- Page 1 XCEL EXCEL EXCEL EXCEL EXCEL EXCEL EXCEL User Manual Excel Galaxy Plus...
- Page 2 User Manual BEFORE USE YOUR NEW GALAXY PLUS SCOOTER YOU AND / OR YOUR ATTENDANT MUST READ AND FULLY UNDERSTAND THIS MANUAL. General information You have just purchased a Van Os Medical B.V. scooter and we want to thank you for the confidence in our EXCEL®...
- Page 3 User Manual Fill out the information on your authorized dealer below: Company: ………………………………………………………………… Address: ………………………………………………………………… ………………………………………………………………… Telephone number: ………………………………………………………………… Fax number: ………………………………………………………………… Email address: ………………………………………………………………… Website: ………………………………………………………………… ~ 2 ~ © 2013 VAN OS MEDICAL B.V., Koperslagerij 3, 4651 SK, Steenbergen, The Netherlands Tel.
-
Page 4: Table Of Contents
User Manual IDENTIFICATION ......................4 GENERAL EXPLANATION CONCERNING YOUR SCOOTER ..........5 2.1 C ....................5 OMPONENTS OF THE SCOOTER 2.2 G ........6 ENERAL EXPLANATION OF THE FUNCTION AND POSSIBILITIES OF YOUR SCOOTER SAFETY REGULATIONS ....................6 3.1 G ....................6 ENERAL SAFETY REGULATIONS 3.2 W ......................6 ARNINGS FOR SAFE USE... -
Page 5: Identification
User Manual IDENTIFICATION Your Galaxy plus scooter is equipped with a unique identification number. You can find this number on the frame of your scooter. Below is an example of the frame label on which you can find the identification number. Furthermore you will find the explanation of the various data stored on the frame label listed below. -
Page 6: General Explanation Concerning Your Scooter
User Manual GENERAL EXPLANATION CONCERNING YOUR SCOOTER 2.1 Components of the scooter Mirror Rear fender Steer/ Battery socket Rear shroud Ignition key Rear light Basket Freewheel lever Tiller lever adjustment Armrest reflector Front light Armrest adjustment knob Front cover Armrest Front bumper Seating Front wheel... -
Page 7: General Explanation Of The Function And Possibilities Of Your Scooter
Excel scooter is not used correctly, dangerous situations may occur. 3.1 General safety regulations Protect your Excel Galaxy Plus scooter by checking it regularly. When a part of your Excel scooter is not functioning properly, a dangerous situating could occur. Warning: ... -
Page 8: Instructions For Use
INSTRUCTIONS FOR USE Your Excel Galaxy Plus scooter is a battery working personnel mobility vehicle. Before you take your first trip, you should familiarize yourself well with the operation of the vehicle and with all operating elements. Take your time to test all functions and driving modes. -
Page 9: Control Units
User Manual 4.1 Control units Speed button Horn Battery indicator Emergency Horn light Lever Lever Big light Indicator right Indicator left Turtle knob Controle panel: Speed button With the speed button you can adjust the minimum and maximum speed; Turn the knob against the clock for lower speed;... - Page 10 User Manual Brakes and throttle lever Whenever the speed engager lever is moved out of the neutral position, the electromagnetic brake will automatically release and your scooter will move. When the speed engager lever is released, it will return to the neutral position and the scooter will decelerate and come to a complete stop.
-
Page 11: Getting On And Off
User Manual 4.2 Getting on and off your scooter Warning: When getting on or off your scooter, keep your weight toward the middle of the deck. Putting most or all of your weight on the edge of the deck may cause an unstable condition! Before getting on your scooter Check to be certain that the power is turned off. -
Page 12: Basic Driving
User Manual To get on your scooter: Stand behind your scooter; Place the scooter in Drive;(Picture 1) Make certain that the seat is positioned for safe and easy use; Position yourself in the seat; Use the seat rotate lever to position the seat so that it is locked in the fully ... -
Page 13: Steering
User Manual 4.5 Steering Place both hands on the handgrips of the tiller, turn the tiller to the right to travel to the right; Turn the tiller to the left to travel to the left; Make certain to maintain sufficient clearance when turning your scooter so that ... - Page 14 User Manual Ramps When proceeding up any ramp, curb, or incline: Lean forward in your seat to move your centre of gravity forward for maximum stability and safety. If the ramp has a switchback, good cornering ability is required: Manoeuvre your scooter so that the front wheels take wide swings around the ...
