Bulk Seed Handling
®
Seed Chariot
2-Box Tender
Model 1020
Part No. 2000827

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PARKER Seed Chariot 1020 and is the answer not in the manual?

Questions and answers

Related Manuals for Unverferth PARKER Seed Chariot 1020

Summary of Contents for Unverferth PARKER Seed Chariot 1020

  • Page 1 Bulk Seed Handling ® Seed Chariot 2-Box Tender Model 1020 Part No. 2000827...
  • Page 2 — Introduction Seed Chariot 1020 Foreword This symbol identifies important safety messages. When you see it, read the mes- sage that follows and be alert to the possibility of personal injury. Remember, safety instructions stated in this manual are for your protection. Read them carefully and follow them closely when working around or using this machine.
  • Page 3 — Introduction Seed Chariot 1020 Product Information All products manufactured by Unverferth Mfg. Co., Inc. are warranted to be free from ma- terial and workmanship defects for one full year from time of consumer delivery. Your local dealer will gladly assist you with any warranty questions.

  • Page 4: Table Of Contents

    — Introduction Seed Chariot 1020 Table of Contents Section I Safety General Hazard Information ......................1-2 Safety Decals ..........................1-3 Following Safety Instructions ......................1-4 Before Servicing ..........................1-4 Before Operating ..........................1-5 During Operation ..........................1-5 Before Transport ..........................1-6 During Transport ..........................
  • Page 5 — Introduction Seed Chariot 1020 Table of Contents Section IV Maintenance Lubrication - Conveyor and Auger Bearings .................. 4-2 Lubrication - Auger U-Joint ......................4-2 Lubrication - Pivot Points ....................... 4-3 Lubrication - Wheel Bearings ......................4-3 Lubrication - Engine Oil Level ....................... 4-3 Conveyor Belt - Belt Tension ......................
  • Page 6 — Introduction Seed Chariot 1020 Table of Contents Section V Parts Decals & Touch-Up Paint ......................5-2 Stationary Bracket Components ....................5-4 Scale Components........................5-6 Conveyor Drive Assembly & Hopper Components ..............5-8 Conveyor Idler End Components ....................5-12 Conveyor Discharge End Components ..................5-14 Auger Drive Assembly &...
  • Page 7 — Safety Seed Chariot 1020 Section I Safety General Hazard Information ......................1-2 Safety Decals ..........................1-3 Following Safety Instructions ......................1-4 Before Servicing ..........................1-4 Before Operating ..........................1-5 During Operation ..........................1-5 Before Transport ..........................1-6 During Transport ..........................1-6 Prepare for Emergencies ........................

  • Page 8: Safety

    It is true that the designer, the manufacturer, and the safety engineer can help; and they will help, but their combined efforts can be wiped out by a single careless act of the operator. It is said that, “the best kind of a safety device is a careful operator.” We, at Unverferth Mfg.

  • Page 9: Safety Decals

    — Safety Seed Chariot 1020 Safety Decals • REPLACE LOST, DAMAGED, PAINTED, OR UNREADABLE DECALS IMMEDIATELY. IF PARTS THAT HAVE DECALS ARE REPLACED, ALSO MAKE SURE TO INSTALL NEW DECALS. THESE DECALS INFORM AND REMIND THE OPERATOR WITH OPERATIONAL INFORMATION AND SAFETY MESSAGES. Part No.

  • Page 10: Following Safety Instructions

    — Safety Seed Chariot 1020 Following Safety Instructions • Read and understand this operator’s manual before operating. • All machinery should be operated only by trained and authorized personnel. • To prevent machine damage, use only attachments and service parts ap- proved by the manufacturer.

  • Page 11: Before Operating

    — Safety Seed Chariot 1020 Before Operating • Do not stand between the towing vehicle and implement during hitching. • Always make certain everyone and everything is clear of the machine before beginning operation. • Verify that all safety shields are in place and properly secured. •...

