What You Need - modway Nomad EEI-6204 Assembly Instructions Manual

Read through all of
the instructions
before starting
Approx. 60 minutes
assembly time
2 people recommended
for assembly
Furniture components:
1 Top Board
2 Bottom Board
3 Side Board Left
4 Side Board Right
5 Center Board
6 Adjustable Shelf
7 Door
8 Back Board
Provided hardware:
A Cam Bolt Ø6 x 35 mm
B
Cam Lock Ø15 mm
C Wood Dowel Ø8 x 30 mm
D Screw M 7 x 50 mm
E Screw M 3.5 x 13 mm
F Screw Cap Ø15 mm
G
Allen Key
H Wedge
I Screw M 3.5 x 15.5 mm
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
x1
x1
3
x1
x1
x2
x3
x3
7
x3
x8 J
K
x8
x16 L
x8
M
x24 N
x8 O
x2 LM19A1
x24
x24
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
you're assembling the product.
Keep all components and packaging out of reach of children or animals
1
8
5
6
7
Shelf Pin
Silicon Bumper
Screw M 4.5 x 12.5 mm
Floor Pad
Sliding Top
Sliding Bottom
Leg Hairpin
8
8
6
5
6
7
2

What you need:

x12
x5 Phillips
x24
x6
x6
x6
x6
4
Phillips Head Screwdriver
PAGE 2 OF 8
