install four tarp cables across the top Attach Tarp Cables using 3/8”-16UNC 1/2” capscrew Capscrew (TA0-907131-0), 3/8” lock washer (9005688), (TA0-907131-0) 3/8” fender washer (9005696) and bracket & U-nut assembly (281712B). See Figures 2-19 Lock through 2-22.
  • Page 35 — Set Up Killbros 1135 Basic Set Up (continued) 6. Install end cap extension (283431B) between End Cap Extension the end cap and right-hand sideboard on both (283431B) the front and rear of cart. Retain in place using two 3/8”-16 x 1” carriage bolts (9388-051), two 3/8”-16 flange nuts (91263) and one 1/4”-14 x...
  • Page 36 — Set Up Killbros 1135 Basic Set Up (continued) 8. Attach the crank handle to the tarp roll tube, Fig. 2-26 Figure 2-26. Once secure, roll tarp across the cart to the closed position. Attach to Tube Crank Handle 9. Confirm that the roll tube on the handle is at a Fig.
  • Page 37 — Set Up Killbros 1135 Basic Set Up (continued) 11. Add #10-16 x 3/4” self-drilling screws (9005197) Fig. 2-28 and U-clamps (9004949) to secure tarp in place on the roll tube side. Check that clips are lo- cated on the straps with an even height across, Figures 2-28 and 2-29.

  • Page 38: Smv Emblem And Sis Decals

    — Set Up Killbros 1135 Basic Set Up (continued) SMV Emblem & SIS Decals Before the cart is used the reflective surface FIG. 2-31 of the SMV must face rearward. This may re- quire removal of film protecting the reflective surface or removing and reinstallation of the SMV.

  • Page 39: Auger Rest Retainer Removal

    — Set Up Killbros 1135 Basic Set Up (continued) Auger Rest Retainer Removal Remove the retainer located on the upper auger rest at the back of the cart, before folding out the upper auger tube. (FIG. 2-33) • Upper auger retainer must be removed before operating upper auger tube.

  • Page 40: Lamp Set Up

    See federal regulation 49 CFR 562; available at www.govinfo.gov for US federal law require- ments. Amber Reflector To Front of Cart See your Unverferth dealer for additional brackets, reflectors, or lights to meet your requirements. FIG. 2-36 Driveline Storage Storage brackets are located on the inside right frame rail. Secure the PTO shaft to these brackets for extended transporting or seasonal storage.

  • Page 41: Wheel/Tire Set Up

    — Set Up Killbros 1135 Basic Set Up (continued) Wheel/Tire Set Up Tire Pressure Tire pressure must be verified before first use and adjusted as necessary. Refer to MAINTENANCE section of this manual for information on tire pressure. Wheel Nuts •...

  • Page 42: Adjustable Axle (Optional)

    — Set Up Killbros 1135 Basic Set Up (continued) Adjustable Axle (Optional) • FALLING OBJECTS CAN CAUSE SERIOUS INJURY OR DEATH. DO NOT WORK UNDER THE MACHINE AT ANY TIME WHILE BEING HOISTED. BE SURE ALL LIFTING DEVICES AND SUPPORTS ARE RATED FOR THE LOADS BEING HOISTED. THESE ASSEMBLY INSTRUCTIONS WILL REQUIRE SAFE LIFTING DEVICES UP TO 16,000 LBS.
  • Page 43 — Set Up Killbros 1135 Basic Set Up (continued) Adjustable Axle (Optional) (continued) 4. Slide extensions to desired tire gauge spacing. Axle extensions should be extended equally. Refer to chart below and FIG. 2-39. Slide Out Distance Distance Hub Flange...
  • Page 44 — Set Up Killbros 1135 Notes 2-24...

  • Page 45: For Track Information, Please Refer To Your Track Manual

    — Operation Killbros 1135 Section III Operation Operating Checklist ......................... 3-2 Preparing Tractor..........................3-3 Preparing Cart Hardware ..........................3-3 Pivot Pins ..........................3-3 Hitch ............................3-3 Auger ............................3-3 Auger Driveline Assembly......................3-4 Soft Start System........................3-5 Hydraulic System........................3-5 Tires/Wheels..........................

  • Page 46: Operating Checklist

    — Operation Killbros 1135 Operating Checklist o Read and understand all safety precautions before operating cart.  Check axle spacing to be sure axle is adjusted from shipping position to desired operating width. (If applicable)  Check to be sure all the reflective decals, SMV sign and SIS decals are clearly visible with the cart attached to the tractor.

  • Page 47: Preparing Cart

    — Operation Killbros 1135 Preparing Cart Perform the service checks as outlined below. Repair or replace any damaged or worn parts before operating. Hardware Check for loose bolts and nuts, and tighten as needed. Check again after the first half-day of operation.

  • Page 48: Auger Driveline Assembly

    — Operation Killbros 1135 Preparing Cart (continued) Auger Driveline Assembly NOTE: Ends of driveshaft are symmetrical. Universal Joint Drill Dimple 1. Slide driveshaft down into the universal joint at- Orientaton in Line on Driveshaft tached to the gearbox until the end of the shaft extends into the universal joint about 2 3/8”.