  • Page 12: Before Transport

    — Safety Seed Chariot 1020 Before Transporting • Secure transport chains to the towing vehicle before transporting. DO NOT transport without chains. • Install transport locks before transporting. • Check for proper functioning of all available transport lights. Make sure that all reflectors are clean and in place on machine.

  • Page 13: Prepare For Emergencies

    — Safety Seed Chariot 1020 Preparing for Emergencies • Keep a first aid kit and properly rated fire extinguisher nearby. • Keep emergency numbers for fire, rescue, and poison control personnel near the phone. Wearing Protective Equipment • Wear clothing and personal protective equipment appropriate for the job. •...
  • Page 14 — Safety Seed Chariot 1020 Notes...

  • Page 15: Set Up

    — Set Up Seed Chariot 1020 Section II Set Up Pre-Delivery Checklist ........................2-2 Seed Chariot Assembly ........................2-3 Assemble Hitch to Undercarriage ....................2-3 Raising Conveyor/Auger to Working Position .................. 2-4 Optional Scale Package (#2000621) ....................2-5 Optional Electric Raise/Lower for Conveyor ................... 2-7 Optional AG Decal Package, Decal Placement ................

  • Page 16: Pre-Delivery Checklist

    — Set Up Seed Chariot 1020 Pre-Delivery Checklist After the Seed Chariot tender has been completely assembled, use the following checklist and inspect the implement. Check off each item as it is found satisfactory or after proper adjustment is made. o Torque wheel nuts as specified in Maintenance section.

  • Page 17: Assemble Hitch To Undercarriage

    — Set Up Seed Chariot 1020 Assemble Hitch to Undercarriage 1. If the seed tender was shipped with a hitch installed, torque 5/8”-11UNC retaining hard- ware to 120-135 ft.-lbs. If it was shipped without a hitch installed, proceed to step 2. 2.

  • Page 18: Raising Conveyor/Auger To Working Position

    — Set Up Seed Chariot 1020 Raising Conveyor/Auger into Working Position Unit is shipped with the conveyor or auger in the lowered position. If the unit is not equipped with the optional electric lift/lower, it will be necessary to raise the conveyor or auger to the upper fixed position.

  • Page 19: Optional Scale Package (#2000621)

    — Set Up Seed Chariot 1020 Optional Scale Package (#2000621) 1. Assemble the weigh bars (902063) to the scale Fig. 1 brackets using 3/8” bolts and locknuts. The weigh bars must be assembled so the ‘TOP’ indicator on the weigh bar is located to the bottom of the bracket or rotate the load cell so the “bending direction”...
  • Page 20 — Set Up Seed Chariot 1020 Optional Scale Package (#2000621) (continued) 8. Remove the safe lifting device from the center plates on the upper platform. 9. Route the weigh bar cables along the inside edge of the box and fasten using the cable ties (9000106).

  • Page 21: Optional Electric Raise/Lower For Conveyor

    — Set Up Seed Chariot 1020 Optional Electric Raise/Lower for Conveyor/Auger 1. Attach the clevis weldment (2009372CG) to the conveyor/auger arm using 3/8” bolts and locknuts. 2. Attach the electric actuator to the support arm and lift link using the clevis pins and cotter pins.

  • Page 22: Optional Ag Decal Package Placement

    — Set Up Seed Chariot 1020 Optional AG Decal Package Placement 1. Center and attach the SMV Emblem (95730) to the rear of the unit 8 1/2” from the frame. (FIG. 2-20) 2. Attach the SIS decal (9008714) to the rear of the unit 13 3/4”...

  • Page 23: Optional Ag Decal Package, Decal Placement

    — Set Up Seed Chariot 1020 Optional AG Decal Package Placement (continued) 5. Place the amber reflector (9003127) 30” from the frame and 3 1/2” from the front on the right- Right-Hand hand side of the unit. (FIG. 2-22) Side View FIG.
  • Page 24 — Set Up Seed Chariot 1020 Notes 2-10...

