Unverferth Killbros 1150 Manual

Grain carts
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Grain Carts
Model 1150 & 1160
Model 1150 Beginning With Serial Number D10000000 & UP
Model 1160 Beginning With Serial Number D10000000 & UP
Part No. 252318

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Killbros 1150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unverferth Killbros 1150

Summary of Contents for Unverferth Killbros 1150

  • Page 1 Grain Carts Model 1150 & 1160 Model 1150 Beginning With Serial Number D10000000 & UP Model 1160 Beginning With Serial Number D10000000 & UP Part No. 252318...
  • Page 2 The information, specifications, and illustrations in the manual are on the basis of informa- tion available at the time it was written. Due to continuing improvements in the design and manufacture of Unverferth products, all specifications and information contained herein are subject to change without notice.
  • Page 3 Please fill out and retain this portion for your records. All products manufactured by Unverferth Mfg. Co., Inc. are warranted to be free from material and workmanship defects for one full year from time of consumer delivery. Your local dealer will gladly assist you with any warranty questions.

  • Page 4: Table Of Contents

    GRAIN CARTS — Introduction Table of Contents SECTION I Safety General Hazard Information ....................... 1-2 Safety Decals ..........................1-3 Follow Safety Instructions ......................1-4 Before Servicing ......................... 1-4 Before Operating ........................1-4 During Operation ........................1-5 Before Transporting ........................1-5 During Transport .........................
  • Page 5 GRAIN CARTS — Introduction Table of Contents SECTION II Set Up Set Up Checklist ........................2-2 Basic Cart Set Up Folding Side Extension Set Up ................... 2-3 Ladder ..........................2-3 Jack ............................. 2-3 Standard Chute Installation ....................2-3 Optional Extension Chute Installation .................. 2-4 Driveline Storage .........................
  • Page 6 GRAIN CARTS — Introduction Table of Contents SECTION III Operation Preparing Tractor ........................3-2 Preparing Cart Inspection ..........................3-3 Lubrication ........................... 3-3 Hitching To Tractor Drawbar Connection ......................3-4 Jack ............................. 3-4 Hydraulic Connections ......................3-5 Electrical Connections ......................3-6 Towing ............................
  • Page 7 GRAIN CARTS — Introduction Table of Contents SECTION IV Maintenance Lubrication ..........................4-2 Gearbox Lubrication ........................4-3 Seasonal Storage ........................4-3 Hydraulic System ........................4-4 Purge Hydraulic System ...................... 4-4 Relieving Hydraulic Pressure ....................4-5 Verify Telescoping PTO Shaft Length ..................4-6 Auger Driveline Bearings ..........................
  • Page 8 GRAIN CARTS — Introduction Table of Contents SECTION V Parts Final Assembly ........................... 5-2 Hitch ............................5-4 Axle ............................5-5 Hub - Model 1150 ........................5-6 Hub - Model 1160 ........................5-7 Wheels & Tires - Model 1150 ....................5-8 Wheels &...
  • Page 9 — Safety GRAIN CARTS SECTION I Safety General Hazard Information ....................... 1-2 Safety Decals ..........................1-3 Follow Safety Instructions ......................1-4 Before Servicing ......................... 1-4 Before Operating ........................1-4 During Operation ........................1-5 Before Transporting ........................1-5 During Transport ......................... 1-5 Driveline Safety ..........................

  • Page 10: Safety

    It is said that, “the best kind of a safety device is a careful operator.” We, at Unverferth Mfg. Co., Inc. ask that you be that kind of operator.

  • Page 11: Safety Decals

    — Safety GRAIN CARTS Safety Decals • REPLACE LOST, DAMAGED, PAINTED, OR UNREADABLE DECALS IMMEDIATELY. PARTS THAT HAVE DECALS ARE REPLACED, ALSO MAKE SURE TO INSTALL NEW DECALS. THESE DECALS INFORM AND REMIND THE OPERATOR WITH OPERATIONAL INFORMATION AND SAFETY MESSAGES. Part No.

  • Page 12: Follow Safety Instructions

    — Safety GRAIN CARTS Follow Safety Instructions • Read and understand this operator’s manual before operating. • All machinery should be operated only by trained and authorized personnel. • To prevent machine damage, use only attachments approved by the manufacturer. •...

