Using your gas cooktop

Fig 27 Cooktop layout
1. Triple-ring wok burner
2. Semi-rapid burner
3. Dual burner
Gas burners
The dial controls the flow of gas through the safety valve.
Semi-rapid and triple-ring wok burners
• o = closed valve (OFF)
•
= maximum flow of semi-rapid and triple-ring burner burners
•
= minimum flow of semi-rapid and triple-ring burner burners
You can choose to cook at any heat between
https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX...
Updated: Sat, 18 Feb 2023 23:02:06 GMT
Powered by
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OR90SDBGFX3 and is the answer not in the manual?

Questions and answers

Related Manuals for Fisher & Paykel OR90SDBGFX3

Summary of Contents for Fisher & Paykel OR90SDBGFX3

  • Page 1 • o = closed valve (OFF) • = maximum flow of semi-rapid and triple-ring burner burners • = minimum flow of semi-rapid and triple-ring burner burners You can choose to cook at any heat between https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Sat, 18 Feb 2023 23:02:06 GMT Powered by...
  • Page 2 • Read this user guide, taking special note of the ‘Safety and warnings’ section. • Make sure all burner control dials are turned off. • Turn the power to the cooker on at the wall. https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Sat, 18 Feb 2023 23:02:06 GMT Powered by...
  • Page 3 If the burner does not light within 15 seconds, turn the control dial off and wait at least one minute before trying again. 4. To turn the burner off, turn the dial clockwise (semi-rapid and triple-ring burners or dual burner when using https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Sat, 18 Feb 2023 23:02:06 GMT Powered by...
  • Page 4 If the flame is irregular If the flame is yellow or irregular, check that the burner parts, including the burner cap, are: • clean and dry. • positioned correctly. See ‘Care and cleaning’. https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Sat, 18 Feb 2023 23:02:06 GMT Powered by...
  • Page 5 Fig. 30 Efficient and inefficient saucepan bottoms Fig. 29 Correct and incorrect matching of cookware and burner size Wok stand The wok stand fits over the dual or triple ring burner pan support. https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Sat, 18 Feb 2023 23:02:06 GMT Powered by...
  • Page 6 • The wok stand MUST BE PLACED ONLY over the pan support for the triple ring or dual burner. • The cooktop becomes very hot during operation. Keep children well out of reach. Fig. 31 Correct placement of wok stand https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Sat, 18 Feb 2023 23:02:06 GMT Powered by...