  • Page 49: Soft Start System

    — Operation Killbros 1135 Preparing Cart (continued) Soft Start System Check for wear or damage. Hydraulic System Check all hoses and cylinders for signs of leakage. Hoses should not be kinked, twisted or rubbing against sharp edges. Re-route or repair hoses as necessary. Refer to SAFETY section for additional information on safe repair and inspection of hydraulic components.

  • Page 50: Hitching To Tractor Drawbar Connection

    — Operation Killbros 1135 Hitching to Tractor Drawbar Connection This cart is intended to be hitched to a tractor drawbar. Do not attempt to hitch to any other location on the tractor other than the drawbar. The cart is equipped standard with a single tang hitch.

  • Page 51: Jack Usage

    — Operation Killbros 1135 Hitching to Tractor (continued) Jack Usage • UNHITCHING A LOADED CART CAN CAUSE SERIOUS INJURY OR DEATH DUE TO THE TONGUE RISING OR FALLING. ALWAYS HAVE A LOADED CART ATTACHED TO A TRACTOR. THE JACK IS INTENDED TO SUPPORT AN EMPTY CART ONLY.

  • Page 52: Transport Chain Connection

    — Operation Killbros 1135 Hitching to Tractor (continued) Transport Chain Connection • ALWAYS USE TRANSPORT CHAIN WHEN TRANSPORTING IMPLEMENTS. FAILURE TO USE A TRANSPORT CHAIN COULD CAUSE PERSONAL INJURY IF CART BECOMES DISENGAGED. Always use intermediate chain support when connecting the grain cart directly to a tractor.

  • Page 53: Hydraulic Connections For Hydraulic Drive

    — Operation Killbros 1135 Hitching to Tractor (continued) Clean hydraulic hose couplers before connecting to the tractor. For convenience, it is recom- mended to connect the flow door circuit hoses to tractor implement coupler #1, auger spout circuit hoses to coupler #2, and attach auger fold circuit to coupler #3.

  • Page 54: Electrical Connections

    Compliance with all lighting and marking laws is the responsibility of the operator at the time of travel. See federal regulation 49 CFR 562; available at www.govinfo.gov for US federal law require- ments. See your Unverferth dealer for additional brackets, reflectors, or lights to meet your require- ments. 3-10...

  • Page 55: Towing

    — Operation Killbros 1135 Towing This cart is not equipped with brakes. Ensure that the towing vehicle has adequate weight and braking capacity to tow this implement. See towing vehicle’s operators manual for tow- ing capacity. Never tow a loaded grain cart over public roads.

  • Page 56: Auger Operation Pto Driven Auger

    — Operation Killbros 1135 Auger Operation PTO Driven Auger • ELECTROCUTION WILL CAUSE SERIOUS INJURY OR DEATH. THE GRAIN CART IS NOT INSULATED. KEEP AWAY FROM ALL ELECTRI- CAL LINES AND DEVICES. ELECTROCUTION CAN OCCUR WITHOUT DIRECT CONTACT. • ENTANGLEMENT WITH THE DRIVELINE WILL CAUSE SERIOUS INJURY OR DEATH.

  • Page 57: Hydraulic Drive (Optional)

    — Operation Killbros 1135 Hydraulic Drive (Optional) The optional hydraulically-driven auger permits FIG. 3-12 cart operation using tractors that are not equipped with a PTO. However, due to the power requirements of a grain cart, it should be expected that a hydraulically-driven grain cart will not unload as quickly as a PTO driven cart.
  • Page 58 — Operation Killbros 1135 Hydraulic Drive (Optional) (continued) NOTE: For complete assembly and operation details for the Hydraulic Drive, please refer to the Hydraulic Drive manual (282894). 1. Before loading cart or operating auger, verify that the flow control door is closed.

  • Page 59: Weather Guard Tarp

    — Operation Killbros 1135 Weather Guard Tarp • TO PREVENT PERSONAL INJURY OR DEATH, DO NOT ALLOW ANYONE ON A CLOSED TARP. TARP SYSTEM IS NOT DESIGNED TO SUPPORT A PERSON. • FALLING OBJECTS CAN CAUSE SERIOUS INJURY OR DEATH. REMOVE ACCUMULATED WATER/SNOW/ICE OR ANY OTHER OBJECTS FROM TARP BEFORE OPENING TARP.
  • Page 60 — Operation Killbros 1135 Weather Guard Tarp (continued) Procedure 1. Using both hands, carefully remove crank from holder. (FIG. 3-14) 2. Roll tarp to the desired location, choosing either a fully open or fully closed position. 3. To close the tarp, roll the main tarp tube clockwise up under the latch plate. Next, bring the crank handle down perpendicular to the ground.

  • Page 61: For Track Information, Please Refer To Your Track Manual

    — Maintenance Killbros 1135 Section IV Maintenance Lubrication............................4-2 Gearbox Lubrication ........................4-4 Seasonal Storage ..........................4-4 Auger System..........................4-5 Lower Auger Disassembly ......................4-5 Lower Auger Assembly......................4-6 Upper Auger Disassembly......................4-8 Upper Auger Assembly ......................4-9 Auger Flow Door Cylinder Replacement .................. 4-10 Bearings............................

