K-array Kommander-KA User Manual page 25

Kommander-KA
User Guide
Kommander-KA18 Kommander-KA28 Kommander-KA68 Kommander-KA208
Type 8ch switching mode, Class D Amplifier
Output Power 8x 150W @ 4Ω 8x 600W @ 4Ω 8x 750W @ 4Ω 8x 2500W @ 4Ω
1
Minimum impedance 4 Ω 2 Ω 4 Ω 4 Ω
Frequency Response 20 Hz – 20 kHz (±1 dB)
Input:
Remote connectivity:
8x XLR-F balanced input
1x Ethernet RJ45
Connectors
4x USB-A
Output:
Wi-Fi IEEE 802.11 b/g/n
4x PC 4/ 4-ST-7,62 speaker output
Input gain, routing matrix, delay, full parametric IIR filters (Peaking, Shelving, Hi/Lo pass, Hi/Lo Butterworth),
DSP
On-board preset, Remote monitoring
Remote control Wi-Fi dedicated APP | K-framework3 via wired Ethernet connection
MAINS Operating Range 100-240V AC, 50-60 Hz with PFC
300 W @ 8 Ω load, 800 W @ 8 Ω load, 1200 W @ 4 Ω load, 1200 W @ 4 Ω load,
Power Consumption
Pink noise, 1/4 rated power Pink noise, 1/4 rated power Pink noise, 1/4 rated power Pink noise, 1/4 rated power
Protections Thermal protection, output short circuit, RMS output current protection, high frequency protection, power limiter, clip limiter.
IP Rating IP20
Dimensions (WxHxD) 430 x 87 x 430 mm (17 x 3,4 x 17 in)
Weight 7 kg (15,4 lb) 7,4 kg (16,3 lb) 8,3 kg (18,3 lb) 10 kg (22 lb)
25
