Spray Nozzles - BorMann PRO BPW5000 Manual

- Connect nozzle and nozzle extension.
- Check gauze filter is clear of any blockage.
- Connect the water supply hose.
- Check that the hose has no kinks in it.
- Turn on water and check for leaks.
- Depress trigger to allow air to be expelled though the pump and hoses, lock trigger.
- Plug in machine and turn on switch.
- Unlock trigger and use the pressure washer.
Shut down
Turn off the motor (push switch to the off position).
Unplug the unit from the power source.
Turn off the water supply.
Press the trigger of the gun to depressurize the system.
Disconnect the garden hose from the pressure washer.
Wipe all surfaces of the unit with a damp clean cloth.
Engage the gun safety lock.
CAUTION: ALWAYS turn off the unit's motor BEFORE turning off the unit's water supply.
Serious damage could occur to the motor if the unit is run without water.
CAUTION: NEVER disconnect the high-pressure discharge hose from the machine while the system is
still pressurized. To depressurize the unit, turn off the motor, turn off the water supply and squeeze
the trigger 2-3 times.

SPRAY NOZZLES

The Pressure Washer comes furnished with four spray nozzles. Each nozzle is color coded and delivers
a specific spray pattern and pressure for a particular cleaning job. The size of the nozzle determines
the size of the fan spray and the pressure out of the nozzle.
0°Nozzle – Red: This nozzle delivers a pinpoint stream of pressurized water and is extremely powerful.
It covers only a small area of cleaning. This nozzle should only be directed at surfaces that can
withstand high pressure such as metal or concrete. Do not use this nozzle to clean wood. (Fig 1)
Fig 1 Fig2 Fig 3 Fig 4
25° Nozzle – Green: This nozzle delivers a 25 degree spray pattern for intense cleaning of larger areas.
This nozzle should only be used on areas that can withstand pressure from this nozzle. (Fig 2)
40° Nozzle – Yellow: This nozzle delivers a 40 degree spray pattern and a less powerful stream of
water. This nozzle can cover a wide area and should be used for most general cleaning jobs. (Fig 3)
Chemical Nozzle – Black: This nozzle is used to apply special chemicals and cleaning solutions. This
nozzle produces the weakest pressure stream of the five nozzles. (Fig 4)
The nozzles are stored in receptacles on a panel mounted to the handle of the washer. Colors on the
panel identify nozzle location and spray panel.
WATER INLET SCREEN
This switch is used to adjust the flow rate of cleaning solution when using the washing machine.
When you rotate clockwise, the flow rate of the cleaning solution will increase. (Fig 5)
The water inlet filter must be inspected regularly, so as to avoid blockage and restriction in the water
supply to the pump (fig 6).
4