  • Page 62: Lubrication

    — Maintenance Killbros 1135 Lubrication To keep your grain cart in top operating condition and to assure its proper performance and reliability for a long period of time, periodic inspection and lubrication is a must. 1 SHOT GREASE WEEKLY SEE CHART...
  • Page 63 To keep your grain cart in top operating condition and to assure its proper performance and reliability for a long period of time, periodic inspection and lubrication is a must. Unverferth Mfg. recommends use of NLGI #2 Extreme Pressure grease. The lubrication locations and recommended schedule are as follows:...

  • Page 64: Gearbox Lubrication

    — Maintenance Killbros 1135 Gearbox Lubrication Gearbox check/fill plug is located on the right hand front side of the housing. To check oil fluid level, place cart on a level surface with the tongue elevated to hitch height and remove the plug.

  • Page 65: Auger System

    — Maintenance Killbros 1135 Auger System • TO PREVENT PERSONAL INJURY OR DEATH, ALWAYS ENSURE THAT THERE ARE PEOPLE WHO REMAIN OUTSIDE THE CART TO ASSIST THE PERSON WORKING INSIDE, AND THAT ALL SAFE WORKPLACE PRACTICES ARE FOLLOWED. THERE IS RESTRICTED MOBILITY AND LIMITED EXIT PATHS WHEN WORKING INSIDE THE IMPLEMENT.

  • Page 66: Lower Auger Assembly

    — Maintenance Killbros 1135 Auger System (continued) Lower Auger Assembly 1. When installing the coupler into the auger pipe, the lower auger flighting should be set with the FIG. 4-2 driving surface of the drive lobe at a 6 o’clock position and the flighting edge at a 7 o’clock...
  • Page 67 — Maintenance Killbros 1135 Auger System (continued) Lower Auger Assembly (continued) 4. Rotate auger 360 degrees to ensure it is cen- FIG. 4-4 tered on the drive bushing weldment (286436) and the five pins are engaged with auger end. Check for flighting interference or binding along housing and at lower end.

  • Page 68: Upper Auger Disassembly

    — Maintenance Killbros 1135 Auger System (continued) Upper Auger Disassembly 1. Support the upper auger assembly using a 2-ton hoist and two straps rated for 2000 lbs. 2. Remove auger tube cylinder pin and carefully swing cylinder down without breaking hose connec- tions.

  • Page 69: Upper Auger Assembly

    — Maintenance Killbros 1135 Auger System (continued) Upper Auger Assembly 1. Install upper bearing and spring assembly if previously removed. 2. Insert auger in auger tube. Back out bearing setscrews and insert auger stub shaft through bearing. Retain auger with 5/16” x 2” machine screw and nut.

  • Page 70: Auger Flow Door Cylinder Replacement

    — Maintenance Killbros 1135 Auger System (continued) Auger Flow Door Cylinder Replacement • TO PREVENT PERSONAL INJURY OR DEATH ALWAYS ENSURE THAT THERE ARE PEOPLE WHO REMAIN OUTSIDE THE CART TO ASSIST THE PERSON WORKING INSIDE, AND THAT ALL SAFE WORKPLACE PRACTICES ARE FOLLOWED. THERE IS RESTRICTED MOBILITY AND LIMITED EXIT PATHS WHEN WORKING INSIDE THE IMPLEMENT.
  • Page 71 — Maintenance Killbros 1135 Auger System (continued) Auger Flow Door Cylinder Replacement (continued) 2. On the inside of the cart, open the screen ser- FIG. 4-9 vice access panel shown in FIG. 4-9. Screen Service Access Panel 3. Remove the cotter pins from the lower cylinder pin then remove the pin.
  • Page 72 — Maintenance Killbros 1135 Auger System (continued) Auger Flow Door Cylinder Replacement (continued) 6. Label the hydraulic hoses to indicate upper and lower. Disconnect them from the cylin- Remove Lower der, along with the lower hydraulic fitting (FIG. Hose & Fitting 4-11).

  • Page 73: Bearings

    — Maintenance Killbros 1135 Auger Driveline Bearings It is important to periodically check set screws in all bearings at either end of the driveline for tightness. Gearbox Fluid level/fill plug is in front of the axle on the right OIL LEVEL SHOULD BE AT THE...
  • Page 74 — Maintenance Killbros 1135 Auger Driveline (continued) 4. Remove paint on driveshaft to allow for easier movement. Slide driveshaft forward until the rear spline is out of the universal joint connect- ed to the gearbox. 5. Drop the gearbox end of driveshaft down and slide driveshaft out of the flangette bearing on the hitch end of the driveshaft.
  • Page 75 — Maintenance Killbros 1135 Auger Driveline (continued) 11. Slide driveshaft down into the gearbox universal joint attached to the gearbox until the end of the shaft extends into the universal joint about 2 3/8”. Ensure universal joint and driveshaft splines completely engage.

