Springfree O200 Assembly & Installation page 11

DISASSEMBLY
2b
ROD REMOVAL
TECHNIQUE
Outside Person:
Push the mat rod out of the mat rod
holder, guiding the ball along the path
shown.
In one swi movement:
1. Up and forward into the mat
underside, out of the mat rod holder.
2. Down and away from the mat
underside.
3. Back towards you, easing it to a resting
position.
WARNING - Treat any loaded rod with caution until you are sure it is properly
installed or uninstalled. Keep your face well away from any loaded rod.
WARNING - Both people must maintain a steady grip on the rod until it is in its
resting position.
18
Please read before continuing. Do not remove any of
the mat rods yet.
Inside Person:
Pull the mat rod to assist the outside
person in guiding the ball up and out
of the mat rod holder.
Maintain a steady grip until the ball is
securely removed from the mat rod
holder.
DISASSEMBLY
3
MAT ROD REMOVAL
Moving clockwise between the blue
mat rod (remove one, skip one). Do NOT remove the mat rods at the blue
locations.
Repeat the above step (removing every other installed mat rod), several times around
the trampoline, until only the mat rods at the blue
Continue clockwise removing the final mat rods at each of the blue
Pulling the mat edge while pushing the rod will be required to uninstall these rods.
Remove the mat rods from the frame and then pack the net, mat and rods.
Disassemble the frame in the reverse order to which it was assembled.
WARNING - Treat any loaded rod with caution until you are sure it is properly
installed or uninstalled. Keep your face well away from any loaded rod.
NOTE - Following the sequence shown maintains the tension evenly across
the mat. If you do not follow this sequence, it will be very di icult to remove
the mat.
TOP VIEW
tag locations, remove every other installed
tag locations remain.
tag locations.
tag
