- Page 1 INSTALLATION INSTRUCTIONS VOLT LOW VOLTAGE LANDSCAPE LIGHTING ® VOLT Mini Brass RGBW Underwater Pond Lights ® ITEM: VUL-6704 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
-
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS VOLT Mini Brass RGBW Underwater Pond Lights - VUL-6704 ® IMPORTANT: PLEASE READ BEFORE INSTALLATION This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty. -
Page 3: Package Contents
PACKAGE CONTENTS A. (1) Fixture Body PRODUCT DIMENSIONS 2.15” 1.3” 1.3” 1.89” 2.17” 2.42” WIRE CONNECTIONS Main Supply Cable Wire Connector (Sold Separately) Fixture Body Pigtail Place fixture body on your desired location. Strip both leads from luminaire pigtail. Using two UL listed wire connectors (sold separately), connect the leads from the luminaire to main supply cable leads. - Page 4 INSTALLATION INSTRUCTIONS VOLT Mini Brass RGBW Underwater Pond Lights - VUL-6704 ® RGBW IR REMOTE CONTROLLER INSTRUCTIONS RGBW IR Remote Controller is suitable for this fixture. Refer to the following instructions for the remote controller. If the fixture is placed in deep water, it will need to be removed in order for the remote to work properly.
-
Page 5: Ir Remote Functions
IR REMOTE FUNCTIONS 1. On 2. Off 3. Brightness Control 4. 16 color selections 5. Flash • Mode 1: Repeats Red, Green, Blue + color cycle for 1 second duration of each of the seven colors within this FLASH mode. STROBE • Mode 2: Hit flash a second FADE time and this mode slowly blends the same seven... - Page 6 INSTALLATION INSTRUCTIONS VOLT Mini Brass RGBW Underwater Pond Lights - VUL-6704 ® 813.978.3700 • customersupport@voltlighting.com • www.voltlighting.com...