  • Page 25: Operation

    — Operation Seed Chariot 1020 Section III Operation Preparing Towing Vehicle ........................ 3-2 Preparing Implement - Lubrication ....................3-2 Preparing Implement - Tires/Wheels ....................3-2 Connecting Seed Chariot to Towing Vehicle ................... 3-3 Transport Chains ..........................3-3 Transporting ............................. 3-4 Power Pak Warranty ........................

  • Page 26: Preparing Towing Vehicle

    — Operation Seed Chariot 1020 Preparing Towing Vehicle Before operating the implement, refer to the towing vehicle’s operator’s manual for informa- tion concerning safe methods of operation, hitch capacities, hitch adjustments, tire inflation and undercarriage braking operation. The vehicle must be equipped with proper electric undercarriage braking components. Check the vehicle brakes and transport lights.

  • Page 27: Connecting Seed Chariot To Towing Vehicle

    — Operation Seed Chariot 1020 Connecting Seed Chariot to Towing Vehicle • DO NOT STAND BETWEEN THE IMPLEMENT AND THE TOWING VEHICLE WHEN HITCHING. The Seed Chariot undercarriage is designed to be connected to a towing vehicle utilizing either the pintle hitch, or a 2 5/16” ball hitch. Back the towing vehicle up to the undercarriage and align the vehicle’s ball or pintle hook with the coupler or ring on the undercarriage.

  • Page 28: Transporting

    — Operation Seed Chariot 1020 NOTE: - EXTERIOR DURABILITY: MUST COMFORM TO ASTM D-1014. LIFE EXPECTANCY EQUALS FIVE YEARS. - ADHESIVE: PRESSURE SENSITIVE ADHESIVE BACKING SHALL MEET ADHESIVE SYSTEMS AS SPECIFIED IN ASTM D-4956, CLASS 1 BACKING. Transporting EXPECTANCY EQUALS FIVE YEARS - DECAL FORMAT AND COLORS MUST CONFORM TO ASAE S441.3 - SCORE BACKER / LINER: VERTICAL, HORIZONTAL, OR AS INDICATED.

  • Page 29: Power Pak

    — Operation Seed Chariot 1020 Power Pak Warranty For general maintenance and servicing of power pak unit. NOTE: For maintenance of engine and warranty information, refer to Operator’s Manual pro- vided with engine. Following are phone numbers and Websites for your convenience: www.honda-engines.com Phone 800-426-7701 Canada...

  • Page 30: Engine Operation

    — Operation Seed Chariot 1020 Engine Operation • EXPLOSIVE FUEL CAN CAUSE FIRES AND SEVERE BURNS. STOP THE ENGINE BEFORE FILLING THE FUEL TANK. • CARBON MONOXIDE CAN CAUSE SEVERE NAUSEA, FAINTING OR DEATH. DO NOT OPERATE THE ENGINE IN A CLOSED OR CONFINED AREA. •...

  • Page 31: Pivoting Conveyor Or Auger Side-To-Side

    — Operation Seed Chariot 1020 Raising and Lowing Conveyor or Auger If equipped with electric lift/lower, the conveyor/ auger can be raised by first pivoting the con- veyor/auger out of the transport position, and then actuating the raise/lower button on the wired switch.

  • Page 32: Filling Planter Or Drill

    — Operation Seed Chariot 1020 Filling Planter or Drill The conveyor/auger On/Off is controlled by a centrifugal clutch on the engine. Increasing the engine speed will engage the clutch and turn the conveyor/auger on. Continuing to increase the engine speed will increase the belt speed. Decreasing the engine speed will slow the belt, and eventually disengage the clutch to turn the conveyor/auger off.

  • Page 33: Loading Boxes Onto Seed Chariot

    — Operation Seed Chariot 1020 Loading Boxes Onto Seed Chariot 1. Remove covers from the Seed Chariot box chute by removing the pin holding the cover Remove Covers in place. Place the pin back into the bracket. Cover Removed 2. Locate covers in storage position in front of the front standard, securing with provided bungee cord.