  • Page 13: During Operation

    — Safety GRAIN CARTS During Operation • Regulate speed to field conditions. Maintain complete control at all times. • Never service or lubricate cart when in operation. • Keep away from overhead power lines. Electrical shock can cause serious injury or death.

  • Page 14: Driveline Safety

    — Safety GRAIN CARTS Driveline Safety • Do not allow children near equipment that is running or engaged. • Do not exceed 1000 RPM PTO speed. • Disengage the PTO, stop the tractor engine, and remove the key from the ignition before making inspections, or performing maintenance and repairs.

  • Page 15: Pressurized Oil

    — Safety GRAIN CARTS Pressurized Oil • Relieve pressure before disconnecting hydraulic lines from tractor, loosening any hydraulic fittings or servicing hydraulic system. See hydraulic power unit manual for procedure to relieve pressure. • High-pressure fluids can penetrate the skin and cause serious injury or death. Use cardboard or wood to detect leaks in the hydraulic system.

  • Page 16: Preparing For Emergencies

    — Safety GRAIN CARTS Preparing for Emergencies • Keep a first aid kit and properly rated fire extinguisher nearby. • Keep emergency numbers for fire, rescue, and poison control personnel near the phone. Wearing Protective Equipment • Wear clothing and personal protective equipment appropriate for the job. •...
  • Page 17 — Set Up GRAIN CARTS SECTION II Set Up Set Up Checklist ........................2-2 Basic Cart Set Up Folding Side Extension Set Up ................... 2-3 Ladder ..........................2-3 Jack ............................. 2-3 Standard Chute Installation ....................2-3 Optional Extension Chute Installation .................. 2-4 Driveline Storage .........................

  • Page 18: Set Up Checklist

    — Set Up GRAIN CARTS Set Up Checklist After the cart has been completely assembled, use the following checklist and inspect the cart. Check off each item as it is found satisfactory or after proper adjustment is made. o Check that wheels are properly installed and torque wheel nuts as specified in MAINTENANCE section.

  • Page 19: Folding Side Extension Set Up

    — Set Up GRAIN CARTS Basic Cart Set Up (Continued) Folding Side Extension Hardware is stored behind right axle standard of grain cart. 1. Rotate extensions up into position and secure at corner holes. 2. Attach center support hardware. 3. Tighten all hardware, including hinge bolts. Ladder Set ladder over mounting lugs and secure to front panel of cart.

  • Page 20: Optional Extension Chute Installation

    — Set Up GRAIN CARTS Basic Cart Set Up (Continued) Optional Extension Chute Installation 1. Remove existing chute. 2. Fold overlap and snap four end snaps. 3. Slide chute over auger tube outlet shroud with overlap towards hitch. 4. Install top and bottom strips over chute and fasten with existing capscrews, flatwashers and locknuts.

  • Page 21: Wheel/Tire Set Up

    — Set Up GRAIN CARTS Basic Cart Set Up (Continued) Wheel/Tire Set Up Tire Pressure Tire pressure must be verified before first use and adjusted as necessary. Refer to maintenance section of this manual for information on tire pressure. Wheel Nuts •...
  • Page 22 — Set Up GRAIN CARTS Notes...
  • Page 23 — Operation GRAIN CARTS SECTION III Operation Preparing Tractor ........................3-2 Preparing Cart Inspection ..........................3-3 Lubrication ........................... 3-3 Hitching To Tractor Drawbar Connection ......................3-4 Jack ............................. 3-4 Hydraulic Connections ......................3-5 Electrical Connections ......................3-6 Towing ............................3-8 Auger Operation .........................

  • Page 24: Preparing Tractor

    — Operation GRAIN CARTS Operating Checklist  Read and understand all safety precautions before operating cart.  Check axle spacing to be sure axle is adjusted from shipping position to desired operating width. (If Applicable)  Check to be sure all the reflective decals and the SMV sign are clearly visible with the cart attached to the tractor.

  • Page 25: Preparing Cart Inspection

    — Operation GRAIN CARTS Preparing Cart Inspection Perform the service checks as outlined below. Repair or replace any damaged or worn parts before operating. Hardware: Check for loose bolts and nuts, and tighten as needed. Check again after the first half-day of operation. Pivot Pins: Check that all pins are in place and in good condition.

