WARNING
To avoid damage from the electronic fuel injection system, do not remove or install the
battery when the ignition switch is in the "
" position.
The long-term storage of the vehicle could cause fuel and engine oil deterioration and
probably get into a non-start situation.
Service more frequently when operating in severe conditions such as dusty area, high
speed riding, frequent start and stop or extreme riding habit.
Make sure to keep away from any flammable materials such as dry grasses or leaves,
avoid them in contact with the exhaust pipe or muffler when parking the vehicle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PEOPLE S 50 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KYMCO PEOPLE S 50

Summary of Contents for KYMCO PEOPLE S 50

  • Page 1 WARNING To avoid damage from the electronic fuel injection system, do not remove or install the battery when the ignition switch is in the " " position. The long-term storage of the vehicle could cause fuel and engine oil deterioration and probably get into a non-start situation.
  • Page 2 Read this Manual carefully This Owner's Manual contains important information on safety, operation and maintenance of KYMCO PEOPLE S 50/125/200. Anyone who is going to ride should carefully read and understand the contents of this manual before riding. For personal safety, understand and follow all of the warnings contained in this Owner's Manual and the labels attached on vehicle.
  • Page 3 R e c o r d t h e Ve h i c l e I d e n t i f i c a t i o n , Engine Serial Number Number , in the blanks above for a reference to assist you in ordering parts from the authorized KYMCO dealer or in case the vehicle is stolen.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SECTION 1–SAFETY INTRODUCTION...1 SECTION 4–MAINTENANCE....26 Maintenance Schedule......27 Forward..........1 Engine Oil..........30 Scooter Safety.........2 Engine Oil Replacement......31 Accessories & Modifications.....4 Transmission Fluid Change ......32 Locations of Parts & Controls....5 Air Filter Element Change ......33 Throttle Operation........34 SECTION 2–CONTROLS &...

  • Page 5: Section 1-Safety Introduction

    SECTION 1 - FORWARD & SAFETY INTRODUCTION Thanks for purchasing this KYMCO PEOPLE S 50/125/200, and welcome to the KYMCO family. Please read this owner's manual carefully before riding so that you will be thoroughly familiar with the proper operation of controls, features, capabilities, and limitations.

  • Page 6: Scooter Safety

    SCOOTER SAFETY Keep the vehicle in safe condition IMPORTANT SAFETY INFORMATION It will be used with pleasure for a longer time For safe riding, it's important to inspect the if you take responsibility for your safety and vehicle before every ride and perform all understand the challenges that you could face recommended maintenance.
  • Page 7 SCOOTER SAFETY PROTECTIVE CLOTHING For your safety, always wear an approved The recommended riding gears: scooter or scooter helmet, eyes protection, ①Wear gloves boots, gloves, long pants, and a long-sleeve ②Clothes that fit properly shirt or jacket during a ride. ③A helmet with eye protection Helmets and protection ④Bright or reflective clothing...

  • Page 8: Accessories & Modifications

    The addition of unsuitable accessories can lead to unsafe operation. It is not possible for KYMCO to test each accessory on the market or combinations of all the available accessories; however, the KYMCO dealer can assist you in selecting quality accessories and then install them correctly.
  • Page 9 LOCATION OF PARTS & CONTROLS Rear Brake Lever Headlight Front Left Turn Signal Light Fuel Filler Cap Helmet Hook Side Stand(with cut off feature) Seat Engine Number Air Cleaner Rear Left Turn Signal Light Tail/Brake Light Luggage Box NOTE: Your scooter may differ slightly in appearance from the images in this manual.
  • Page 10 LOCATION OF PARTS & CONTROLS Reflector Right Turn Signal Light Muffler Oil Filler Cap/dipstick Center Stand Rear Passenger Foot Peg Right Turn Signal Light Front Brake Lever Electric Starter Button Ignition Switch Vehicle Identification Number (VIN) NOTE: Your scooter may differ slightly in appearance from the images in this manual.
  • Page 11 LOCATION OF PARTS & CONTROLS Right Rearview mirror Left Rearview mirror Right Turn Signal Light Left Turn Signal Light Battery NOTE: Your scooter may differ slightly in appearance from the images in this manual.

  • Page 12: Section 2-Controls & Features

    SECTION 2 - CONTROLS&FEATURES With the ignition key in the " " position IGNITION SWITCH (the engine is not running), turn the To operate the ignition switch and its functions: counterclockwise from the " " to the " " position. “...

  • Page 13: Security Shutter

    CONTROLS & FEATURES SECURITY SHUTTER To open the ignition switch security shutter : Push the shut button on the ignition switch panel to close the security shutter. To shut the ignition switch security shutter : 1.Insert the specific key until the notch aligned with the pin 2.Turn clockwise to open the security shutter.