  • Page 34: Electronic Scale Operation - Model 640Xl (Optional)

    — Operation Seed Chariot 1020 Electronic Scale Operation - Model 640XL (Optional) The following instructions can also be found in your scale/indicator user’s manual. Key Functions ON/OFF Pressed to power on or off the indicator. Pressed to access memory channel. Also used to increment numbers during the numeric entry procedure.
  • Page 35 — Operation Seed Chariot 1020 Electronic Scale Operation - Model 640XL (Optional) (continued) Gross/Tare/Net Weighing (continued) 4. Remove the weighed material from the scale (leaving the tared item). 5. Repeat steps 2 through 5 for each weighment using the same tare weight. 6.
  • Page 36 — Operation Seed Chariot 1020 Electronic Scale Operation - Model 640XL (Optional) (continued) How to Configure Filtering (continued) 5. Press the PRINT/SELECT key twice... The current CONSTANT value is shown. Press the HOLD/MENU key to increase the value. Increasing this value causes the indicator to ignore increasing amounts of weight change on the scale.
  • Page 37 Below is a summary of the items in this menu, followed by a comprehensive explanation of each item: — Operation Seed Chariot 1020 • A-LIST Used to edit the memory accumulator descriptions • A-STAT Used to access statistics of the memory accumulator channels Electronic Scale Operation - Model 640XL (Optional) (continued) •...
  • Page 38 — Operation Seed Chariot 1020 Notes 3-14...
  • Page 39 — Maintenance Seed Chariot 1020 Section IV Maintenance Lubrication - Conveyor and Auger Bearings .................. 4-2 Lubrication - Auger U-Joint ......................4-2 Lubrication - Pivot Points ....................... 4-3 Lubrication - Wheel Bearings ......................4-3 Lubrication - Engine Oil Level ....................... 4-3 Conveyor Belt - Belt Tension ......................
  • Page 40 — Maintenance Seed Chariot 1020 Lubrication Lubricate with an SAE multi-purpose grease. All fittings must be free from dirt and paint to insure entry of lubricant inside the bearing. Conveyor and Auger Bearings Lubricate these bearings every 100 hours of operation and at the end of each season before storage.

  • Page 41: Lubrication - Pivot Points

    — Maintenance Seed Chariot 1020 Lubrication (continued) Pivot Points Lubricate the pivot points on the pivoting arm Shown less conveyor/auger for every 50 hours of operation and at the end of illustration purposes only. each season. Grease Pivot Point Wheel Bearings The wheel bearings should be cleaned, repacked and adjusted every 12 months or 12,000 miles, whichever comes first.
  • Page 42 — Maintenance Seed Chariot 1020 Conveyor Belt Proper belt tension and correct ‘tracking’ of the belt are critical to maintaining the belt for years of worry-free use. Belt tension and tracking should be checked at the beginning of each season. Belt alignment should be checked after the very first initial use then after the first 2 hours of initial use or after every adjustment of the belt tension/alignment.
  • Page 43 — Maintenance Seed Chariot 1020 Conveyor Belt (continued) Belt Tracking The conveyor belt must always run at the center of the pulley in both the intake and discharge end. Improper tracking of the belt will result in excessive wear to the edge of the belt, and will greatly reduce belt lift.
  • Page 44 — Maintenance Seed Chariot 1020 Brake Cleaning and Inspection Your undercarriage brakes must be inspected and serviced immediately if a loss of perfor- mance is experienced. With normal use, servicing at one year intervals is usually adequate. With increased usage, this work should be performed more frequently as required. Magnets and shoes must be changed when they become excessively worn or scored, a condition which can reduce vehicle braking.

  • Page 45: Brake Cleaning And Inspection - Magnets

    — Maintenance Seed Chariot 1020 Brake Cleaning and Inspection (continued) Shoes and Linings A simple visual inspection of your brake lin- ings will tell if they are usable. Replacement is necessary if the lining is worn (to within 1/16” or less), contaminated with grease or oil, or abnormally scored or gouged.