  • Page 26: Hitching To Tractor Drawbar Connection

    — Operation GRAIN CARTS Hitching To Tractor Drawbar Connection This cart is intended to be hitched to a tractor drawbar. Do not attempt to hitch to any other location on the tractor other than the drawbar. The cart may be equipped standard with a single-tang hitch which utilizes a 1 1/2 inch diameter drawbar pin and must only be used with a clevis-type tractor drawbar.

  • Page 27: Hydraulic Connections

    — Operation GRAIN CARTS Hitching To Tractor (Continued) Always use intermediate chain support when connecting grain cart directly to a tractor. DO NOT use the intermediate chain support as the chain attaching point. Fig. 6 shows how the transport chain must be installed between tractor and grain cart.

  • Page 28: Electrical Connections

    This cart is equipped with a seven-pin SAE connector plug which will connect with the receptacle found on most newer tractors. If your tractor does not have this type of receptacle, an SAE J-560 seven-point socket can be purchased from your Unverferth dealer (Part number 92824).
  • Page 29 — Operation GRAIN CARTS Hitching To Tractor (Continued) GRAIN CART WIRES White -- Ground Green -- Right amber flashing lamp Yellow -- Left amber flashing lamp Brown -- Tail light Blue -- Auger Light...

  • Page 30: Towing

    — Operation GRAIN CARTS Towing This cart is not equipped with brakes. Ensure that the towing vehicle has adequate weight and braking capacity to tow this implement. Never tow a loaded grain cart over public roads. Do not exceed 10 mph during off-highway travel. Do not exceed 8 mph when cart is fully loaded.

  • Page 31: Pto-Driven Auger

    — Operation GRAIN CARTS Auger Operation (continued) PTO Driven Auger • ELECTROCUTION WILL CAUSE SERIOUS INJURY OR DEATH. THE GRAIN CART IS NOT INSULATED. KEEP AWAY FROM ALL ELECTRI- CAL LINES AND DEVICES. ELECTROCUTION CAN OCCUR WITHOUT DIRECT CONTACT. • ENTANGLEMENT WITH THE DRIVELINE WILL CAUSE SERIOUS INJURY OR DEATH.
  • Page 32 — Operation GRAIN CARTS Notes 3-10...
  • Page 33 — Maintenance GRAIN CARTS SECTION IV Maintenance Lubrication ..........................4-2 Gearbox Lubrication ........................4-3 Seasonal Storage ........................4-3 Hydraulic System ........................4-4 Purge Hydraulic System ...................... 4-4 Relieving Hydraulic Pressure ....................4-5 Verify Telescoping PTO Shaft Length ..................4-6 Auger Driveline Bearings ..........................

  • Page 34: Lubrication

    — Maintenance GRAIN CARTS Lubrication To keep your grain cart in top operating condition and to assure its proper performance and reliability for a long period of time, a periodic inspection and lubrication is a must. 252922 250950...

  • Page 35: Gearbox Lubrication

    — Maintenance GRAIN CARTS Gearbox Lubrication Gearbox check/fill plug is located on the right hand front side of the housing. To check oil fluid level, place cart on a level surface with the tongue elevated to hitch height and remove the plug.

  • Page 36: Hydraulic System

    When properly assembled and maintained, the hydraulic system of the grain cart requires little maintenance. Replacing Hoses/Fittings/Cylinders: 1. Use replacement hoses, fittings, and cylinders from your Unverferth Manufacturing dealer which are rated for 3000 psi. 2. Do not use hoses, fittings and cylinders that have pipe threads.

  • Page 37: Relieving Hydraulic Pressure

    — Maintenance GRAIN CARTS Hydraulic System (continued) Relieving Hydraulic Pressure To relieve hydraulic pressure in the system, be sure hydraulic motor is disengaged and/or hydraulic cylinder is not exerting force on the system. Next, turn off engine and actuate valve in hydraulic system to all positions of actuation and to the neutral position.