  • Page 76: Adjusting Cleanout Door

    — Maintenance Killbros 1135 Adjusting Cleanout Door • MOVING PARTS CAN CRUSH AND CUT. KEEP AWAY FROM MOVING PARTS. • KEEP HANDS CLEAR OF PINCH POINT AREAS. • EYE PROTECTION AND OTHER APPROPRIATE PERSONAL PROTECTIVE EQUIPMENT MUST BE WORN WHILE SERVICING THE IMPLEMENT.
  • Page 77 — Maintenance Killbros 1135 Adjusting Cleanout Door (continued) 5. Push the gear assembly toward bottom of au- ger to remove excess movement and prevent Push Gear Assembly the door from moving upward when unloading Toward Bottom of Auger the cart. (FIG. 4-19) FIG.

  • Page 78: Verify Telescoping Pto Shaft Length

    — Maintenance Killbros 1135 Verify Telescoping PTO Shaft Length - GKN Walterscheid PTO • PROPERLY EXTENDED AND COLLAPSED LENGTHS OF THE TELESCOPING PTO SHAFT MUST BE VERIFIED BEFORE FIRST OPERATION WITH EACH AND EVERY DIFFERENT TRACTOR. IF THE EXTENDED LENGTH OF THE PTO SHAFT IS NOT SUFFICIENT, IT...
  • Page 79 — Maintenance Killbros 1135 Verify Telescoping PTO Shaft Length - GKN Walterscheid PTO (continued) 4. Hitch tractor drawbar to cart, ensuring that tractor and cart are on level ground and coupled as straight as practical. 5. Connect PTO shaft to tractor, and measure length “L” from same points as used in step 1. Ensure that this measurement does not exceed the maximum recommended extended length calculated in step 3 above.

  • Page 80: Pto Shaft And Clutch - Benzi Pto

    — Maintenance Killbros 1135 PTO Shaft and Clutch - Benzi PTO Lubrication Lubricate with NLGI grade 2 grease before starting work and every 8 operating hours. Clean and grease PTO drive shaft before each prolonged period of non-use. Molded nipples on the shield near each shield bearing are intended as grease fittings and should be lubricated every 8 hours of operation! Check and grease the guard tubes in winter to prevent freezing.
  • Page 81 — Maintenance Killbros 1135 PTO Shaft and Clutch - Benzi PTO (continued) Shear-Bolt and Friction Clutches (Figs. H1 - H3) 1. Shear bolt clutches: When the set torque value is exceeded, power flow is interrupted due to the bolt shearing.
  • Page 82 — Maintenance Killbros 1135 PTO Shaft and Clutch - Benzi PTO (continued) To Dismantle Guard (Figs. J1 - J3) 1. Pull the guard tube backwards and, using a screwdriver, disengage the three bearing ring tabs by pushing them inward. (FIG. J1) 2.
  • Page 83 — Maintenance Killbros 1135 PTO Shaft and Clutch - Benzi PTO (continued) To Assemble Guard (Figs. K1 - K3) 1. Clean and grease the bearing ring, yoke groove and inner profile tube. (FIG. K1) 2. Fit bearing ring in groove with three bearing ring tabs positioned as shown.

  • Page 84: Pto Locking Systems - Benzi Pto

    — Maintenance Killbros 1135 PTO Locking Systems - Benzi PTO Ball-Type Collar Coupling Slide clamp yoke or clutch onto connecting shaft. Pull in the coupler collar to release the balls and simultaneously push PTO driveshaft into the connecting shaft until the coupler collar locks onto the connecting shaft annular grooves.

  • Page 85: Pto Shaft And Clutch - Gkn Walterscheid Pto

    — Maintenance Killbros 1135 PTO Shaft and Clutch - GKN Walterscheid PTO Lubrication (Figs. D1 - D6) Lubricate with quality grease before starting work and every 8 operating hours. Clean and grease PTO driveshaft before each prolonged period of non-use.
  • Page 86 — Maintenance Killbros 1135 PTO Shaft and Clutch - GKN Walterscheid PTO (continued) Coupling the PTO driveshaft (Figs. E1 - E2) Clean and grease the PTO and implement input connection (IIC) AS-Lock 1. Pull locking collar and simultaneously push PTO driveshaft onto PTO shaft until the locking device engages.
  • Page 87 — Maintenance Killbros 1135 PTO Shaft and Clutch - GKN Walterscheid PTO (continued) Chains (Figs. G1 - G3) NOTE: The chain is intended to prevent the shield from rotating against non-moving parts and there- by preventing shield damage. A properly installed chain will increase the service life of the shield.
  • Page 88 — Maintenance Killbros 1135 PTO Shaft and Clutch - GKN Walterscheid PTO (continued) To Dismantle Guard (Figs. J1 - J4) 1. Remove locking screw. 2. Align bearing tabs with cone pockets. 3. Remove half-guard. 4. Remove bearing ring. To Assemble Guard (Figs. K1 - K5) 1.
  • Page 89 — Maintenance Killbros 1135 PTO Shaft and Clutch - GKN Walterscheid PTO (continued) To Assemble Cone (Figs. L1 - L3) 1. Dismantle guard (Figs. J1 - J3). Remove old cone (e.g. cut open with knife). Take off chain. Place neck of new cone in hot water (approx 80°...