  • Page 46: How To Measure Amperage

    — Maintenance Seed Chariot 1020 How to Measure Amperage System amperage is the current flowing in the system when all the magnets are energized. The amperage will vary in proportion to the voltage. The engine of the tow vehicle should be running with the undercarriage connected when checking the undercarriage braking sys- tem.

  • Page 47: Brake Drum Inspection

    — Maintenance Seed Chariot 1020 Brake Drum Inspection There are two areas of the brake drum that are subject to wear and require periodic inspec- tion. These two areas are the drum surface where the brake shoes make contact during stopping and the armature surface where the magnet contacts (only in electric brakes).

  • Page 48: Troubleshooting Brakes

    — Maintenance Seed Chariot 1020 Troubleshooting Brakes Most electric brake malfunctions, that cannot be corrected by either brake adjustments or synchronization adjustments, can generally be traced to electrical system failure. Voltmeters and ammeters are essential tools for proper troubleshooting of electric brakes. Mechanical causes are ordinarily obvious, i.e.
  • Page 49 — Maintenance Seed Chariot 1020 Belt Stretcher (Optional) ITEM PART NO. DESCRIPTION TA4-114400-0 BELT INSTALLATION TOOL 9390-122 CAPSCREW, 5/8-11UNC x 1 1/2 LG. GRADE 5 TA0-903118-0 BEARING, BALL THRUST, 5/8” I.D. TA1-114401-0 BOTTOM BAR TA2-114404-0 PLAIN TOP BAR WELDMENT TA2-114406-0 THREADED TOP BAR WELDMENT TA2-114408-0 THREAD ROD WELDMENT...

  • Page 50: Stretcher Assembled To Belt

    — Maintenance Seed Chariot 1020 Belt Stretcher (Optional) (Continued) Stretcher Assembled to Belt FOR ILLUSTRATION ONLY Belt Stretcher Assembly Rides On Bottom Of Conveyor Stretcher Trough/Pan And Is Held In Line By Bolts Assembly View "A" Belt Return Access Opening Shield View "B"...

  • Page 51: Wheels & Tires - Wheel Torque Requirements

    — Maintenance Seed Chariot 1020 Wheels & Tires Wheel Torque Requirements • IMPROPERLY TORQUED WHEEL NUTS/BOLTS CAN CAUSE A LOSS OF IMPLEMENT CONTROL AND MACHINE DAMAGE. TORQUE WHEEL NUTS/BOLTS TO VALUES IN THE TABLE. CHECK THE TORQUE BEFORE THE INITIAL USE, AFTER ONE HOUR OF UNLOADED USE OR AFTER THE FIRST LOAD, AND EACH LOAD UNTIL THE WHEEL NUTS/BOLTS MAINTAIN THE TORQUE VALUE.
  • Page 52 — Maintenance Seed Chariot 1020 Wheels & Tires (continued) Tire Warranty For questions regarding new tire warranty, please contact your local equipment tire dealer. Used tires carry no warranty. The following are phone numbers and websites for your convenience: Greenball www.greenball.com Phone nearest location: California...

  • Page 53: Torque Chart

    — Maintenance Seed Chariot 1020 Torque Chart Capscrews - Grade 5 NOTE: Grade 5 capscrews can be identified by three radial dashes on the head. NOTE: Tighten the U-bolts to have the same number of threads exposed on each end. FOOT NEWTON SIZE...

  • Page 54: Storage

    — Maintenance Seed Chariot 1020 Storage Your Seed Chariot tender is an important investment. Spend a little time to protect it from destructive rust and corrosion. You will be repaid in longer service life and better performance. After use, clean out the box, conveyor/auger and hopper. Remove all seed, and pressure wash to remove road dirt, seed treatment, etc.

