Single Channel Video Transmit Unit for a Multimode Optical
The AMG5611R is a compact standalone one channel video transmit unit designed to transmit 1 video
signal over a Multimode optical fibre.
The AMG5611R is designed to plug into an AMG2005 or AMG2009 subrack, which in turn fits into a
19" rack system.
The AMG5611R is designed to operate with an AMG5612 / AMG5612R single channel or AMG5622 /
AMG5622R dual channel video receive unit in a point to point configuration. The R suffix in the partno.
indicates a rackmount configuration.
AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Fibre Link
Page 1 of 8
AMG5611R
Instruction Manual
AMG5611R Instruction Sheet D17157-
02.doc
Advertisement
Table of Contents
Related Manuals for AMG AMG5611R
Summary of Contents for AMG AMG5611R
- Page 1 The AMG5611R is a compact standalone one channel video transmit unit designed to transmit 1 video signal over a Multimode optical fibre. The AMG5611R is designed to plug into an AMG2005 or AMG2009 subrack, which in turn fits into a 19" rack system.
- Page 2 Dimensions ............................6 Mounting Details ..........................6 Safety Maintenance and Repair AMG Systems Ltd. reserves the right to make changes to this Page 2 of 8 AMG5611R Instruction Sheet D17157- document without notice. The information herein is believed to 02.doc...
- Page 3 The AMG5611R transmits 1 video signal to the AMG5612 receive unit. Optical Connection The AMG5611R connections are illustrated in the following example which shows a AMG5611R transmit unit together with an AMG5612R single channel rackmount receive unit configured as a point to point system.
- Page 4 Power Connection Power supply ........From plug in connection on the AMG2009 or AMG2015 subrack Power consumption ......1.5 Watts max. AMG Systems Ltd. reserves the right to make changes to this Page 4 of 8 AMG5611R Instruction Sheet D17157- document without notice. The information herein is believed to 02.doc...
- Page 5 Video input. Unit powered, no Video input. No power applied to unit AMG Systems Ltd. reserves the right to make changes to this Page 5 of 8 AMG5611R Instruction Sheet D17157- document without notice. The information herein is believed to 02.doc...
- Page 6 There are no user serviceable parts within AMG products. See unit data sheet for full specification. In case of problem or failure, please call your local support centre or contact: AMG Systems Ltd. at 3 The Omega Centre, Stratton Business Park, Biggleswade, Beds., SG18 8QB, UK.
- Page 7 This page is intentionally blank. AMG Systems Ltd. reserves the right to make changes to this Page 7 of 8 AMG5611R Instruction Sheet D17157- document without notice. The information herein is believed to 02.doc be accurate. No responsibility is assumed by AMG for its use.
- Page 8 This page is intentionally blank. AMG Systems Ltd. reserves the right to make changes to this Page 8 of 8 AMG5611R Instruction Sheet D17157- document without notice. The information herein is believed to 02.doc be accurate. No responsibility is assumed by AMG for its use.
