The HDMI & (USB) over Giga LAN Extender NVxMx-Series
Model
Number
NVKMU-M41
NVKMU-M42
NVKM-M41
NVKM-M42
NVXMU-M31
NVXMU-M32
NVXM-M31
NVXM-M32
Transmitter & Receiver
NVKMU-41L + NVKMU-41R
NVKMU-42L + NVKMU-42R
NVKM-41L + NVKM-41R
NVKM-42L + NVKM-42R
NVXMU-31L + NVXMU-31R
NVXMU-32L + NVXMU-32R
NVXM-31L + NVXM-31R
NVXM-32L + NVXM-32R
With
USB
V
X
V
X
0
Max.
With PoE
Resolution
X
V
4K@30Hz
X
V
X
V
1080p
X
V
Advertisement
Table of Contents
Related Manuals for DirekTronik NV M Series
Summary of Contents for DirekTronik NV M Series
- Page 1 The HDMI & (USB) over Giga LAN Extender NVxMx-Series Max. Model With Transmitter & Receiver With PoE Resolution Number NVKMU-M41 NVKMU-41L + NVKMU-41R NVKMU-M42 NVKMU-42L + NVKMU-42R 4K@30Hz NVKM-M41 NVKM-41L + NVKM-41R NVKM-M42 NVKM-42L + NVKM-42R NVXMU-M31 NVXMU-31L + NVXMU-31R NVXMU-M32 NVXMU-32L + NVXMU-32R 1080p...
-
Page 2: Table Of Contents
Table of Content ------------------------ Introduction ................1 ------------------------ Features ..................2 ------------------------ Product Description ..............4 ------------------------ Installation .................. 6 1. Device Connection ................... 6 2. Connection Pattern ..................7 ------------------------ Operation ................... 10 1. Push Button Control ..................10 2. -
Page 3: Introduction
Introduction ------------------------ This User’s Manual is included 3 applications: Application 1: Unit-Cast Configuration →The Unit-Cast application is Plug-and-Play basis. It’s easy to install in seconds. Application 2: Multi-Cast (Multi-to-Multi) Configuration Application 3: Video Wall Configuration →The Multi-Cast application can be used as multi-to-multi and video wall which is suitable for digital signage. - Page 4 Features ------------------------ Extend HDMI video (4K UHD supported for NVKMx Series), Audio signals and 2 x USB 2.0, 2 x USB 1.1 signals over Giga LAN ( USB extension function is only available for NVxMU series products ) 16 selections on the Rotary DIP Switch available for pairing ...
- Page 5 System Requirement 1. HDCP 2.2 compliant monitors with HDMI interface for the HDCP video source 2. CAT5 / 5e / 6 UTP cable (EIA / TIA 568B industry standard compliant) 3. Ethernet Hub (Giga Ethernet Hub is recommended): Application Recommended Ethernet Hub Giga Ethernet Hub with IGMP, Snooping &...
-
Page 6: Product Description
Product Description ------------------------ NVKMU-M42 Connect to an HDMI source Video Connector Connect to an HDMI display RJ-45 Port Connect to Ethernet Hub Reset Button System reset Power Supply Apply the proper power to the unit (PoE) T5: Connect to a PC or HDMI device with USB port R5’... - Page 7 Connect IR Receiver to “IN” IR Connector Connect IR Transceiver to “OUT” F1 Push Button See Push Button Control section F2 Push Button Locking HDMI cable on the panel HDMI Lock Screw Audio Embed Embed audio source into HDMI input Switch Native (Left): Original Resolution NVKMU...
-
Page 8: Installation
Installation ------------------------ 1. Device Connection WARNING! ● Ensure that all devices are powered off before connecting to the Unit. ● Make sure all devices you will connect are properly grounded. ● Place cables away from fluorescent lights, air conditioners, and machines that are likely to generate electrical noise.. -
Page 9: Connection Pattern
2. Connection Pattern Point-to-Point Application Function as simple video extenders, without Ethernet Hub in between Uni-cast Application USB Application... - Page 10 Multi-to-Multi Application...
- Page 11 Video Wall Application...
-
Page 12: Operation
Operation ------------------------ The LEDs on the Extender Units show the real-time status, indicating the linking and communication between the Transmitter and the Receiver Unit. Users can identify the current status through the LED indicators on the unit. The quality of the output signal will depend largely upon the quality of video sources, cables and display devices. -
Page 13: Uni-Cast Configuration
2. Uni-Cast Configuration User needs to do the first thing setting Uni-cast mode in the browser because factory default is Multicast Mode. 2.1. How to set Uni-cast for Transmitter A). Domain Name The first thing users need to do is to set the unit as Uni-cast mode via the web browser because the factory default setting is Multi-cast mode. -
Page 14: Multi-To-Multi Configuration
3. Multi-to-Multi Configuration Set up an identical ID number for the connected units in the same channel. For example, if the ID number on unit is 0, then the ID number of Rx units that display the same content as should be set up as 0 as well. -
Page 15: Video Wall Configuration
4. Video Wall Configuration 4.1 Basic Setup: Click on Video Wall Setup for Basic Setup first Bezel and Gap Compensation: ＊ OW = Outside Width ＊ OH = Outside Height ＊ VW = View Width ＊ VH = View Height Adjust dimensions (mm) for the monitors of video wall. - Page 16 Wall Size and Position Layout: Step 1. ● Vertical Monitor Count x Horizontal Monitor Count: If the video wall is 2 x 2, then set up Vertical Monitor Count and Horizontal Monitor Count as 2. (maximum: 9 x 9) Step 2.