  • Page 38: Verify Telescoping Pto Shaft Length

    — Maintenance GRAIN CARTS Verify Telescoping PTO Shaft Length • PROPER EXTENDED AND COLLAPSED LENGTHS OF THE TELESCOPING PTO SHAFT MUST BE VERIFIED BEFORE FIRST OPERATION. IF THE EXTENDED LENGTH OF THE PTO SHAFT IS NOT SUFFICIENT, IT MAY BECOME UNCOUPLED IN OPERATION AND CAUSE SERIOUS INJURY OR DEATH FROM CONTACT WITH UNCONTROLLED FLAIL- ING OF PTO SHAFT ASSEMBLY COMPONENTS.
  • Page 39 — Maintenance GRAIN CARTS Verify Telescoping PTO Shaft Length (Continued) 6. Position the tractor to obtain the tightest turning angle, relative to the cart (Fig. 3). 7. Measure the length “L” from the same points as used in step 1. This distance must be at least 1.5 inches greater than the distance measured in step 1.

  • Page 40: Auger Driveline

    — Maintenance GRAIN CARTS Auger Driveline Bearings It is important to periodically check setscrews in all bearings of the driveline for tightness. Driveline Replacement Flangette Bearings FIG. 4-1 1. Park the empty cart on a firm, level surface. Block the wheels or tracks on the cart to keep it from moving.
  • Page 41 — Maintenance GRAIN CARTS Auger Driveline (continued) Driveline Replacement (continued) 6. Remove bearings, bearing mounts, universal joint cover, PVC driveshaft covers, and driveline cover, located behind the ladder, off the current driveshaft. 7. When installing new bearings (9003920) onto new driveshaft (9007718), assemble new 25” PVC driveshaft cover (291555) between bearings near the gearbox, and new 36”...
  • Page 42 — Maintenance GRAIN CARTS Auger Driveline (continued) Driveline Replacement (continued) 11. Tighten all flangette mounting hardware. Universal Joint Drill Dimple 12. With bearing mounting hardware loosely In-Line Orientation on Driveshaft tightened, drill a setscrew dimple in the driveshaft by going through the bearing setscrew threaded hole to dimple the driveshaft being careful to not damage threads.

  • Page 43: Gearbox

    — Maintenance GRAIN CARTS Auger Driveline (continued) Gearbox Fluid level plug is on the right side of gearbox. Fill plug is in front of the axle on the left side of gearbox (Standing behind the cart looking toward the tractor). For maximum gearbox life: Check oil level every 2 weeks.

  • Page 44: Pto Shaft & Clutch

    — Maintenance GRAIN CARTS PTO Shaft & Clutch Lubrication Lubricate with quality grease before starting work and every 8 operating hours. Clean and grease PTO drive shaft before each prolonged period of non-use. Molded nipples on the shield near each shield bearing are intended as grease fittings and should be lubricated every 8 hours of operation! Telescoping members must have lubrication to operate successfully regardless of whether a grease fitting is provided for that purpose!
  • Page 45 — Maintenance GRAIN CARTS PTO Shaft & Clutch (Continued) Dismantling Guard 1. Remove locking screw. 2. Align bearing tabs with cone pockets. 3. Remove half-guard. 4. Remove bearing ring. Assembling Guard 1. Grease yoke groove and inner profile tube. 2. Fit bearing ring in groove with recesses facing profile tube.
  • Page 46 — Maintenance GRAIN CARTS PTO Shaft & Clutch (Continued) Assembling Cone 1. Dismantle guard (Figs. J1 - J3). Remove old cone (e.g. cut open with knife). Take off chain. Place neck of new cone in hot water (approx 80°C/180°F) and pull onto bearing housing (Fig.

  • Page 47: Auger System

    — Maintenance GRAIN CARTS Auger System • FALLING OBJECTS CAN CAUSE SERIOUS INJURY OR DEATH. DO NOT WORK UNDER THE MACHINE AT ANY TIME WHILE BEING HOISTED. BE SURE ALL LIFTING DEVICES AND SUP- PORTS ARE RATED FOR THE LOADS BEING HOISTED. THESE ASSEMBLY INSTRUCTIONS WILL REQUIRE SAFE LIFTING DEVICES UP TO 1200 LBS.

  • Page 48: Upper Auger

    — Maintenance GRAIN CARTS Auger System (Continued) 5. Position height pin against top of drive bushing and weld to auger tube. NOTE: Height pin can be located adjacent to one of drive pins and both pins welded together in Step 6. 6.

