SPECIFICATIONS
70
G½
G½
120
WALL
OPERATING CONDITIONS
1.
Water supply pressure : 0.05 ~ 0.75 MPa.
2.
Ensure that water supply is clean ( No Sand, Dirt, Etc.).
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth.
Many cleaners may contain chemicals, such as ammonia,
chlorine, toilet cleaner etc. which could adversely affect the
finish and are not recommended for cleaning
ATTENTION
1.
Don t use abrasive cleaners or solvents on faucets and
fittings.
2.
As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
S060330S
INSTALLATION
1.
Hot Water
Supply *
100
G½
* Pipe supplied by owner
2.
0
50
20
-20
Bolt
* Remove the cover after the mortar dry
3.
Packing
Flange
Handle
" ALISEI "
SINGLE LEVER SHOWER MIXER TX443SX
To Shower Head *
Minimal
Mortar Level
Cold Water
Supply *
Maximal
Mortar Level
Mortar
Cover *
Ring w/ O-Ring
Bolt
Hex. Key
TROUBLESHOOTING
CHECK
PROBLEM
POINT
1
Water leaks around the handle
Handle is loose
2
1. CONNECTING NUT
Use Hex. Socket Key
(Not Include)
2. BOLT
SOLUSI
Tighten
Tighten
R2
