- Page 1 SATA PASSIVE BACKPLANE USER’S MANUAL P/N : 2RAKVI012000 Model：3TO4 4BAY SATA BP MODULE Version : V1.0 Model : 3TO4 4BAY SATA BP User’s Manual PAGE 1 OF 14...
- Page 2 Revision History Version Changes Date V1.0 Official Release 2022/03/08 Model : 3TO4 4BAY SATA BP User’s Manual PAGE 2 OF 14...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Overview ......................4 Physical Outlook ........................5 Connector Locations and LED Indicators ............ 6 Bottom Connector and Pin Definitions .................. 6 Top Connectors and LED Indicators ..................8 Hardware Specification ................. 9 LED Behavior ....................10 ... -
Page 4: Overview
Overview The backplane is a high performance economical solution for users who has sufficient SAS host ports on MB or RAID/HBA to accommodate 4 disks in the system. The passive backplanes support state-of-the-art SAS 6Gbps HDD/SSD and also backward compatible with SATA 6Gps and SATA 3Gps HDD/SSD. Basically,4 SATA7P connector can support up to 4 disk bays. -
Page 5: Physical Outlook
Physical Outlook TOP VIEW BOTTOM VIEW Model : 3TO4 4BAY SATA BP User’s Manual PAGE 5 OF 14... -
Page 6: Connector Locations And Led Indicators
Connector Locations and LED Indicators Description Description Host facing interface (SATA):SAS1~SAS4 FAN Connector:FAN1 Main Power Connector: WP1/WP2 FAN/TEMP Setting Header:CN1 Firmware Programming Header:JD1 SGPIO header:CN2 Mute_SW Connector:JB1 Alarm Buzzer:SUB1 Bottom Connector and Pin Definitions SAS1~SAS4 Signal Name Pin No. SAS_RX_[p/n] SAS_TX_[p/n] SAS_GND 1/4/7... - Page 7 Firmware Programming Connector Mute Button Connector PIN # Definition PIN # Definition PIN # Definition ICE_CLK Mute_Button + ICE_DATA #Key Mute_Button - ICE_RST Ground FAN/TEMP Setting Header PIN # Definition PIN No# Definition PWM_SET1_- PWM_SET1_+ PWM_SET2_- PWM_SET2_+ TEMP_SET_- TEMP_SET_+ [CN1 Function] [CN1 Function] Setting Function...
-
Page 8: Top Connectors And Led Indicators
Top Connectors and LED Indicators Location SATA Drive Number SAS1~SAS4 SATA Disk #1~#4 SAS1~SAS4 Signal Name Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name Pin No. SAS0Tx[p/n] S2/S3 SAS0Rx[p/n] S5/S6 SAS1Tx[p/n] S9/S10 SAS1Rx[p/n] S12/S13 SAS_GND S1/S4/S7/S8/S11/S14 Power_GND P4/P5/P6/P10/P12 +3.3V&Charge... -
Page 9: Hardware Specification
Hardware Specification HOST Interface ：SATA-7P Hard Disk (SSD) Interface ：SATA/SAS Indicator ： Power LED (LED1~LED4) : Blue –(When HDD is resent) Dual color(Green/Red) LED D1~D4 for Hard Disk Drive Status (Activity/Fail/Locate) Activity LED: Green (When HDD is Access) ... -
Page 10: Led Behavior
LED Behavior Disk Bay LED Blue LED: Disk Insertion Indicator – Turned on whenever disk drive is properly installed. Green LED: Activity indicator – Stay off when idle and blinking (~8 Hz) whenever disk drive is being accessed. RED LED: Fail and Locate indicator –... -
Page 11: Smart Fan Speed Control
Smart FAN Speed Control IN WIN’s Backplane is designed with Smart Fan Control feature by automatically detecting the existences of the Fan Modules and intelligently control the Fan RPM per the system temperature being detected by single thermal sensor on the backplane. Model : 3TO4 4BAY SATA BP User’s Manual PAGE 11 OF 14... -
Page 12: System Alarm
IN WIN’s Backplane is implemented Smart Fan Control feature by automatically detecting the existences of the Fan Modules and intelligently control the Fan RPM per the system temperature being detected by a thermal sensor (RT1) on the backplane. Thanks to Smart Fan Control feature the Fan connector (FAN1) on backplane support wide variety of PWM driven Fan modules being used in the enclosure. -
Page 13: Firmware Upgrade
Firmware Upgrade The passive backplanes are planted Nuvoton M058 series MCUs for hosting disk LED indication, Fan speed control and system fail alarm. These MCUs are preprogrammed in manufacturing. In most cases, the MCUs are not required to reprogram unless there is issue needed to fix. - Page 14 3. Make sure device is connected and select the binary file being programmed and then click on Start button to program firmware. 4. Please refer to http://www.nuvoton.com/resource- files/NuLink_Adapter_User_Manual_EN_V1.01.pdf for more details. Model : 3TO4 4BAY SATA BP User’s Manual PAGE 14 OF 14...