  • Page 49: Upper Auger

    — Maintenance GRAIN CARTS Auger System (Continued) Upper Auger Assembly 1. Install the upper bearing and spring assembly if previously removed. 2. Using a safe lifting device rated for 500 lbs., insert auger in auger tube. Back out bearing setscrews and insert auger stub shaft through bearing.

  • Page 50: Wheel Torque Chart & Tire Specifications

    — Maintenance GRAIN CARTS Wheel Torque Chart & Tire Specifications Wheel Torque Requirements • IMPROPERLY TORQUED WHEEL NUTS/BOLTS CAN CAUSE A LOSS OF IMPLEMENT CONTROL AND MACHINE DAMAGE. TORQUE WHEEL NUTS/BOLTS TO VALUES IN TABLE. CHECK TORQUE BEFORE INITIAL USE, AFTER ONE HOUR OF UNLOADED USE OR AFTER FIRST LOAD, AND EACH LOAD UNTIL WHEEL NUTS/BOLTS MAINTAIN TORQUE VALUE.

  • Page 51: Tire Pressure

    — Maintenance GRAIN CARTS Wheel Torque Chart & Tire Specifications (Continued) Tire Pressure The following is to be used as a general guide for tire inflation and figures can vary depending on specific brand of tire used. It is important that tires are inspected after unit is loaded.
  • Page 52 — Maintenance GRAIN CARTS Wheel Torque Chart & Tire Specifications (Continued) Tire Pressure Tire Pressure for Grain Carts Load Index / Ply Max. PSI Tire Make Part Number Tire Size Rating Titan/Goodyear 94286 23.1x26 R-3 99364 23.1x26 R-1 99307 24.5R32 R-1 169A8/B (5-Star) 94289 24.5x32 R-3...

  • Page 53: Tire Warranty

    — Maintenance GRAIN CARTS Wheels and Tires (continued) Tire Warranty For questions regarding new tire warranty, please contact your local original equipment tire dealer. USED TIRES CARRY NO WARRANTY. Following are phone numbers and Websites for your convenience: Firestone www.firestoneag.com Phone 800-847-3364 Titan www.titan-intl.com...

  • Page 54: Torque Chart

    — Maintenance GRAIN CARTS Complete Torque Chart Capscrews - Grade 5 NOTE: • Grade 5 capscrews can be identified by three radial dashes on the head. • For wheel torque requirements, refer to Wheels and Tires. • Tighten U-bolts evenly and equally to have the same number of threads exposed on each end. FOOT NEWTON SIZE...

  • Page 55: Hydraulic Fittings

    — Maintenance GRAIN CARTS Hydraulic Fittings – Torque and Installation SAE Flare Connection (J. I. C.) 1. Tighten nut with finger until it bottoms the seat. 2. Using a wrench, rotate nut to tighten. Turn nut 1/3 turn to apply proper torque. SAE Straight Thread O-Ring Seal 1.
  • Page 56 — Maintenance GRAIN CARTS Notes 4-24...
  • Page 57 — Parts GRAIN CARTS SECTION V Parts Final Assembly ........................... 5-2 Hitch ............................5-4 Axle ............................5-5 Hub - Model 1150 ........................5-6 Hub - Model 1160 ........................5-7 Wheels & Tires - Model 1150 ....................5-8 Wheels & Tires - Model 1160 ....................5-9 Decals ............................

  • Page 58: Final Assembly

    — Parts GRAIN CARTS Final Assembly Please visit www.unverferth.com/parts/ for the most current parts listing.
  • Page 59 — Parts GRAIN CARTS Final Assembly Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Window 92403 Window Molding 250431 Bracket, Window Retaining 250461B Capscrew, 1/4”-20UNC x 3/4” 9390-003 Flat Washer, 1/4” 9405-064 Locknut, 1/4”-20UNC...

  • Page 60: Hitch

    — Parts GRAIN CARTS Hitch Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Remove from Scale Swivel Hitch Insert Bushing 7-0063 Hitch Setscrew, 1/2-13 UNC x 1 1/4 9399-111 Capscrew, 1/2-13 UNC x 1 1/4...

