X. PARTS LIST AND SCHEMATIC DIAGRAMS
A A A A - - - - REPLACEMENT PARTS LIST REPLACEMENT PARTS LIST REPLACEMENT PARTS LIST REPLACEMENT PARTS LIST
NOTE: SERIAL NUMBER OF VENTILATOR MUST ACCOMPANY ALL PARTS ORDERS
ITEM PART #
1 PRT3348
2 PRT3350
3 PRT3353
4 PRT3354
6 PRT4467
12 PRT3316
13 PRT4410
15 PRT3318
15A PRT3319
16 PRT3322
16A PRT3323
23 EVAL006
29 4419A
30 4419B
32 PFIL008
141 PRT3317
KIT, PREVENTIVE MAINTENANCE (UNITS WITHOUT FLOW SENSOR
AND WITHOUT ENTRAINMENT)
KIT, PREVENTIVE MAINTENANCE (UNITS WITHOUT FLOW SENSOR
BUT WITH ENTRAINMENT)
KIT, PREVENTIVE MAINTENANCE (UNITS WITH FLOW SENSOR BUT
WITHOUT ENTRAINMENT)
KIT, PREVENTIVE MAINTENANCE (UNITS WITH FLOW SENSOR &
ENTRAINMENT)
BATTERY PACK, 6 D CELL NiMH (Do not substitute)
ASSY, LCD/TOUCHSCREEN DISPLAY
LED, ALARM
PC BOARD FOR UNITS WITH FLOW SENSOR- NO DISPLAY INCL'D*
PC BOARD FOR UNITS WITH FLOW SENSOR- DISPLAY INCL'D*
PC BOARD FOR UNITS WITHOUT FLOW SENSOR- NO DISPLAY INCL'D*
PC BOARD FOR UNITS WITHOUT FLOW SENSOR- DISPLAY INCL'D*
SOLENOID
CHARGER w/US HOSPITAL-GRADE CORD (Do not substitute)
CHARGER w/EURO UNTERMINATEDCORD (Do not substitute)
FILTER, CONICAL SUPPLY
PRESSURE SENSING SWITCH
DESCRIPTION
