EA520 Wearable Kit
How to Attach the Wearable Kit
Slide the EA520 terminal from top to bottom, then press
down to secure in place.
Note:
You can use the single slot USB/charging cradle
or USB Type-C cable without removing the wearable kit
after removing the detachable part on the single slot
cradle
Quick Start Guide
V1.3
Package
Please make sure the following contents are in the
EA520 wearable kit gift box.
If something is missing or damaged, please contact
your unitech representative.
The Package Contents
• EA520 Wearable Kit with bracket, strap and pad
(PN#3210-900032G)
Wear On
Wear on the wrist holder kit, then you can start your
mobility work.
Note:
Make sure the barcode engine is facing the front.
Wearing on the left arm
Wearing on the right arm
Adjust the Wearable Kit
You can adjust the wearable kit according to your wrist
circumference by opening either side of the strap.
Advertisement
Related Manuals for Unitech EA520
Summary of Contents for Unitech EA520
- Page 1 Quick Start Guide V1.3 Wear On How to Attach the Wearable Kit Slide the EA520 terminal from top to bottom, then press Wear on the wrist holder kit, then you can start your down to secure in place. mobility work.
- Page 2 1. Push the button up. 2. Use your thumbs and push the EA520 terminal on its yellow part, until the terminal completely detaches from the boot case.