  • Page 90: Pto Quick Disconnect - Gkn Walterscheid Pto

    — Maintenance Killbros 1135 PTO Quick Disconnect - GKN Walterscheid PTO Quick Disconnect Pin Using a drift punch and hammer, drive the pin towards the retaining washer to force the complete assembly out. Clear the edges of the retaining washer bore to accept the new one by removing the deformed metal from the last peening operation to hold the washer in place.
  • Page 91 — Maintenance Killbros 1135 PTO Quick Disconnect - GKN Walterscheid PTO (continued) Quick Disconnect Disassembly 1. Compression Spring 2. Ball 3. Lock Collar 4. Back-up ring 5. Snap ring * Back-up ring * (For some clutch types, place additional back up ring first).
  • Page 92 — Maintenance Killbros 1135 PTO Quick Disconnect - GKN Walterscheid PTO (continued) Clutch Disassembly Tighten the four hex nuts (12) uniformly until the clutch pack and hub are loose. Use special tool 9002007 to bend all four retaining lugs back on the edge of the clutch housing. Remove the thrust plate with Belleville springs to get at the friction disks, drive plates and hub for inspection and service.

  • Page 93: Tarp Troubleshooting Inspection & Maintenance

    — Maintenance Killbros 1135 Tarp Troubleshooting Inspection & Maintenance PROBLEM SOLUTION TARP SAGS IN MIDDLE AREAS BOWS MAY BE BENT OR ADJUSTED TOO LOW MISSING OR LOOSE RIDGE STRAP REPLACE OR RETIGHTEN TENSION MAY BE TOO LOOSE. U-JOINT MAY NEED TO BE ADJUSTED ON SPLINED SHAFT...
  • Page 94 — Maintenance Killbros 1135 Electrical System Diagram — Overall Right-Hand To Right-Side of Side Cart Interior Tail Light RH Sub Assembly #280848B Work Light #9008957 Red Tail/Turn Light #9006282 Rear Wiring Harness #9003050 To Tractor Front Wiring Harness #9007460 Plug #92450...
  • Page 95 — Maintenance Killbros 1135 Electrical System Diagram — Plug #92450 GRAIN CART WIRES White -- Ground Green -- Right amber flashing lamp Yellow -- Left amber flashing lamp Brown -- Tail light Black -- Interior & Auger Lights Red -- Brake Lights...
  • Page 96 — Maintenance Killbros 1135 Electrical Diagram — Front Wiring Harness #9007460 4-36...
  • Page 97 — Maintenance Killbros 1135 Electrical Diagram — Rear Wiring Harness #9003050 4-37...
  • Page 98 — Maintenance Killbros 1135 Electrical Diagram — Auger Wiring Harness #9009080 - For SN B41380100 & Higher #9007461 - For SN B41380099 & Lower 4-38...
  • Page 99 — Maintenance Killbros 1135 Electrical Diagram — Proximity Sensor #9007472 Electrical Diagram — Work Light #9008957 For SN B41380100 & Higher 2 PIN INTEGRATED DEUTSCH CONNECTOR POWER (PIN #1) GROUND (PIN #2) Electrical Diagram — Work Light #9007186 For SN B41380099 & Lower...
  • Page 100 — Maintenance Killbros 1135 Electrical Diagram — Red Tail/Turn Light #9006282 Electrical Diagram — Amber Lamp Double Face #9005142 4-40...

  • Page 101: Hydraulic System Diagram

    — Maintenance Killbros 1135 Hydraulic System Diagram 4-41...

  • Page 102: Wheels And Tires

    — Maintenance Killbros 1135 Wheels and Tires Wheel Nut Torque Requirements • IMPROPERLY TORQUED WHEEL NUTS/BOLTS CAN CAUSE A LOSS OF IMPLEMENT CONTROL AND MACHINE DAMAGE. TORQUE WHEEL NUTS/BOLTS TO VALUES IN TABLE. CHECK TORQUE BEFORE USE, AFTER ONE HOUR OF UNLOADED USE OR AFTER FIRST LOAD, AND EACH LOAD UNTIL WHEEL NUTS/BOLTS MAINTAIN TORQUE VALUE.

  • Page 103: Tire Pressure

    — Maintenance Killbros 1135 Wheels and Tires (continued) Tire Pressure The following is to be used as a general guide for tire inflation and figures can vary depend- ing on specific brand of tire used. It is important that tires are inspected after unit is loaded.
  • Page 104 — Maintenance Killbros 1135 Wheels and Tires (continued) Tire Pressure (continued) Tire Pressure for Grain Carts Load Index / Ply Max. PSI Tire Make Part Number Tire Size Rating Titan/Goodyear 94286 23.1x26 R-3 99364 23.1x26 R-1 99307 24.5R32 R-1 169A8/B (5-Star) 94289 24.5x32 R-3...

  • Page 105: Tire Warranty

    — Maintenance Killbros 1135 Wheels and Tires (continued) Tire Warranty For questions regarding new tire warranty, please contact your local original equipment tire dealer. USED TIRES CARRY NO WARRANTY. Following are phone numbers and Websites for your convenience: Firestone www.firestoneag.com...

  • Page 106: Complete Torque Chart - Hardware

    — Maintenance Killbros 1135 Complete Torque Chart Capscrews - Grade 5 NOTE: • Grade 5 capscrews can be identified by three radial dashes on the head. • For wheel torque requirements, refer to Wheels and Tires. • Tighten U-bolts evenly and equally to have the same number of threads exposed on each end.
  • Page 107 — Maintenance Killbros 1135 Complete Torque Chart Capscrews - Grade 8 NOTE: • Grade 8 capscrews can be identified by six radial dashes on the head. • For wheel torque requirements, refer to Wheels and Tires. • Tighten U-bolts evenly and equally to have the same number of threads exposed on each end.