  • Page 14: Instruments

    CONTROLS & FEATURES INSTRUMENTS MODE Button ADJ Button...
  • Page 15 CONTROLS & FEATURES INSTRUMENTS(noodoe) noodoe MODE Button ADJ Button...
  • Page 16 Battery Voltage and Digital Clock(without system. It needs immediate inspection by noodoe): the authorized KYMCO dealer. It displays the battery voltage or clock. NOTE: Turn on the ignition switch, The CLEP indicator will always illuminate. After starting it will be USB Charging Indicator: off.
  • Page 17 CONTROLS & FEATURES Ser vice Indicator Reset: After you change the engine oil, you need to reset the Service Indicator. 1. Push MODE button, the multifunction display will change ODO→ Trip→ Oil service (blank mode) repeatedly in sequence. 2. Choose Oil service mode press MODE button and ADJ button at the same time for 2 seconds and the display will turn to 0.0,the service indicator is reset.
  • Page 18 CONTROLS & FEATURES Adjust clock(without noodoe) The setting procedure: 1. Turn the ignition switch to the “ ” position. 2. Push the MODE button to toggle between ODO mode, trip mode and oil service and choose ODO mode. NOTE: The digital clock can be only adjusted in ODO mode.
  • Page 19 CONTROLS & FEATURES Service Indicator Reset(Noodoe Dashboard) After you change the engine oil or the drive belt ,you need to reset the Service Indicator. 1.Push MODE button, the multifunction display → Belt tirp will change (ODO→ Trip→ Oil trip repeatedly in sequence. 2.Choose Oil trip mode or Belt trip，press MODE button and ADJ button at the same time for 2 seconds and the display will turns to 0.0,the...

  • Page 20: Usb Power Supply

    CONTROLS & FEATURES Accessor y Socket This vehicle is equipped with the accessory USB power socket which provides a function to charge the mobile phone with capacity compliance as below. ˙To use the accessory USB power supply, turn on the ignition switch, and then start the engine.
  • Page 21 CONTROLS & FEATURES Right handlebar switch Passenger foot pegs Your scooter is equipped with additional pegs Star ter button: for use when you are carrying a passenger. Press starter button " "and pull brake lever in the meantime to actuate the starter 1.To move the passenger pegs from the motor.
  • Page 22 CONTROLS & FEATURES Left handlebar switch Tur n signal switch Push to signal other drivers for an intention to make a turn or change a lane. The turn signal light is blinking while the switch is pushed left or right. PASSING "...

  • Page 23: Fuel Recommendation

    CONTROLS & FEATURES Fuel level inspection / Refilling If the low fuel indicator blinks, quickly refill the fuel tank with the specified unleaded gasoline. To refuel, do the following: 1. Turn the ignition key clockwise to open the fuel tank cap. 2.

  • Page 24: Seat

    CONTROLS & FEATURES Seat To unlock the seat With the ignition key in the " " position (the engine is running), push the key in and turn it counterclockwise from " " to the " " position. With the ignition key in the " "...
  • Page 25 CONTROLS & FEATURES HOOK Helmet Holder If you need to use the front hook, press To use the helmet holders, open the seat and button the hidden hook will come out. hang the helmet on the holder hook , then lock the seat securely.

  • Page 26: Suspension

    CONTROLS & FEATURES Suspension Each shock absorber assembly is equipped with a spring preload adjusting ring. Adjust the spring preload as follows. To increase the spring preload and thereby harden the suspension, turn the adjusting ring on each shock absorber assembly in direction (a).

  • Page 27: Side Stand

    Put the side stand up and start the engine. ● Lower the side stand . The engine should ● stop as doing. NOTE: If the side stand system does not operate as described, see your KYMCO dealer for service.

  • Page 28: Section 3-Operation

    If you brake fluid leakage. detect any problem, be sure to deal with it, or 4. Tires: have the KYMCO dealer to fix it. Check condition and inflation pressure. WARNING 5. Throttle: Improper maintenance of the motorcycle...

  • Page 29: Break-In

    OPERATION Break-in Avoid constant low speed Operate the engine at constant low The first 1600km (1000 miles) of riding is speed even of light load may cause the very important to the life of usage. Proper running part a fit-in problem. Be sure to break-in operation during this period will start up the engine gently during the help ensure maximum life and performance.

  • Page 30: Starting The Engine

    OPERATION Star ting the engine Always follow the proper starting procedure described here and on the following pages. CAUTION To protect the catalytic converter in the engine's exhaust muffler, avoid idling too long and do not use leaded gasoline. CAUTION To prevent damage to the starter motor, do not operate the starter motor for more than 5 seconds at a time.
  • Page 31 OPERATION 3.Squeeze the left (rear) brake lever to connect 4.Press the starter button with the throttle closed, releases it at once as the engine starts. 5.Keep the throttle closed while warming up the engine. 6. Keep the engine warming up thoroughly before each ride.

  • Page 32: Section 4-Maintenance

    KYMCO dealer inspect all major parts, even if you are able to make some repairs. To properly take care of the scooter, the...

  • Page 33: Maintenance Schedule

    Maintenance should be performed according to the design standards and specifications by the authorized KYMCO dealer. Be serviced by the KYMCO dealer, unless you have the proper tools, service data and are technically qualified.

