Specifications Of Your Excel Outback; Components Of Your Excel Outback; The Dashboard - Excel Outback User Manual

4.

Specifications of your Excel Outback

Seat width
53 cm
Seat height
44 cm
Maximum
user weight
200 kg
*= indicative, measured under ideal conditions.
5.

Components of your Excel Outback

This chapter describes the various components of the Excel Outback. The scooter has a number of components that
are adjustable and adjustable. If you want to install, remove, adjust or move any of the components, always follow the
instructions described in this user manual.
5.1

The dashboard

The Excel Outback is equipped with a well-arranged dashboard. As you can see, the dashboard consists of different
components, each of which has its own function. The various components are explained in more detail below:
5
1. Speed Buttons
With these two buttons you can set the desired speed. By pressing the right button, with the hare icon, you increase the
speed. This can be seen by the increasing dashes on the right side of the display, press 1 dash at a time. To decrease
the speed, press the left button with the turtle icon. Then the dashes on the right of the display decrease, press 1 dash
at a time.
Seat depth
48 cm
Total height
169 cm
Total weight
192/208 kg
6
7 9
1
3
8
2
9
Total width
78 cm
Batteries
90/120 Ah
Max, speed
15/20 km/u*
7
1
4
2
9
Totale length
147 cm
Charger
8 Ah
Range
tot 54 km*
5
