Summary of Contents for Excel Outback
- Page 1 Excel Outback User Manual...
-
Page 2: Table Of Contents
2.1.1 Components and constrction of your scooter 2.2 General explanation about your scooter 3. Safety regulations 3.1 General safety instructions 3.2 Safe use warnings 4. Specifications of your Excel Outback 5. Components of your Excel Outback 5.1 The dashboard 5.2 The steering column 5.3 The armrests 5.4 The battery... - Page 3 7.6 Maintenance schedule 8. Problem analysis and solutions 9. Warranty 9.1 Warranty application 9.2 Warranty conditions...
-
Page 4: General Introduction
At this moment you are introduced to a quality product offered by Van Os Medical B.V. We would like to thank you for your confidence in our Excel Mobility ® brand. An Excel Outback is a real quality product. The policy of Van Os Medical B.V. - Page 5 Enter the details of your authorised dealer and product below: Company Name: …………………………………………………………………………………………………………… Address: …………………………………………………………………………………………………………… Telephone number: …………………………………………………………………………………………………………… Fax number: …………………………………………………………………………………………………………..Email address: …………………………………………………………………………………………………………..Website: …………………………………………………………………………………………………………… Date of purchase: …………………………………………………………………………………………………………… If applicable, stamp or sticker from your authorised dealer: If, in addition to the frame label on the product, there is a second separate frame label with your product, you can place it below so that you can consult it more easily later:...
-
Page 6: Identification
The information on the label of your scooter corresponds to your scooter. Van Os Medical B.V. is the importer of this Excel Mobility product. The product is manufactured by Quality Life Technologies. and European represented by Wellkang LTD. -
Page 7: General Information
General explanation about your scooter Your new Excel Outback is a scooter designed to offer maximum comfort. The comfortable chair can be adjusted as desired and contributes to optimal seating comfort. The scooter is equipped with LED lighting and brake lights. -
Page 8: Safety Regulations
Safety regulations If the rules of handling as described in this user manual are followed, the Excel Outback is an extremely safe and stable product. However, it is possible that dangerous situations can arise if the scooter is not used correctly. Van Os Medical B.V. -
Page 9: Specifications Of Your Excel Outback
Components of your Excel Outback This chapter describes the various components of the Excel Outback. The scooter has a number of components that are adjustable and adjustable. If you want to install, remove, adjust or move any of the components, always follow the instructions described in this user manual. - Page 10 You can sound the horn by pressing one of these buttons. When you use the horn, you will hear a beep sound. The Excel Outback has a horn button on both the left and right side of the dashboard, so that you can press it with either the left and right hand.
-
Page 11: The Steering Column
The steering column The steering column of the Excel Outback can be easily adjusted in angle. Adjusting the steering column to the desired angle improves driving comfort. You can adjust the angle of the steering column by following the steps below;... -
Page 12: The Battery
EXCEL OUTBACK | Photo 16 Warning Only use the charger supplied by Excel Mobility. Using any other charger will void the warranty. A different charger can also damage the batteries of your scooter. The seat The Excel Outback features a comfortable, height- adjustable, 360-degree swivel seat with headrest. -
Page 13: The Freewheel
The freewheel The Excel Outback has two positions, namely the driving position and the freewheel position. On the sticker next to the freewheel lever, the driving position is indicated by a picture of a person riding the scooter (A). The freewheel position is indicated by a picture of a person walking next to the scooter and pushing it forward (B). -
Page 14: The Wheels
Your scooter is equipped with four pneumatic tyres. You should check the tyre pressure regularly. You can do this using a (digital) tyre pressure gauge. Excel Mobility uses a tyre pressure of 2.5 bar per tyre. More information about maintaining the pneumatic tyres can be found in paragraph 7.1.1... -
Page 15: User Instructions
User instructions It is important that you educate yourself on the correct, safe user instructions. To do this, you must be familiar with all the scooter components described in this user manual. Always consult a professional for assistance in developing proper, safe methods of use in relation to your physical ability to operate the scooter. -
Page 16: Going Up Or Down Elevations
Going up and down elevations It may happen that you have to go up or down a elevation with your scooter. In this user manual we first describe how you can do this independently. 6.3.1 Going up an elevation and or slope If you want to go up an elevation and or incline, do so in a forward motion. -
Page 17: Control
This is how you turn on the scooter. To turn the Excel Outback off, for example when you want to get off, turn the key a quarter turn counterclockwise, which brings the key into a vertical position. -
Page 18: Emi / Rfi Recommendations
All electric vehicles, including mobility scooters, are susceptible to Electromagnetic Interference / Radio Frequency Interference (RFI). This can result in abnormal and unexpected movement of your scooter. If unintentional movement occurs or the brake does not work properly, turn your scooter off as soon as possible. The FDA has determined that every scooter must be able to withstand EMI/RFI to a certain level. -
Page 19: Maintenance
Preventative maintenance is therefore very important. We recommend that you have your scooter checked by a qualified Excel Mobility dealer at least once a year. This dealer will only use Excel replacement parts where necessary. This annual inspection will contribute to a long life for your scooter. -
Page 20: Cleaning Your Scooter
Maintenance schedule For an optimal lifespan of your scooter, we recommend that you have your scooter checked by an authorised Excel Mobility dealer at least once a year. The maintenance schedule in the supplied maintenance booklet must be used. The intensity of use of the scooter can vary greatly from person to person. - Page 21 Problem analysis and solutions There may be problems while using your Excel scooter. The fault diagnosis system below indicates what is going on by means of a fault code. This fault code is expressed in a number of beep signals. This means that your scooter gives a number of beeps, the lights flash at the same time and at the top of the display of the dashboard is a wrench symbol.
- Page 22 Furthermore, if a problem occurs, you must immediately notify the relevant Excel Mobility dealer and fully inform them of the nature of the problem. If you use the scooter outside the area of the designated Excel Mobility dealer who must perform the warranty, the work can be performed at any other dealer designated by the factory.
- Page 23 Excel Mobility dealer. The warranty is only valid during the specified period and is only valid in the Netherlands. If adjustments have been made to the scooter that have a structural influence on the product, the warranty will become void in full.
- Page 24 Van Os Medical B.V. Koperslagerij 3 4651 SK, Steenbergen (NB) Nederland +31 (0) 167 57 30 20 * info@vanosmedical.nl : www.vanosmedical.nl Quality Life Technologies Co. Ltd. No. 5, Lao Fu Wu Road, Huang Wu Industrial District, Dongkeng Town, Dongguan, Guangdong, China Wellkang LTD, Enterprise Hub EC REP NW Business Complex 1, Beraghmore Rd.
