- Page 1 Enable-IT 865 PTZQ Pro Rev B High Powered PoE+ Ethernet Extender User Manual All Rights Reserved 1997 - 2015 -IT - Proprietary and Confidential NABLE...
- Page 2 Enable-IT, Inc. Enable-IT, Inc. reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of Enable-IT, Inc., to provide notification of such revision or change. Enable-IT, Inc. provides this documentation without warranty, term, or condition of any...
-
Page 3: Table Of Contents
ANUAL 865 PTZQ PRO EXTENDED P ETHERNET KIT .... 5 NTRODUCING About The 865 PTZQ PRO EXTENDED PoE and ETHERNET KIT ... 5 Key Benefits ....................6 Summary Of Features ................. 6 Multi Use Applications ................. 7 865 PTZQ PRO EXTENDED P ETHERNET KIT .... -
Page 4: About This User Manual
This product User Manual provides all the information needed to install and use the Enable-IT 865 PTZQ PRO EXTENDED PoE and ETHERNET KIT. This User Manual is intended for use by technicians who are responsible for installing and setting up network equipment. -
Page 5: Introducing The 865 Ptzq Pro Extended P Oeand Ethernet Kit
Voice, Ethernet Data and Power over Ethernet (PoE) in a combined package that exceeds the IEEE distance limitations for all Ethernet equipment. WARNING: Output LAN ports 1 & 2 on the 865 PTZQ PRO CPE are PoE enabled and not for use with non-PoE equipment as it may damage any non-PoE equipment. -
Page 6: Key Benefits
The following list identifies the 865 PTZQ PRO Extended PoE and Ethernet Kit key benefits. • Quad switched PoE+ enabled LAN RJ-45 10/100 Ethernet ports on each end for expansion without adding a hub or switch on each end. •... -
Page 7: Multi Use Applications
Carriers and Access Providers can come and go, but the 865 PTZQ PRO Extended PoE and Ethernet Kit technologies continue to provide lasting value such as the other utilities like water, gas and electricity. The Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit is suited for the following key environments: •... -
Page 8: Installing The 865 Ptzq Pro Extended P Oeand Ethernet Kit
The Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit has a distance restriction of 1,500ft or 458m over 2-pair of Category 3 up to 4-pair Category 5e / CAT6 wiring from your LAN and power source to the remote PoE device. Therefore quick, simple site surveys and installation planning are highly recommended –... -
Page 9: Unpacking The Enable-It 865 Ptzq Pro Kit
This confirms basic proper operation of the units. WARNING: Output LAN ports 1 & 2 on the 865 PTZQ PRO CPE are PoE enabled and not for use with non-PoE equipment as it may damage any non-PoE equipment. -
Page 10: Performing The On-Site Installation
PoE injector Data IN port. Attach the power adapter to the 865 PTZQ CO unit. Attach the 375 PoE+ injector to the 865 PTZQ PRO CO LAN1/PoE port with Ethernet patch cord provided. Apply power to the 375 PoE injector with the country power cord provided. -
Page 11: Troubleshooting
For troubleshooting, first examine the backbone wiring pair and make sure you have solid connections. The Interlink Sync LED will be lit on each 865 PTZQ PRO unit to show proper connection and pairing. If the Interlink Sync LED Link is flashing – (Not pulsing) 1) Make sure your wiring is straight through and not connected to any Telco punch down blocks or a few as possible –... -
Page 12: Performance Settings (Dip Switch)
6dB SNR and change to Interleaved channel. This may help clean up any noise bleeding over your cabling. All Rights Reserved 1997 - 2015 Enable-IT, Inc. Page 12 of 16... -
Page 13: Technical Support
Online Technical Services The Enable-IT Support Portal is available 24/7 to open a ticket or check the status of one. Please use this support website as your first source for help as it contains an on-line knowledge base of articles, documentation, FAQ's and other problem-solving resources. -
Page 14: Enable -It, Inc . Limited Warranty
Remedies for Breach of Warranty. In the event of a breach of the foregoing warranty, Enable-IT will, in its sole discretion and at its cost, and subject to the terms of the following paragraph, repair the non-conforming Product, replace the non-conforming Product with a new or reconditioned Product or refund the purchase price for the Product. - Page 15 STORED ON OR TRANSMITTED USING THE PRODUCT. 2. LIMITATION OF LIABILITY. IN NO EVENT SHALL ENABLE-IT BE LIABLE TO THE END USER, OR ANY THIRD PARTY, FOR ANY INDIRECT, SPECIAL, PUNITIVE, INCIDENTAL OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH OR ARISING OUT OF THE SALE OR USE OF THE...
-
Page 16: Contact Us
Sales and Customer Care: Toll Free US and Canada 888 309-0910 866 389-8605 Fax Other International +1 702 924-0402 +1 702 800-2711 Fax E Mail sales@enableit.com support@enableit.com RMA Support: http://support.enableit.com All Rights Reserved 1997 - 2015 Enable-IT, Inc. Page 16 of 16...
