Note: The hardkey of a CardBus card is different from that of
the traditional 16-bit PCMCIA card. This mechanism can
protect the 3.3V CardBus card from mis-insertion to 5V 16-bit
PCMCIA slot (Fig. 2-2.2).
Protection grid
Figure 2-2.1 CardBus Fast Ethernet Adapter (LinkPort/TX32A)
Traditional PC Card (5V)
CardBus Card (3.3V)
PCMCIA Card
Figure 2-2.2 Hardkey of CardBus and Traditional
Ethernet
Adapter Cable and RJ-45 Extension Adapter (See Fig. 2-2.3)
2-2
Chapter 2: Hardware Installation