  • Page 55: Troubleshooting

    — Maintenance Seed Chariot 1020 Troubleshooting PROBABLE CAUSE CORRECTION UNDERCARRIAGE SWAYING, TIRE WEAR, LIGHTS Unit sways during travel Check tire pressure Check tongue and steering hardware, tighten appropriately Tires show excessive wear Check tire pressure Wheel makes grinding or squeaking noise Service wheel bearings Tail lights are not functioning Check wires and connections...

  • Page 56: Front Undercarriage Electrical Schematic

    — Maintenance Seed Chariot 1020 Front Undercarriage Electrical Schematic — #25045 4-18...

  • Page 57: Undercarriage Lighting & Brake Electrical Schematic - #25046

    — Maintenance Seed Chariot 1020 Undercarriage Lighting & Brake Electrical Schematic — #25046 4-19...

  • Page 58: Charge From Truck Electrical Schematic - #29410

    — Maintenance Seed Chariot 1020 Charge From Truck Electrical Schematic — #29410 4-20...

  • Page 59: Conveyor Or Auger Control Electrical Schematic - #28920

    — Maintenance Seed Chariot 1020 Conveyor or Auger Control Electrical Schematic – #28920 4-21...
  • Page 60 — Maintenance Seed Chariot 1020 Conveyor/Auger Control Electrical Schematic #2000588 For Electric Conveyor/Auger Lift Package 4-22...

  • Page 61: Switch Electrical Schematic - #26734

    — Maintenance Seed Chariot 1020 Switch Electrical Schematic — #26734 4-23...
  • Page 62 — Maintenance Seed Chariot 1020 Switch Electrical Schematic — #2000617 For Electric Conveyor/Auger Lift Package 4-24...
  • Page 63 — Parts Seed Chariot 1020 Section V Parts Decals & Touch-Up Paint ......................5-2 Stationary Bracket Components ....................5-4 Scale Components........................5-6 Conveyor Drive Assembly & Hopper Components ..............5-8 Conveyor Idler End Components ....................5-12 Conveyor Discharge End Components ..................5-14 Auger Drive Assembly &...

  • Page 64: Decals & Touch-Up Paint

    — Parts Seed Chariot 1020 Decals & Touch-Up Paint Please visit www.unverferth.com/parts/ for the most current parts listing. Front, Left-Hand View ITEM 235161 95445 97961 98350 27741@ 902456 9807 9390-028 9500463 91605 902934 902933 902936 95839 98229 Rear, Right-Hand View...
  • Page 65 — Parts Seed Chariot 1020 Decals & Touch-Up Paint Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 235161 Decal, DANGER “Flammable” 95445 Decal, WARNING “High-Pressure Fluid” 97961 Decal, WARNING “Read and Understand” 98350 Decal, WARNING “No Riders”...

  • Page 66: Stationary Bracket Components

    — Parts Seed Chariot 1020 Stationary Bracket Components Please visit www.unverferth.com/parts/ for the most current parts listing.
  • Page 67 — Parts Seed Chariot 1020 Stationary Bracket Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 29070CG Stationary Bracket 9390-138 Capscrew 5/8-11UNC x 7 Grade 5 9801 Locknut 5/8-11UNC...

  • Page 68: Scale Components

    — Parts Seed Chariot 1020 Scale Components Please visit www.unverferth.com/parts/ for the most current parts listing.
  • Page 69 — Parts Seed Chariot 1020 Scale Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 29065CG Scale Bracket Weldment 902063 Weigh Bar - 2 1/8” Dia. w/ 21’ Cable 9390-138 Capscrew 5/8-11UNC x 7...

