X304 Quick Start Guide
LOG INTO THE GATEWAY
Note: The DHCP client must be enabled on your computer to obtain a
valid IP address from the gateway. Refer to your computer's operating
system documentation if you need details.
To connect using Wi-Fi: In the computer's Wi-Fi network settings, select
the gateway's Wi-Fi access point SSID and click Connect. Enter the default
WPA/WPA2 key when prompted.
To connect using Ethernet: Attach one end of a Cat 5 cable to the unit's
LAN port and the other end to the computer's LAN port.
1. To log into the Web Admin interface, open a web browser and type
the unit's LAN IP address, 192.168.1.1, in the URL field.
2. On the first login, enter the root user name and password. It will
prompt you to change all passwords at once.
Note: Change the initial password for both the root and admin users
before configuring the gateway.
QUICK SETUP
To configure the network interfaces:
1. Log into the Web Admin interface and click the Quick Setup menu.
2. Click the Quick Setup button to display the Network Setup page,
where you can configure the LAN, Cellular, and Wireless LAN
(access point) network interfaces.
3. To configure the cellular connection, scroll to the Cellular section.
On the General Settings tab next to SIM to use, select Embedded
SIM or External SIM as the primary SIM to use. If External SIM is
selected, click the External SIM settings tab and configure it.
4. Click Save & Apply. If you changed the LAN address, select and click
Apply unchecked to avoid rolling back the configuration.
Note: Use the Lantronix Connectivity Services SIM Management Portal
to manage the provided SIM card.
ACTIVATE YOUR LANTRONIX SERVICES
1. Open the camera app on your smartphone and point
it at the QR code.
2. Tap the notification to open the link associated with
the QR code.
3. Complete the enrollment form to register the device.
© 2023 Lantronix, Inc. Lantronix is a registered trademark of Lantronix, Inc. All other trademarks are the property of their respective
owners. Specifications subject to change without notice. 895-0052-00 Rev. A
Default Credentials
Access Point SSID
Parameter Default Value
SSID Lantronix-<model>-<serial-number>
WPA/WPA2 Key W1rele$$
Web Admin Console
User name Default Password
admin admin
root L@ntr0n1x
Lantronix Support
For support links and the latest firmware and
documentation, visit
https://www.lantronix.com/technical-support
2
