3.3 Button bars

When you touch the screen, button bars are displayed at the top and
the bottom of the screen. A graphical overview and button definitions
follow:
The buttons are defined in the following table.
Button Name
Menu button
Time button
Zoom out
Snapshot
Color mode
Zoom in
Advanced Features and Functions
Description
Displays the Main Menu, where you
can access functions and change how
the display is rendered.
Displays the current time and date. Tap
anywhere on this screen to display the
Time and Date screen
where you set the values.
Decreases the magnification and
shows more of the image on the
screen.
Takes a picture of the image currently
on the screen.
Changes the color combination used to
display the current image on the
screen.
Increases the magnification and shows
less of the image on the screen.
Compact 8
(see page 14),