  • Page 70: Conveyor Drive Assembly & Hopper Components

    — Parts Seed Chariot 1020 Conveyor Drive Assembly & Hopper Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM 20016 9473 ITEM 29150 90167 28377 29160 90205 9399- 90165 9399- 91263 9405- TA0-9 29157 9388- 91257 91256 90311...
  • Page 71 — Parts Seed Chariot 1020 Conveyor Drive Assembly & Hopper Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 29150CG Engine Mount Weldment 901673 Honda Engine 4.8 Net HP Gas, 9.9 Cu. In. 901333...
  • Page 72 — Parts Seed Chariot 1020 Conveyor Drive Assembly & Hopper Components (continued) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 2008982 Actuator Replacement Kit 2008983CG Throttle Bracket Angle for Actuator Assembly 26719CG For 6” Tube Conveyor 9390-007 Capscrew 1/4”-20UNC x 1 1/2”...
  • Page 73 — Parts Seed Chariot 1020 Notes 5-11...

  • Page 74: Conveyor Idler End Components

    — Parts Seed Chariot 1020 Conveyor Idler End Components Please visit www.unverferth.com/parts/ for the most current parts listing. 5-12...
  • Page 75 — Parts Seed Chariot 1020 Conveyor Idler End Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 2005359CG Conveyor Tube 6” x 18’ with Decals Plate/Strap TA0-903088-0 Bearing w/Flange 1” I.D. 23912CG Adjustment Plate...

  • Page 76: Conveyor Discharge End Components

    — Parts Seed Chariot 1020 Conveyor Discharge End Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM 23918@ 23994@ 24260 24414@ 24755 26580@ 901101 901662 901723 902006 91256 93400 9500341 9388-051 9390-055 9394-004 9394-006 9394-010 9404-019 9404-021 9405-076...
  • Page 77 — Parts Seed Chariot 1020 Conveyor Discharge End Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 9500310 Idler Cover 23918CG Top Shield/Cover 23994CG Adjustment Plate 24260 Seal 24414CG Spout Bracket 24755 Poly Strip...

  • Page 78: Auger Drive Assembly & Hopper Components

    — Parts Seed Chariot 1020 Auger Drive Assembly & Hopper Components Please visit www.unverferth.com/parts/ for the most current parts listing. 5-16...
  • Page 79 — Parts Seed Chariot 1020 Auger Drive Assembly & Hopper Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 26734 Switch Assembly 198” 28920 Wire Harness 2000399 Vinyl Cover 26505 Switch Retainer 2005356CG Auger Tube 6” x 18’ with Decals...

  • Page 80: U-Joint, Pulley, Engine, & Battery Components

    — Parts Seed Chariot 1020 U-Joint, Pulley, Engine, & Battery Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 104988 Draw Latch 2008983CG Throttle Bracket 26719CG Angle for Actuator Assembly 28377CG Adjustment Plate 5-18...
  • Page 81 — Parts Seed Chariot 1020 U-Joint, Pulley, Engine, & Battery Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 28418B Battery Bracket 28419CG Battery Cover 29157CG Shield Weldment 29160CG Outer Shield Weldment 29275CG Engine Mount Weldment...

  • Page 82: Auger Discharge End Components

    — Parts Seed Chariot 1020 Auger Discharge End Components Please visit www.unverferth.com/parts/ for the most current parts listing. 5-20...
  • Page 83 — Parts Seed Chariot 1020 Auger Discharge End Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES TA0-903088-0 Bearing w/Flange 1” I.D. 29405CG End Cap 9473 Self-Drilling Screw 1/4-14 x 3/4 24414CG Spout Bracket...

  • Page 84: Pivot Arm Components

    — Parts Seed Chariot 1020 Pivot Arm Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM Front, Left-Hand Side Shown 5-22...
  • Page 85 — Parts Seed Chariot 1020 Pivot Arm Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 9388-052 Carriage Bolt 3/8-16UNC x 1 1/4 Grade 5 91263 Flange Nut 3/8-16UNC 9936 Locknut 1/4-20UNC 24863 Plate/Segment...
  • Page 86 — Parts Seed Chariot 1020 Pivot Arm Components (continued) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 9500091 Nylon Washer 9405-086 Flat Washer 1/2” SAE 9663 Top Locknut 1-8”UNC 2000189 Bearing Assembly 23951 Bushing 9405-118 Flat Washer 1”...
  • Page 87 — Parts Seed Chariot 1020 Notes 5-25...

