GPD315 Communication Parameters

Run/Stop and Frequency Selection

The run/stop and frequency reference commands can originate from serial communication, the
digital operator, or the external terminals. The origin of the run/stop command does not have to
be the same as the origin of the frequency reference command. Parameter n003 (Operation
Method Selection) allows you to set up the origin of the run/stop commands. Parameter n004
(Reference Selection) allows you to set up the origin of the frequency reference command. The
charts below illustrate the possible run/stop and frequency reference selections.
Parameter n003 Setting
The default value of parameter n003 is '1'.
Parameter n004 Setting
The default value of parameter n004 is'2'.
GPD315 Modbus RTU Technical Manual TM 4325

Chapter 3

Table 3-1. Run/Stop Selection

0 Digital Operator
1 External Terminals
2 Serial Communication

Table 3-2. Frequency Reference Selection

0 Digital Operator Pot
1 Digital Operator
2 Voltage Reference (0-10V)
3 Current Reference (4-20mA)
4 Current Reference (0-20mA)
5 Pulse Train Reference
6 Serial Communication
7 Multi-Function Analog Input (0-10V)
8 Multi-Function Analog Input (4-20mA)
9 Option Board
Operation Method Selection
Frequency Reference Selection
5