  • Page 108: Hydraulic Fittings

    — Maintenance Killbros 1135 Hydraulic Fittings – Torque and Installation SAE Flare Connection (J. I. C.) 1. Tighten nut with finger until it bottoms the seat. 2. Using a wrench, rotate nut to tighten. Turn nut 1/3 turn to apply proper torque.

  • Page 109: For Track Information, Please Refer To Your Track Manual

    — Parts Killbros 1135 Section V Parts Touch-Up Paint........................... 5-2 Final Assembly ........................... 5-2 Rigid Axle........................... 5-4 Adjustable Axle........................... 5-6 Track Axle Components with 5 Point Scale System ..............5-8 Hub Components........................5-10 Wheels & Tires ........................5-12 Decals ............................5-14 Sideboards..........................

  • Page 110: Touch-Up Paint

    — Parts Killbros 1135 Touch-Up Paint Please visit www.unverferth.com/parts/ for the most current parts listing. PAINT SPRAY Black 97013 Green 97015 97301 Primer, Gray 9500082 Off White 97016 Final Assembly...
  • Page 111 — Parts Killbros 1135 Final Assembly Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Bracket, Window Retainer 250461B Ladder Weldment 280600B Ladder Bracket Weldment 280603B Wearshoe - Hitch, CAT 3 281663 Wearshoe - Hitch, CAT 4 281898 Tension Bushing 2 OD x 1.516 ID x 2...

  • Page 112: Rigid Axle

    — Parts Killbros 1135 Rigid Axle Please visit www.unverferth.com/parts/ for the most current parts listing.
  • Page 113 — Parts Killbros 1135 Rigid Axle Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Axle Bundle 134”, Scale =Green= 287976G Includes Items 1, 2A, 3-9 Axle Bundle 134”, Scale =Red= 287976R Axle Bundle 134”, Non-Scale =Green=...

  • Page 114: Adjustable Axle

    — Parts Killbros 1135 Adjustable Axle Please visit www.unverferth.com/parts/ for the most current parts listing. 1A 1B Assemble Scale Load Cell With “TOP” Decal On The Bottom...
  • Page 115 — Parts Killbros 1135 Adjustable Axle Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Adjustable Axle Bundle, Scale =Green= 280489G Includes Items 1-7, 8A, 9-20 Adjustable Axle Bundle, Scale =Red= 280489R Adjustable Axle Bundle, Non-Scale =Green=...

  • Page 116: Track Axle Components With 5 Point Scale System

    — Parts Killbros 1135 Track Axle Components with 5 Point Scale System Please visit www.unverferth.com/parts/ for the most current parts listing. Assemble Scale Load Cell With “TOP” Decal On The Bottom...
  • Page 117 — Parts Killbros 1135 Track Axle Components with 5 Point Scale System Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Track Axle Bundle, Scale =Green= 287906G Track Axle Bundle, Scale =Red= 287906R Track Axle Bundle, Non-Scale =Green=...

  • Page 118: Hub Components

    — Parts Killbros 1135 Hub Components Please visit www.unverferth.com/parts/ for the most current parts listing. 5-10...
  • Page 119 — Parts Killbros 1135 Hub Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Hub & Digi-Star Scale Spindle Kit =Green= 267280G Hub & Digi-Star Scale Spindle Kit =Red= 267280R Hub & Non-Scale Spindle Kit =Green= 267284G Hub &...

  • Page 120: Wheels & Tires

    — Parts Killbros 1135 Wheels & Tires Please visit www.unverferth.com/parts/ for the most current parts listing. TIRES For questions regarding new tire warranty, please contact your local original equipment tire dealer. Used tires carry no warranty. • V e r i f y w h e t h e r y o u...
  • Page 121 — Parts Killbros 1135 Wheels & Tires Please visit www.unverferth.com/parts/ for the most current parts listing. STRAIGHT PLATE WHEELS ITEM DESCRIPTION PART NO. NOTES Wheel & Tire Assembly - Diamond Tread\ 17939WO/9500946 30 x 32 / 900/65R32 R-3 Includes Items 2, 7 & 8 Wheel &...

  • Page 122: Decals

    — Parts Killbros 1135 Decals Please visit www.unverferth.com/parts/ for the most current parts listing. Always consult your operator’s manual for correct tire pressure and wheel hardware torque specifications. 94754 5-14...
  • Page 123 — Parts Killbros 1135 Decals Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Decal, Auger Indicator 9005335 Decal, Profile Cart 9004288 Decal, Reflective Checker Tape 265384 Decal, DANGER (Driveshaft Entanglement) 95046 Decal, WARNING (Read & Understand)

  • Page 124: Sideboards

    — Parts Killbros 1135 Sideboards Please visit www.unverferth.com/parts/ for the most current parts listing. 5-16...
  • Page 125 — Parts Killbros 1135 Sideboards Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Angle Tube Brace 220032B Board Tube Brace 287524B Tube Brace 155" Long 287586B Board Weldment-Front, LH 287759W Board Weldment-Rear, LH 287761W...