-
Page 15: Going Up An Incline / Down A Decline
User Manual 4.7 Going up an incline / down a decline Driving on inclines For maximum stability, lean forward in your scooters seat while proceeding up ramps, inclines, curbs, or any low rise; Drive with caution when attempting to drive up to any incline, even handicap ... -
Page 16: Emi / Rfi
User Manual Procedure 1: Under power Set the key switch to the “Off position”; Dismount your scooter; Set the key switch to the “On position”; While standing next to your scooter, carefully operate the controls at the lowest ... - Page 17 User Manual Warning: Unintended movement or brake release could cause an accident or injury. The FDA has determined that each make and model of scooter can resist EMI/ RFI to a certain level. The higher the lever of resistance, the greater the degree of protection from EMI/ RFI –...
-
Page 18: Instructions For Use And Mounting Options
User Manual MAKING ADJUSTMENTS TO YOUR SCOOTER CAN CAUSE BIG RISKS FOR YOUR SAFETY AND THE FUNCTION OF YOUR SCOOTER. ADJUSTMENTS MADE BY YOURSELF ARE STRONGLY ADVISED AGAINST AND CARRIED OUT AT YOUR OWN RISK. INSTRUCTIONS FOR USE AND MOUNTING OPTIONS 5.1 Technical information Total length 140 cm... -
Page 19: Armrest Adjustments
User Manual 5.2 Armrest adjustments Armrest width adjustment To adjust the armrest width: Loosen the adjustment knobs at the rear of the seat; (Picture 2) Slide the armrests in or out to the desired width; (Picture 3) Tighten the adjustment knobs. ... -
Page 20: Seat Adjustments
User Manual Loosen the adjustment knobs at the rear side of the armrest; (Picture 5) Slide the armrests up or down to the desired height; Tighten the adjustment knobs. Picture 5 5.3 Seat adjustments Seat rotation lever The seat swivel lever (on the side of the seat) allows the seat to rotate in 45º. -
Page 21: Tiller
User Manual 5.4 Tiller Tiller position adaption You can adjust the position of the tiller of your scooter: Hold with one hand the tiller, while you move the lever; (Picture 7) Place the tiller into the desired position; Move the lever up again;... -
Page 22: Assembly
Warning: Always make sure the seat is correct locked. TRANSPORT AND TRANSIT IN CAR Your Excel scooter is designed to be transported by every car with a approved transport system. CARE AND MAINTAINANCE Routine maintenance The scooter is virtually maintenance free. All of the bearings on your scooter are permanently lubricated and sealed. -
Page 23: Problem Analysis And Solutions
If you are not going to use the scooter for more than a week, fully charge the batteries and then disconnect them from the scooter. Picture 9 PROBLEM ANALYSIS AND SOLUTIONS Your Excel Galaxy Plus scooter is inspected and adjusted so that you can use it immediately. Number of lights Meaning Battery needs recharging... -
Page 24: Warranty
WARRANTY 9.1 Warranty application Together with your Excel Galaxy Plus scooter you get the factory warranty. This warranty is only granted to you as the consumer. It is not intended to be used commercially (like hiring or institutional use). The warranty is limited to defects to materials and possible hidden shortages. -
Page 25: General Maintenance Instructions
While this manual is created with care it is not exclusive. The warranty is only valid during the indicated period. If adjustments are made to the Excel Galaxy Plus scooter, which have structural impact on the product, the warranty will expire completely. - Page 26 User Manual Product identification Product: Electrically powered wheelchairs, scooters and their chargers Brand: Excel Model/type: Galaxy Plus Version: Manufacturer: Name Van Os Medical B.V. Address Koperslagerij 9 4651 SK Steenbergen Country The Netherlands EU Representative: Name W. van Os Address...
- Page 27 Van Os Medical UK Ltd. Excel House Escrick Business Park Escrick, York YO19 6FD Tel.+44 (0) 1904 720170 Fax. +44 (0) 1904 720398 E-mail: sales@vanosmedical.com www.vanosmedical.com...
