DirekTronik DVFX-110 User Manual

1-fiber detachable dvi module

Advertisement

Quick Links

1-Fiber Detachable DVI
module, DVFX-110
User's Manual
Manual Contents
__________________________________________
Manual Contents
Warranty Information
Regulatory Statements
Pictorials
Figure 1 - Connection Diagram of Optical DVI
Extension Modules
Figure 2 - Connection of power adapter to the
transmitter and receiver
Figure 3 - Connection of optical fiber
Figure 4 - Connection of the transmitter to DVI source
and receiver to the display
Figure 5 - Connection diagram using optical splitter
Figure 6 - Position of EDID-PRG. Button and
Status LED
1-0
1-1
1-2
1-3
1-4
1-5
1-6
1-7
1-8
1-1
1-3
1-3
1-4
1-4
1-5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVFX-110 and is the answer not in the manual?

Questions and answers

Summary of Contents for DirekTronik DVFX-110

  • Page 1 Self-EDID Programming Procedure Troubleshooting, Maintenance, Technical Support Product Specifications Warranty Information 1-Fiber Detachable DVI Regulatory Statements module, DVFX-110 Pictorials Figure 1 – Connection Diagram of Optical DVI Extension Modules User’s Manual Figure 2 – Connection of power adapter to the transmitter and receiver Figure 3 –...
  • Page 2 The key features of DVI graphic controller in your OS. DVFX-110-TR is, by using an optical splitter (OPS-116S), one (1) signal from transmitter can be copied up to sixteen (16) times and it gives you a cost effective and space saving installation for various application.
  • Page 3 Step 3 By using an optical splitter OPS-xyz, one (1) signal from DVFX-110 transmitter Please, check if the maximum resolution of the display is UXGA (1600x1200). can be copied up to sixteen (16) times as shown in figure 5. For more Otherwise, follow the instructions for Self-EDID Programming Procedure on information, please refer to user’s manual of OPSR-2, OPX-xyz.
  • Page 4 Step 2 Screen is distorted or displays noises. Plug the 5V power adapter to the power jack of the transmitter of DVFX-110. Ensure the Power LED ON and Status LED blinking slowly. - Check if the graphic resolution is properly set. Go to the display properties of Windows and tap the settings.
  • Page 5 Fiber-optic connection: The transmitter and receiver modules of Opticis shall not be responsible for any software, firmware, information, or me DVFX-110 have one (1) SC receptacles so as to be connected with mory data of customer contained in, stored on, or integrated with any product s returned to Opticis for repair under warranty or not.
  • Page 6 © 2011 Opticis Co., Ltd. All Rights Reserved UL/EN Statement Revision 1.0, .Mar. 04, 2011 This equipment has been tested and found to comply with the limits for medical devices in UL/EN 60601-1, 60601-1-2 and FCC/CE. These limits are designed to provide reasonable protection against harmful interference in a typical medical installation.