  • Page 126: Electrical

    — Parts Killbros 1135 Electrical Please visit www.unverferth.com/parts/ for the most current parts listing. 5-18...
  • Page 127 — Parts Killbros 1135 Electrical Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NUMBER DESCRIPTION NOTES 280847B Tail Light Subassembly, Left-Hand 280848B Tail Light Subassembly, Right-Hand 251407B Light Bracket 251406B Light Bracket 251155B Light Bracket Weldment Kit, Left-Hand...

  • Page 128: Drive Components

    — Parts Killbros 1135 " 2 " 1 " 2 " 2 Drive Components Please visit www.unverferth.com/parts/ for the most current parts listing. To Tractor Check/Fill Plug 5-17 5-20...
  • Page 129 — Parts Killbros 1135 Drive Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Includes Items: 1 - 5, 12, 13, & 9008676 One Piece Driveshaft Replacement Kit 289761 Lock Collar 1 1/2 Flangette Bearing...

  • Page 130: Auger Components

    — Parts Killbros 1135 Auger Components Please visit www.unverferth.com/parts/ for the most current parts listing. 5-22...
  • Page 131 — Parts Killbros 1135 Auger Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Upper Auger Replacement Kit =Black= 281262 Includes Items 2, 3, 4, 5, 6 Soft-Start Kit 281682 Includes Items 3, 4, 5, 6...
  • Page 132 — Parts Killbros 1135 Auger Components (continued) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Grease Zerk 1/8 NPT 93426 Capscrew 5/16-18UNC x 2 1/2 9390-036 Grade 5 Capscrew 3/8-16UNC x 1 1/2 9390-057...

  • Page 133: Auger Fold Indicator

    — Parts Killbros 1135 Auger Fold Indicator Please visit www.unverferth.com/parts/ for the most current parts listing. Behind Front Panel ITEM DESCRIPTION PART NO. QTY. NOTES Auger Indicator Weldment 280168B Decal, Auger Indicator 9005335 Decal, Cart Profile 9004288 Indicator Retainer Weldment 268671B Cable, Push/Pull 180"...

  • Page 134: Cleanout Door Assembly

    — Parts Killbros 1135 Cleanout Door Assembly Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Door Wheel Weldment 220060B Door Weldment 281015B Roller, Plastic 222118 Plate, Back Door Lift 281059B Plate, Front Door Lift 281060B Shaft &...

  • Page 135: Flow Door Seals

    — Parts Killbros 1135 Flow Door Seals Please visit www.unverferth.com/parts/ for the most current parts listing. Cx7/8 G5 Cx1 3/4 G5 Cx1 3/4 G5 ITEM DESCRIPTION PART NO. QTY. NOTES Capscrew, 1/4-20UNC x 7/8 G5 9390-004 Capscrew, 3/8-16UNC x 1 3/4 G5...

  • Page 136: Hydraulics

    — Parts Killbros 1135 Hydraulics Please visit www.unverferth.com/parts/ for the most current parts listing. 5-28...
  • Page 137 — Parts Killbros 1135 Hydraulics Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Cylinder, 3 x 22 (3000 PSI) 9004730 Auger Fold Seal Kit 9003772 90° Elbow (9/16-18 JIC Female x 9/16-18 JIC Male)

  • Page 138: Directional Spout - For Sn B37230100 & Higher

    — Parts Killbros 1135 Directional Spout Components - For SN B37230100 & Higher Please visit www.unverferth.com/parts/ for the most current parts listing. SEAM LOCATION Beginning with Serial Number B37230100 SEAM LOCATION APPLY ADHESIVE TO SEAL GRIP TO SECURELY FASTEN SEAL TO SPOUT...
  • Page 139 — Parts Killbros 1135 Directional Spout Components - For SN B37230100 & Higher Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION QTY. NOTES 2007601B Link Weldment =Black= 268282 Pad - Wear Ring 268972B Hood Shim 1 1/2” x 10”...
  • Page 140 — Parts Killbros 1135 Directional Spout Components - For SN B37230099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. Prior To Serial Number B37230100 5-32...
  • Page 141 — Parts Killbros 1135 Directional Spout Components - For SN B37230099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION QTY. NOTES 287842B Directional Downspout Kit 94981 Locknut, 1/2-13UNC 9405-088 Flat Washer, 1/2 9004494...

  • Page 142: Pto Assembly Shearbolt Clutch - For Sn B41380100 & Higher

    — Parts Killbros 1135 PTO Assembly Shearbolt Clutch - For SN B41380100 & Higher Please visit www.unverferth.com/parts/ for the most current parts listing. 1 3/4-20 Spline Shown 5-34...
  • Page 143 — Parts Killbros 1135 PTO Assembly Shearbolt Clutch - For SN B41380100 & Higher Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES 1 3/4”-20 Spline PTO Assembly Complete 9008526 Includes Front and Rear Half Assemblies (Benzi America PTO) 1 3/8”-21 Spline (Optional)

