Care And Cleaning
Before you start cleaning your cooker, please:
• Read these cleaning instructions and the 'Safety and warnings' section at the start of this user
• Turn the cooker off at the wall.
• Make sure the cooker is a safe temperature to touch.
• Do not use a steam cleaner.
• Do not keep flammable substances in the oven or drawer.
General Advice
• Wipe down the cooktop and wipe out the oven after every use.
• Wipe up spills. Avoid leaving alkaline or acidic substances (such as lemon juice or vinegar) on the surfaces.
• Do not use cleaning products with a chlorine or acidic base.
Cleaning the Outside of the Cooker
• Do not use abrasive cleaners, cloths or pads on the outside surfaces.
• Immediately wipe off any caustic cleaners if they are spilled onto the oven door handle.
Wipe the outside surfaces often, using warm water and a mild household detergent. The stainless steel may also be
cleaned with a suitable cleaner and polish.
https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX...
guide.
Updated: Thu, 20 Feb 2020 06:37:43 GMT
Powered by
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the OR90SDBGFX3 and is the answer not in the manual?

Questions and answers

Related Manuals for Fisher & Paykel OR90SDBGFX3

Summary of Contents for Fisher & Paykel OR90SDBGFX3

  • Page 1 • Immediately wipe off any caustic cleaners if they are spilled onto the oven door handle. Wipe the outside surfaces often, using warm water and a mild household detergent. The stainless steel may also be cleaned with a suitable cleaner and polish. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...

  • Page 2: Burner Parts And Pan Supports

    • It is very important to check that the burner flame spreader and the cap have been correctly positioned. Failure to do so can cause serious problems. To avoid damage to the electronic ignition, do not try to light a burner without all burner parts in place. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
  • Page 3 Both the ignitor and probe must be very carefully cleaned using a toothbrush and methylated spirits (see Fig. 24). Fig. 28 Correct line-up of semi-rapid burner parts Fig. 29 Replacing the https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
  • Page 4 Both the ignitor and probe must be very carefully cleaned using a toothbrush and methylated spirits (see Fig. 24). Fig. 30b Correct positioning of flame spreader- dual burner Fig. 30a Correct positioning of the flame spreader-triple ring wok burner https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...

  • Page 5: Cleaning The Inside Of Your Oven

    • Do not use abrasive cleaners, cloths or pads to clean the enamel. • To make cleaning easier, you can remove the side racks, the oven door, and the fat filter. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
  • Page 6 Fig. 34 Drop-down grill element Cleaning the Enamel Cavity Clean the enamel on the inside of the oven when it has cooled down, using household detergents. You may use ‘off the https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
  • Page 7 • the guard rail is at the back. The grill tray should be positioned between the two wires of a shelf position and orientated as shown. Fig. 36 Oven shelves and grill tray https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
  • Page 8 • both slides on the same level. Remove the side racks first to make removing the sliding shelf supports easier. Fig. 37 Fitting the sliding shelf support Fig. 38 Removing the sliding shelf supports https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...

  • Page 9: Storage Drawer

    Fig. 39 Removing the drawer Replace the Drawer 1. Insert the drawer rails into the guide rails. 2. Gently push the drawer in completely, the catches will automatically hook. Fig. 40 Replacing the drawer https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...

  • Page 10: Replacing The Oven Light Bulbs

    3. Using a flat-head screwdriver, twist and bracket in the back and pull out the faulty bulb. lift the retainer clip upwards to release the glass cover. Hold the glass cover to prevent it falling. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
  • Page 11 Your oven door has 3 panes of glass. The inner and middle panes may be removed for cleaning. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
  • Page 12 1a. Turn the oven off at the wall. Make sure you have 2. Open the levers on the left and right prepared hinges to their full extent, as shown. enough space for resting the door and its glass panes https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
  • Page 13 5a. Lift the door and disengage the hinges. 5b. Rest the door on a soft surface. Ensure you lay it with the handle side down. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
  • Page 14 • you do not force any of the panes into place. If you are experiencing difficulties replacing the panes, remove them and start the process again from the beginning. If this still does not help, call Customer Care. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT...
  • Page 15 It has to be in this position for the door to function correctly. ◦ Check that the gasket (D) is in place. It should sit on the inner pane of glass in the centre as shown. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
  • Page 16 5. Gently push the glass retainer back into place. You should be able to hear the tabs on both sides click as they lock the glass retainer in. Make sure the glass retainer is correctly and firmly in place and that the glass panes are secure. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
  • Page 17 4a. Fully close the levers on the left and right hinges, as 3. Open the door to its full extent shown. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
  • Page 18 4b. Close the door, turn the power supply to the oven on at the wall. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR90SDBGFX3/User_Guide_OR90SDBGFX… Updated: Thu, 20 Feb 2020 06:37:43 GMT Powered by...