- Page 17 Part 1: Wall Size and Position Layout Part 2: Configure row and column position for each display...
- Page 18 4.2 Advanced Setup: 4.2.1 Software Solution After the Basic Setup is done, users may enter this page for advanced setting. Please notice that each monitor should have its own part of screen section and do not overlap. Step 1: Choose Control Target ●...
- Page 19 4.2.2 Hardware Solution Hardware solution: use multiple Transmitter units. The following is a 4 x 4 example of hardware solution. 1. Add more Transmitter units to the system for each row, and set up the ID number for each Rx unit; see below. 2.
-
Page 20: Network Configuration
a). Choose a host (Transmitter); the ID number (4 digits) should refer to rotary switch position (1~F); see Rotary Switch chart. b). The row & column positions of 1 row should be 0 & 0. The 2 row is 1 & 0. The 3 row is 2 &... - Page 21 5.1.1. System configuration via Domain Name a. Domain Name is for Transmitter only. b. It is suggested to use “Safari” web browser or other web browsers like Google Chrome, Firefox or IE…, etc. If you use other web browsers which are not mentioned above, you’ll need to install “bonjour SDK”: Go to the and look for “bonjour SDK website...
- Page 22 System configuration via IP address 5.1.2. a. Type a specific IP in the address bar and go to the setting page for each extender unit such as 169.254.xxx.xxx. It is suggested using “Safari” web browser or Google Chrome, Firefox or IE. b.
- Page 23 The LAN Extender can either have its IP address assigned dynamically (DHCP) or it can be given a fixed IP address. If there is no DHCP you must assign a static IP for the unit. You can get it from the networking administrator.
- Page 24 On Function Page, it is divided into three sections, Video over IP, serial over IP and USB over IP. In factory default setting, there are three item selected, Enable Video over IP, Enable Video Wall and Enable Serial over IP. If users cancel "Enable Video over IP", Receiver Unit’s Video Output Function will be off.
-
Page 25: Specifications
Specification ------------------------ The 4K UHD HDMI & USB over Giga LAN Extender NVKMU-Series Transmitter Unit Receiver Unit Extender NVKMU-41L NVKMU-41R NVKMU-M41 (Non PoE) NVKMU-M42 *NVKMU-42L *NVKMU-42R (PoE) Video HDMI x 1 Input Audio Analog Stereo Microphone Video HDMI x 1 Output Audio Microphone... - Page 26 The 4K UHD HDMI over Giga LAN Extender NVKM-Series Transmitter Unit Receiver Unit Extender NVKM-M41 NVKM-41L NVKM-41R (Non PoE) NVKM-M42 (PoE) *NVKM-42L *NVKM-42R Video HDMI x 1 Input Audio Analog Stereo Microphone Video HDMI x 1 Output Audio Microphone Analog Stereo RJ45 Connection RJ45 x 1 RJ45 x 1...
- Page 27 The HDMI & USB over Giga LAN Extender NVXMU-Series Transmitter Unit Receiver Unit Extender NVXMU-31L NVXMU-31R NVXMU-M31 (Non PoE) NVXMU-M32 *NVXMU-32L *NVXMU-32R (PoE) Video HDMI x 1 Input Audio Analog Stereo Microphone Video HDMI x 1 Output Audio Microphone Analog Stereo USB Interface Mini-USB USB-A x 4...
- Page 28 The HDMI over Giga LAN Extender NVXM-Series Transmitter Unit Receiver Unit Extender NVXM-31L NVXM-31R NVXM-M31 (Non PoE) NVXM-M32 *NVXM-32L *NVXM-32R (PoE) Video HDMI x 1 Input Audio Analog Stereo Microphone Video HDMI x 1 Output Audio Microphone Analog Stereo RJ45 Connection RJ45 x 1 RJ45 x 1 Control Method...
-
Page 29: Edid Configuration
------------------------ EDID Configuration EDID (Extended Display Identification Data) is greatly important which contains information about manufacturer name and serial number, product type, maximum image size, color characteristics, factory pre-set timings, frequency range limits, etc. In some cases display problems may occur due to incorrect EDID communication between the display monitor and the unit or inappropriate EDID data programmed by display manufactures. -
Page 30: Serial Configuration
Serial Configuration ------------------------ IP Setting Telnet Host / client telnet to IP 169.254.0.101 port 24 telnet 169.254.0.101 24 Use "root" to login. List all boards' hostname and IP address : node_list. Configure IP setting Autoip : 169.254.xxx.xxx private IP domain is used and auto-generated on boot. Dhcp client : Use DHCP client to get IP address. - Page 31 B0,B1,B2,B3 are mapped to the 4-bits dip switch...
-
Page 32: Optional Hdmi Locking Connection
------------ Optional HDMI Locking Connection 1. Hex Jack Screw Hex Jack Screw x 1 Step 1. Install Hex Jack Screw on the unit. Step 2. Install the HDMI Cable. 2. Cable Tie... - Page 33 Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY FOR DIRECT OR INDIRECT, SPECIAL, INCIDENTIAL OR CONSEQUENTIAL DAMAGES, LOSS OF PROFIT, LOSS OF BUSINESS, OR FINANCIAL LOSS WHICH MAY BE CAUSED BY THE USE OF THE PRODUCT EXCEEDS THE PRICE PAID FOR THE PRODUCT.