  • Page 144: Pto Assembly Shearbolt Clutch - For Sn B41380099 & Lower

    — Parts Killbros 1135 PTO Assembly Shearbolt Clutch - For SN B41380099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. 1 3/4-20 Spline Shown Optional 1 3/8-21 Spline Shown 5-36...
  • Page 145 — Parts Killbros 1135 PTO Assembly Shearbolt Clutch - For SN B41380099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES 1 3/4-20 Spline PTO Assembly Complete 9004767 (GKN Walterscheid PTO) 1 3/8-21 Spline (Optional)

  • Page 146: Pto Assembly Friction Clutch - For Sn B41380100 & Higher

    — Parts Killbros 1135 PTO Assembly Friction Clutch - For SN B41380100 & Higher Please visit www.unverferth.com/parts/ for the most current parts listing. 1 3/4-20 Spline Shown 5-38...
  • Page 147 — Parts Killbros 1135 PTO Assembly Friction Clutch - For SN B41380100 & Higher Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES 1 3/4”-20 Spline PTO Assembly Complete 9009258 Includes Front and Rear Half Assemblies (Benzi America PTO) 1 3/8”-21 Spline...

  • Page 148: Pto Assembly Friction Clutch - For Sn B41380099 & Lower

    — Parts Killbros 1135 PTO Assembly Friction Clutch - For SN B41380099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. 1 3/4-20 Spline Shown Optional 1 3/8-21 Spline Shown 5-40...
  • Page 149 — Parts Killbros 1135 PTO Assembly Friction Clutch - For SN B41380099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES 1 3/4-20 Spline PTO Assembly Complete 9004769 (GKN Walterscheid PTO) 1 3/8-21 Spline (Optional)

  • Page 150: Friction Clutch Assembly - For Sn B41380100 & Higher

    — Parts Killbros 1135 Friction Clutch Assembly - For SN B41380100 & Higher Please visit www.unverferth.com/parts/ for the most current parts listing. NOTE: Clutch Assembly (9009256) must be used with the Complete PTO Assembly (9009258) or (9009257 - optional). NOTE: The clutch is preset at the factory and should not require adjustment.

  • Page 151: Friction Clutch Assembly - For Sn B41380099 & Lower

    1 for specific clutch information. — Parts Killbros 1135 Friction Clutch Assembly - For SN B41380099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. NOTE: Clutch Assembly (9004275) must be used with the Complete PTO Assembly (9004769) or (9004768 - optional).

  • Page 152: Shear-Bolt Clutch Assembly - For Sn B41380100 & Higher

    — Parts Killbros 1135 Shear-Bolt Clutch - For SN B41380100 & Higher Please visit www.unverferth.com/parts/ for the most current parts listing. NOTE: Clutch Assembly (9009034) must be used with the Complete PTO Assembly (9008526) or (9009253 - optional). • USE GENUINE OEM REPLACEMENT PART. Incorrect part may cause shear function to occur too soon causing inconvenience or too late resulting in damage to driveline and auger com- ponents.

  • Page 153: Shear-Bolt Clutch Assembly - For Sn B41380099 & Lower

    — Parts Killbros 1135 Shear-Bolt Clutch - For SN B41380099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. • USE GENUINE OEM REPLACEMENT PART. Incorrect part may cause shear function to oc- cur too soon causing inconvenience or too late resulting in damage to driveline and auger components.

  • Page 154: 45 Degree Gearbox

    — Parts Killbros 1135 45 Degree Gearbox Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Gearbox, Complete 9002812 Includes Items 1 thru 17 Shaft, Input 9001131 1.8:1 Gear Shaft, Output 9001132 1.8:1 Gear...

  • Page 155: Driveline U-Joint Assembly

    — Parts Killbros 1135 Driveline U-Joint Assembly Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Complete U-Joint Assembly 95012 Yoke 95010 Grease Zerk, 1/4-28 UNF 91160 Yoke, 1-3/8-6 Spline 95011 Quick Disconnect Pin Kit 92362 Cross &...

  • Page 156: Weather Guard Tarp

    — Parts Killbros 1135 Weather Guard Tarp Please visit www.unverferth.com/parts/ for the most current parts listing. 5-48...
  • Page 157 — Parts Killbros 1135 Weather Guard Tarp Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 287908B Tarp Kit with Arched End Caps 283425B Tarp Bow Bracket =Black= 283427B Tarp Bow Bracket =Black= 287400B Tarp Bow Tube =Black=...
  • Page 158 — Parts Killbros 1135 Weather Guard Tarp (continued) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 9390-099 Capscrew 1/2-13UNC x 1 (Grade 5) 265743B Crank Holder - Channel Extension =Black= 221700B Offset Bracket =Black=...
  • Page 159 — Parts Killbros 1135 Notes 5-51...

  • Page 160: Video System (Optional)

    — Parts Killbros 1135 Video System (Optional) Please visit www.unverferth.com/parts/ for the most current parts listing. 5-52...
  • Page 161 — Parts Killbros 1135 Video System (Optional) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 265770 Video System Kit for Front View Includes Items 1,3,4,5,6,7,8 9004506 Additional Camera for Rear View Includes Items 6 & 7...
  • Page 162 MANUALS\\287969///May 2017-0//May 2018-1//May 2019-2//September 2019-3//April 2020-4//July 2021-5//January 2022-6...

Table of Contents
