IGBT Module Replacement for Fx09-Fx12 and E1h–E4h
Installation Guide
Kit number
176F3957
176F3946
176F4012
Table 4: IGBT Module Replacement Kits for VLT® FC Series E1h–E4h Drives
Kit number
176F6641
176F6642
176F6643
176F6644
176F6711
176F6646

1.3 Items Supplied

The following parts are contained in the kit.
Table 5: Items Supplied in IGBT Module Kits
Item
IGBT module
Fasteners
Syringe of thermal grease
2 | Danfoss A/S © 2022.03
Description
IGBT module 1200 A 1200 V Fx12
IGBT brake module 450 A 1700 V Fx11
IGBT brake module 450 A 1700 V Fx12
Description
IGBT module 600 A T4/T5
IGBT module 900 A T4/T5
IGBT module 600 A 1700 V T7
IGBT module 650 A 1700 V T7
IGBT brake module 450 A E1, E3
IGBT brake module 450 A E2, E4
Quantity
1
varies depending on IGBT type
1
Overview
AN361427984575en-000101 / 130R0770
