Compex WLM54G Datasheet

Datasheet
Product
High performance
with Low Power
Consumption
Output Power of Up
to 23dBm at b/g
Band
Affordable and Ideal
for a Variety of
Applications
WLM54G 6A-23 MINIPCI
ATHEROS AR2413 Chipset
23dBm @ 2.4G (200mW)
The Compex WLM54 G 6A-23 MiniPCI network adapter is compact
and lightweight, and delivers high performance with low power
consumption. Built on the Atheros AR2413 chipset, it can be used
for all IEEE 802.11b/g-compatible WLANs and support up to
54Mbps high-speed data rate. It is ideally suited for integration in a
wide range of OEM devices.
The WLM54G 6A-23 MiniPCI network adapter boasts an output
power of up to 23dBm on the b/g band and also supports a variety
of security features such as WEP, TKIP, AES, receive and transmit
filtering, error recovery, quality of service (QoS) as well as the IEEE
802.1x standard, thus providing security to the wireless network and
increasing WLAN performance.
Features
•
2.4GHz IEE 802.11 b/g standard
•
Up to 54Mbps high-speed data rate
•
Output Power of up to 23dBm @ b/g band
•
Data Security Encryption and Authentication Support
•
Multi-country roaming support (IEEE 802.11d)
•
Flexible design for embedded system or OEM project
Applications
•
Infrastructure Networking
•
Embedded system or OEM device
