Summary of Contents for InWin PF Series

  • Page 2 Product Story High-Performance Without Compromise The PF Series is an 80 PLUS® Gold certified power supply with up to 90% efficiency. It features a powerful single +12V rail design and multi-protection safeguards, which can provide reliability and great performance for high-end components. The PF Series offers high- performance without compromise, a great option for budget builds.
  • Page 3: Specifications

    Max. Output Current 54.2A 0.3A P65F 650W Max. Combined Power 650W 120W 3.6W Max. Output Current 62.5A 0.3A P75F 750W Max. Combined Power 750W 120W 3.6W * InWin products comply with RoHS regulations. * Specifications may vary based on different regions.
  • Page 4: Package Contents

    Package Contents PF Series Power Supply Unit x1 (P55F / P65F / P75F) Mounting Screws x4 Power Cord x1 Cable Ties x8 QR Code Card x1...
  • Page 5: Cable Information

    Cable Information 24(20+4) Pin Motherboard 8 Pin CPU 4 Pin CPU 8(6+2) Pin PCI-E SATA(90 Degree) 4 Pin Peripheral...
  • Page 6: Installation

    Installation Make sure the power supply’s AC power cable is not connected before installation. Place the power supply unit into the space provided in the case and secure the power supply unit with the screws. Connect 24-pin power to the 24-pin socket on the motherboard.
  • Page 7: Troubleshooting

    Troubleshooting These troubleshooting points will help you diagnose and solve problems with your power supply if the unit fails to operate properly: Please make sure the power supply and power cord are connected properly. Please make sure the power cord is plugged into the power socket.
  • Page 8 Notices and Warranty Notices Install in accordance with the user manual’s instructions and safety warnings. Incorrect installation may burnout the motherboard and other system components. To avoid damaging any circuits, please make sure the power is off before assembling any internal device.
  • Page 9: Warranty

    Notices and Warranty Warranty InWin provides a 5-year warranty toward the product. The warranty covers malfunctions or flaws before customer use. The warranty starts from your initial purchase (according to the date on your receipt). Please note that we do...
  • Page 10 Copyright © 2020 In Win Development Inc. All Rights Reserved.
