Toto EGO TX443SEN Manual

SPECIFICATIONS

70
G½
G½
WALL
Ø162

OPERATING CONDITIONS

1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).

MAINTENANCE

All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toilet cleaner etc. which could adversely affect the finish and
are not recommended for cleaning
ATTENTION
Don t use abrasive cleaners or solvents on faucets and
1.
fittings.
2. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
S06164S
"

INSTALLATION

1.
Hot Water
Supply *
118
G½
* Pipe supplied by owner
2.
Cover *
0
50
-20
0
70
-20
Bolt
* Remove the cover after the mortar has dry
3.
Flange
Ring
w/ O-Ring
EGO SINGLE LEVER SHOWER MIXER TX443SEN
"
To Shower Head *
Minimal
Mortar Level
Cold Water
Supply *
Maximal
Mortar Level
Mortar
Packing
4
Handle
Hex. Key

TROUBLESHOOTING

CHECK
PROBLEM
POINT
Water leaks around the handle 1
Handle is loose
2
1. CONNECTING NUT
Bolt
SOLUTION
Tighten
Tighten
2. BOLT
R7