  • Page 61: Axle

    — Parts GRAIN CARTS Model 1150 Axle Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Axle Assembly - 120" =Green= 253176G-SER Axle Assembly - 120" =Red= 253176R-SER Includes Items 1-6 Axle Assembly - 144"...
  • Page 62 — Parts GRAIN CARTS Model 1150 Hub Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Hub Assembly, Complete =Green= 200036G Includes Items 1-6 & 10-13 Hub Assembly, Complete =Red= 200036R Seal 92456 Stud Bolt 3/4-16 UNF x 3...
  • Page 63 — Parts GRAIN CARTS Model 1160 Hub Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Hub Assembly, Complete =Green= 200079G Includes Items 1-6 & 10-13 Hub Assembly, Complete =Red= 200079R Seal 92565 Stud Bolt 3/4-16 UNF x 3...
  • Page 64 — Parts GRAIN CARTS Model 1150 Wheels & Tires Please visit www.unverferth.com/parts/ for the most current parts listing. TIRES For questions regarding new tire warranty, please contact your local original equipment tire dealer. Used tires carry no warranty. Tire manufacturers'...
  • Page 65 — Parts GRAIN CARTS Model 1160 Wheels & Tires Please visit www.unverferth.com/parts/ for the most current parts listing. TIRES For questions regarding new tire warranty, please contact your local original equipment tire dealer. Used tires carry no warranty. Tire manufacturers'...

  • Page 66: Decals

    — Parts GRAIN CARTS Decals Please visit www.unverferth.com/parts/ for the most current parts listing. Parts List ITEM 9004298 DECAL - 9004213 DECAL - 9004035 DECAL - 901267 DECAL-U 91605 DECAL F 97961 DECAL W 95046 DECAL D 9003475 DECAL -...
  • Page 67 — Parts GRAIN CARTS Decals Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES S/N D53710100 & Up (Model 1150) 9005266 S/N D53700100 & Up (Model 1160) Decal, Killbros S/N D53710099 & Prior (Model 1150) 104420 S/N D53700099 &...

  • Page 68: Sideboards

    — Parts GRAIN CARTS Sideboards Please visit www.unverferth.com/parts/ for the most current parts listing. 5-12...
  • Page 69 — Parts GRAIN CARTS Sideboards Please visit www.unverferth.com/parts/ for the most current parts listing. PART NO. ITEM DESCRIPTION QTY. NOTES 1150 1160 Front Board 253240W 253252W Model 1150 - 16" to 0" Model 1160 - 23" to 7" Hinge Front Board Kit*...

  • Page 70: Electrical

    — Parts GRAIN CARTS Electrical Please visit www.unverferth.com/parts/ for the most current parts listing. 5-14...
  • Page 71 — Parts GRAIN CARTS Electrical Please visit www.unverferth.com/parts/ for the most current parts listing. ITEMS DESCRIPTION PART NO. NOTES Wiring Harness, Rear 9003510 Wiring Harness, Front 9003509 Electrical Coupler 92450 Wiring Harness, Auger 9004350 LED Auger Light 9500807 Connector, Male 9004140 Connector 1/2”...

  • Page 72: Auger & Hydraulics

    — Parts GRAIN CARTS Auger & Hydraulics Please visit www.unverferth.com/parts/ for the most current parts listing. 252930 5-16...
  • Page 73 — Parts GRAIN CARTS Auger & Hydraulics Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Hydraulic Hose, 1/4 Dia. x 228 9002215 9/16-18JIC Male x 9/16-18 JIC Bulkhead Union 95192 Bulkhead Thrd w/Nut Hydraulic Hose, 1/4"...

  • Page 74: Upper Auger

    — Parts GRAIN CARTS Upper Auger 233904 ITEM DESCRIPTION PART NO. QTY. NOTES Upper Auger 253016B Upper Tube Housing =Green= 253113G Upper Tube Housing =Red= 253113R Flange Bearing, 1 1/2 4-Hole 92406 Washer 9001197 2x1.554x.134 Capscrew, 1/2-13 UNC x 5 1/2 9390-114 Flatwasher, 1/2 9405-094...

