Compex WLM54AG Datasheet

datasheet
product
High Performance
with Low Power
Consumption
Output Power of up
to 23dBm at a/b/g
band
Available in many
different modes
Affordable and
ideal for a variety
of applications
Copyright © 2006 Compex Systems. All rights reserved. COMPEX and the COMPEX logo, are registered trademarks of COMPEX Inc. While every effort is
made to ensure the information is accurate, Compex does not accept liability for any errors or mistakes that may arise. All specification is subject to change
without notice.
WLM MINIPCI SERIES
WLM54G (G) / WLM54G (SUPERG) /
WLM54AG (AG) / WLM54AG (SUPERAG)
Compex WLM series MiniPCI network adapters are compact, lightweight, has high-
performance and low power consumption. Built on Atheros chipset, it can be used for all
IEEE 802.11b/g or a/b/g compatible WLAN and is ideally suited for integration in a wide
range of OEM devices.
WLM series offers a high output power of up to 23dBm on IEEE 802.11a/b/g band. WLM
Mini PCI series also supports a variety of security features such as WEP, TKIP, AES,
receive and transmit filtering, error recovery, quality of service (QoS) as well as IEEE
802.1x standard, thus providing security to the wireless network and increase WLAN
performance.
It is also available in Super-G/ Super-AG mode which delivers better performance at
higher throughput for your network connectivity.
Features
2.4/ 5GHz IEEE 802.11 a/b/g standard
Up to 108Mbps high-speed data rate
High Output Power of up to 23dBm @ a/b/g Band
Dynamic Frequency Selection (DFS)
Data Security Encryption and Authentication support
Transmission Power Control (TPC)
Multi-country Roaming Support (IEEE 802.11d)
Flexibility: flexible design for embedded system or OEM project
Available in Wireless-G, Wireless-AG, Super-G and Super-AG modes
Applications
•
Infrastructure Networking
•
Embedded system or OEM device