  • Page 88: Electric Conveyor Lift Package

    — Parts Seed Chariot 1020 Electric Conveyor Lift Package #2000623 Please visit www.unverferth.com/parts/ for the most current parts listing. 5-26...
  • Page 89 — Parts Seed Chariot 1020 Electric Conveyor Lift Package #2000623 Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION QTY. NOTES 903116 Electric Actuator 2009372CG Clevis Weldment 902280 Clevis Pin 1/2” Dia. x 2 5/32 9391-023 Cotter Pin 1/8”...

  • Page 90: Platform Components

    — Parts Seed Chariot 1020 Platform Components Please visit www.unverferth.com/parts/ for the most current parts listing. 5-28...
  • Page 91 — Parts Seed Chariot 1020 Platform Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 2010229DG Platform Cover =Dove Grey= 27825DG Hopper Weldment =Dove Grey= 27826 Rubber Hopper 91257 Large Flange Hex Nut 5/16”-18UNC 9388-025 Carriage Bolt 5/16”-18UNC x 1”...

  • Page 92: Undercarriage, Hitch & Fender Components

    — Parts Seed Chariot 1020 Undercarriage, Hitch & Fender Components Please visit www.unverferth.com/parts/ for the most current parts listing. 5-30...
  • Page 93 — Parts Seed Chariot 1020 Undercarriage, Hitch & Fender Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 29237CG Fender Step/Mount LH 29238CG Fender Step/Mount RH 29240CG Fender Weldment 900956 Grommet 900954 Light/Amber (Round) 9405-086 Flat Washer 1/2”...
  • Page 94 — Parts Seed Chariot 1020 Undercarriage, Hitch & Fender Components (continued) Please visit www.unverferth.com/parts/ for the most current parts listing. PART NO. DESCRIPTION NOTES 900786 Breakaway Electric Switch Complete 902764 Battery w/Charger & Box 29230CG Light Bar Weldment 9390-125 Capscrew 5/8-11UNC x 2 1/4...
  • Page 95 — Parts Seed Chariot 1020 Notes 5-33...

  • Page 96: Axle & Wheel Components

    — Parts Seed Chariot 1020 Axle & Wheel Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 9390-123 Capscrew 5/8-11UNC x 1 3/4 Grade 5 9801 Locknut 5/8-11UNC 98115 Wheel/Tire 903052B Torsion Axle Assembly w/Brakes...

  • Page 97: Spare Tire Kit Components

    — Parts Seed Chariot 1020 Spare Tire Kit Components Please visit www.unverferth.com/parts/ for the most current parts listing. DIA. x 6 5/8 7 1/8 2-13UNC 8 GB TOOTH ITEM PART NO. DESCRIPTION NOTES 2000622B Spare Tire Kit Includes Items 1 through 10...

  • Page 98: Telescopic Spout

    — Parts Seed Chariot 1020 Telescopic Spout 2-Stage Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 27629 6” Conveyor Telescopic Spout (71” Extended; 51 1/2 Collapsed) Includes Items 2 & 4 95870 Telescopic Spout...
  • Page 99 — Parts Seed Chariot 1020 Telescopic Spout 3-Stage Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 22578 6” Conveyor Telescopic Spout 6’-10’ ONLY Includes Items 2, 3, 4 96855 Telescopic Spout 98060 Clamp/T-Bolt 22577...

  • Page 100: Platform For Units Less Undercarriage Kit #2003134Cg

    — Parts Seed Chariot 1020 Platform for Units Less Undercarriage Kit #2003134CG Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 2003078CG Adapter Bracket Weldment =Charcoal Grey= 2003079CG Stand Weldment =Charcoal Grey= 2003126CG S-Bracket =Charcoal Grey=...
  • Page 101 — Parts Seed Chariot 1020 AG Decal Package (Optional) - S MV, SIS Decals, & Reflectors Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION QTY. NOTES 2010513 AG Decal Package Option 9003126 Reflector, RED 9003127...
