- Page 1 VUL-6804-25-BBZ Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2023, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • 813.978.3700 - 1 -...
- Page 2 INSTALLATION INSTRUCTIONS VOLT Wide Splash R7S Brass Underwater Light (Bronze) ® VUL-6804-25-BBZ Important: Please Read Before Installation This fixture is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 Important Safety Instructions LIGHTED LAMP IS HOT! WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS. 1. Turn off/unplug and allow to cool before reducing lamp. 2. Lamp gets HOT quickly! 3. Do not touch the hot lens, guard or cowl. 4.
- Page 4 INSTALLATION INSTRUCTIONS VOLT Wide Splash R7S Brass Underwater Light (Bronze) ® VUL-6804-25-BBZ Remove Lens and Reflector Fixture Body Screw Reflector Small Allen Lens Wrench Cover Use the Small Allen Wrench to loosen the screws on the cover to remove the cover, the lens and the reflector from the fixture body.
- Page 5 Install Lens and Reflector Fixture Body Screw Lens Small Allen Cover Reflector Wrench Place the reflector, the lens and the cover back onto the fixture body and secure with previously removed screws. Hand tighten until snug with Small Allen Wrench. Install Horseshoe Mount Attach the horseshoe mount to the desired location and mark...
- Page 6 INSTALLATION INSTRUCTIONS VOLT Wide Splash R7S Brass Underwater Light (Bronze) ® VUL-6804-25-BBZ Wire Connection Wire Connectors Supply Cables from Fixture Body Main Supply Cable Pigtail Strip both leads from the luminaire pigtail. Using two UL listed wire connectors (sold separately), connect the leads from the fixture body to the main supply cable leads.
- Page 7 Install/Replace R7S Bulb Reverse step 1 - step 3 to remove the cover, the lens and the reflector to expose the R7S bulb and replace it with the correct wattage and type marked on the fixture label. Then, reinstall the reflector, the lens and the cover.