  • Page 75: Lower Auger & Driveline

    — Parts GRAIN CARTS Lower Auger & Driveline 233904A ITEM DESCRIPTION PART NO. QTY. NOTES Drive Dog/Missle Shaft (4 Tooth) 250424 Hanger Bushing Assembly 250119B Includes Item #4 Bushing, Bronze, 2" I.D. 95315 Zerk 90°, 1/4-28 9000875 Capscrew, 3/8-16 UNC x 1 1/4 9390-056 Lock Washer, 3/8 9404-021...

  • Page 76: Directional Downspout Control Kit #27122B (Optional)

    — Parts GRAIN CARTS Directional Downspout Control Kit #27122B (Optional) 5-20...
  • Page 77 — Parts GRAIN CARTS Directional Downspout Control Kit #27122B (Optional) ITEM PART NO. DESCRIPTION NOTES 27121B 14" Hydraulic Directional Spout =Black= 27092B 14" Hood Weldment =Black= 27095 Bar, 3/4D x 16 7/8 Lg. 27103B Chute Weldment =Black= 27105B Chute Weldment =Black= 27114 Arm Link Plate 27120...

  • Page 78: Auger Chutes

    — Parts GRAIN CARTS Auger Chutes 253906 ITEM DESCRIPTION PART NO. QTY. NOTES Includes Items 1 Chute Kit 253006 thru 4 Chute 9001437 Fender Washer, 2" OD 94763 Capscrew, 1/4-20 UNC x 1 9390-005 Locknut, 1/4-20 UNC 9936 Fender Washer, 1" OD 9405-066 Adjustable Extended Length Chute 252047...

  • Page 79: Auger Cylinder

    — Parts GRAIN CARTS Auger Cylinder 3” x 20” 802925 ITEM DESCRIPTION PART NO. NOTES Cylinder Complete 9003103 Seal Kit 9003772 Flow Control Cylinder 2 1/2” x 36” ITEM DESCRIPTION PART NO. NOTES Cylinder Complete 9005363 Seal Kit 9005409 5-23...

  • Page 80: Pto Assembly

    — Parts GRAIN CARTS PTO Assembly 233910 ITEM DESCRIPTION PART NO. QTY. NOTES PTO Shaft w/Shielding 95271 1 3/8-21 Spline PTO Shaft w/Shielding 9002662 1 3/4-20 Spline Front Half PTO 95269 1 3/8-21 Spline Front Half PTO 9002663 1 3/4-20 Spline Rear Half PTO 95270 1 1 /4 Rd 5/16 Kwy...

  • Page 81: Pto Clutch

    — Parts GRAIN CARTS PTO Clutch IMPORTANT! TORQUE TO 20 FT. LBS. 233911A ITEM DESCRIPTION PART NO. QTY. NOTES Complete Clutch 95254 Shear Yoke 95255 Locknut 95259 Ball 95257 Grease Zerk 95256 Bolt, M8 x 50 DIN 931 8.8 94916-040 See Note * Hub, 1 1/4 Rd w/5/16 Kwy 95258...

  • Page 82: Gearbox

    — Parts GRAIN CARTS 50° Gearbox TAB45504 ITEM DESCRIPTION PART NO. QTY. NOTES Gearbox, Complete TAB45504 Includes Items 1 thru 14 1.6:1 Ratio Cast Half W/Thru Holes 9003451 Cast Half W/Threaded Holes 9003450 Pinion Shaft (input) TAH2394 1 3/8 - 6 Spline Cross Shaft (Output) TAH2396 1 3/8 - 6 Spline...

  • Page 83: Driveline U-Joint Assembly

    — Parts GRAIN CARTS Driveline U-Joint Assembly 233912 ITEM DESCRIPTION PART NO. QTY. NOTES U-Joint Assembly, Complete 95253 Yoke, 1 3/8-6 Spline 95250 Cross & Bearing Kit 92364 Yoke, 1 1/4 Round with 5/l6 Keyway 95251 Grease Zerk 95252 Key, 5/16 x 2 95176 Set Screw 3/8-16UNC x 1/2 9399-086...
  • Page 84 L:\Pagemaker_OM_Files\OMShellRock\Cart\1150,1160\252318\\020411-6\\December 2013-8\\April 2014-9\\January 2015-10//April 2016-11//May 2019-12//MARCH 2020-13//JUNE 2021-14...
