SPECIFICATIONS
ZAIR MINI
Model No
POWER SUPPLY
100-240V~50/60Hz
Input
0.3A
Capacity of water tank
360ML X 2
INSTRUCTIONS FOR USE
The Ice Cube can be used with or without water, but for optimum cooling it is recommended to fill the Ice cube water
tanks with water following the instruction below:
Filling the Ice Cube
The ice cube must be switched off and unplugged from the power supply before filling the water tanks.
STEP 1: Open the water tank access doors and pull the water tanks up and away from the Ice Cube.
STEP 2: Remove the filter block by lifting and sliding it sideways out of the ice cube and run it under a steady stream of
cool, clean water so that the filter becomes fully wet. Shake gently to remove the excess and replace the filter block into
the Ice Cube.
STEP 3: Take the water tanks, unscrew the caps and fill them with cool, clean water to the brim. Replace the caps and
slide the water tanks back into position so that they are seated properly. The valves in the caps should begin to release
the water into the Ice Cube. This will fill the reservoir in the base of the unit with water.
STEP 4: Carefully close the water tank access doors
USING THE ICE CUBE
STEP 1: Plug in and switch on the Ice Cube at the desired power supply. Press the power button to turn on the Ice Cube
STEP 2: The desired cooling speed can be selected by pressing
. Cycle through the speeds numbered 1-3, 3 being
the strongest cooling speed. The indicator lights will show the speed selected.
STEP 3: Turn on the mood light by pushing
. Cycle the eight colours by repeatedly pressing
until the desired
colour setting has been selected.
STEP 4: To regulate the direction of the air airflow, manually adjust the horizontal grills on the front of the Ice Cube.
STEP 5: Turn off the Ice Cube by pressing the power button.
Note: Always remove the excess water and allow the ice cube to dry after each use to avoid a build-up of lime scale and
bacteria. The Ice Cube is not designed to significantly reduce the room temperature but will provide a localized cool
breeze for a small space.
When positioning the Ice Cube, do not lift it by the front panel. Keep the Ice Cube level when filled with water to avoid
spills. This is due to the water reservoir which is located in the base of the unit
CLEANING AND MAINTENANCE
1. Always remove the plug from the socket-outlet and allow the fan blower to stop acting before clean it.
2. Clean the external surfaces of the unit with a soft damp (not dripping wet) cloth.
