Thank you for purchasing a Franklin Electric Centrifugal
pump. It is to be used with non-volatile, non-fl ammable
liquids with specifi ed entrained solids, except as approved
by the factory.
This manual provides installation, operation and main-
tenance instructions for your Franklin Electric pump
and is intended to make your personnel aware of any
procedure that requires special attention because of
potential hazards to personnel or equipment.
Read all instructions carefully and remember, pump in-
stallations are seldom identical. Therefore, this manual
cannot possibly provide detailed instructions and precau-
tions for each specifi c application. Thus, it is the owner/
installer's responsibility to ensure that applications not
addressed in this manual are performed only after estab-
lishing that neither operator safety nor pump integrity are
compromised by the installation.
Centrifugal pumps are designed for specifi c service and
may or may not be suited for any other service without
loss of performance or potential damage to equipment
or personnel. If there is ever any doubt about suitabil-
ity for a specifi c purpose, contact your Franklin Electric
representative.
REMEMBER: Pump performance may be affected by
changes in pumpage, including specifi c gravity, viscosity,
temperature, operating speed and NPSHA (net positive
suction head available).
STANDARD CENTRIFUGAL
SERIES
OWNER'S MANUAL
READ AND FOLLOW SAFETY INSTRUCTIONS
This is the safety alert symbol. When you see this
symbol on your pump or in this manual, look for one
of the following signal words and be alert to the potential
for personal injury:
D A N G E R
serious personal injury, death or major property damage
if ignored.
W A R N I N G
serious personal injury, death or major property damage
if ignored.
C A U T I O N
minor personal injury or major property damage if ignored.
The label NOTICE indicates special instructions, which
are important but not related to hazards.
Carefully read and follow all safety instructions in this
manual and on pump.
Keep safety labels in good
condition.
Replace missing or damaged
safety labels.
Wire motor for correct
voltage.
Ground motor before
connecting to power supply.
INSPECTION
All equipment is inspected at
the factory prior to shipment.
However, you should inspect
all equipment upon arrival for
shipping
shortages from the packing slip.
Report any damage or shortages to the carrier.
RECORDING MODEL & SERIAL NUMBERS
Please record the model and serial number for your
Franklin Electric pump.
Pump Model:
Pump Serial #:
Engine/Motor Serial #:
Engine/Motor Model Mfg.:
warns about hazards that will cause
warns about hazards that can cause
warns about hazards that will or can cause
damage
and
item
WA R N I N G
Hazardous voltage.
Can shock, burn, or
cause death.
Ground pump before
connecting to power
supply. Disconnect
power before working
on pump, motor
or tank.