  • Page 34: Engine Oil

    MAINTENANCE FREQUENCY WHICHEVER ODOMETER READING [NOTE (1)] COMES FIRST X 1000 km 11 REFER X 1000 mi PAGE ITEM NOTE MONTH ＊ AIR CLEANER NOTE 2 SPARK PLUGS NOTE 4 ＊ THROTTLE OPERATION ＊ VALVE CLEARANCE ＊ FUEL LINE CRANKCASE BREATHER NOTE 3 ENGINE OIL NOTE 7...
  • Page 35 MAINTENANCE FREQUENCY WHICHEVER ODOMETER READING [NOTE (1)] COMES FIRST X 1000 km REFER X 1000 mi PAGE ITEM NOTE MONTH ＊＊ CLUTCH SHOE WEAR BRAKE FLUID NOTE 6 Replace at every 10000km,or every year BRAKE PAD WEAR BRAKE SYSTEM ＊ BRAKE LIGHT SWITCH ＊＊...
  • Page 36 Exchange capacity: 0.8L(0.76 US QT) Overfilling the engine can cause oil leaks or oil contamination of the air filter element. Always People S 50 make sure the oil level is above the "L" mark but Full capacity: 0.85 L (0.8 US QT) not higher than the "F"...

  • Page 37: Engine Oil Replacement

    MAINTENANCE Engine oil replacement Start engine and keep idling for a few minutes. ● Engine oil quality is the major factor that affects Stop the engine and stand the scooter on level ● engine life. Change your scooter's engine oil ground by center stand.
  • Page 38 4. Fill with the recommended oil to reach the capacity listed below. 5. Install the transmission filler bolt and tighten it to the specified torque. People S 50 Gear oil type: SAE 90 People S 125/200 Full capacity: 0.14L (0.13 US QT) Exchange capacity: 0.12L (0.11 US QT)
  • Page 39 , replace it with a new one NOTE: Have the element serviced more often when riding in unusually wet or dusty areas. NOTE: Air cleaner is an important part of your scooter ,please go to a KYMCO dealer for air cleaner service.

  • Page 40: Throttle Operation

    0.08~0.24in of steering. (2~6mm) 2. Measure the throttle free play as shown at right. Throttle free play: 2.0 - 6.0 mm (0.08-0.24 in) NOTE: If your scooter's throttle free play requires adjustment, contact you KYMCO dealer for service.

  • Page 41: Spark Plug

    After cleaning, check to adjust the spark plug gap to specified limit by using a spark plug gap thickness gauge. The spark plug should be replaced periodically. Recommend to consult with the KYMCO dealer when choosing an alternative spark plug instead. 0.7~0.8 mm People S 125/200 Recommended spark plug：CR8E (NGK)

  • Page 42: Brake Fluid Level Inspection

    MAINTENANCE Brake fluid Brake fluid level inspection With the scooter in an upright position, check the front and rear fluid level. Change the brake fluid at the time specified in the maintenance schedule. The fluid level should be above the lower level .
  • Page 43 MAINTENANCE Limitations Of ABS ABS SYSTEM A B S d o e s n o t a p p l y t h e b r a k e s ABS system is the equipment that automatically. It needs to apply the prevents wheel lockup case of an brakes at the right time and with the right emergency braking, thus is capable to...
  • Page 44 MAINTENANCE Combination Braking System (CBS) Combination Braking System , the rider's action of depressing the rear brake lever applies both front and rear brakes, The amount of each brake applied is determined by CBS pump. Depressing the front brake lever only applies the front brake. CBS Diagraph ①...

  • Page 45: Brake Pad Inspection

    MAINTENANCE Brake Pad Inspection Inspect the thickness of brake pad to verify if there is enough lining to brake properly. If the wear indicated groove at the brake pad is no longer visible, this means that the b r a k e p a d i s w o r n a n d r e q u i r e s replacement.
  • Page 46 MAINTENANCE Brake lever free play inspection Brake pad inspection Inspect the brake pad and shoe thickness to & adjustment verify there is enough material for the brakes to Before riding, inspect the rear brake lever function properly. If the " Δ" mark on the rear free play and adjust it to the specified brake indicator aligns with the "Δ"...

  • Page 47: Battery

    . ● Remove the plastic clip ● Remove the front cover. ● NOTE: If your battery seems weak or the electrolyte is leaking to cause hard start or other electrical troubles, contact the KYMCO dealer immediately.
  • Page 48 MAINTENANCE Batter y Remove WARNING Disconnect the negative (-) terminal ● Disconnect the positive (+) terminal ● Electrolyte is toxic and dangerous since it Remove the disabled battery. contains sulfuric acid, which causes ● To reinstall is the reverse sequence of ●...

  • Page 49: Fuse

    Fuse should be inserted according to this sticker. WARNING Never use a fuse of different rating. Fuse Specifications(ABS) ● If the new fuse blows in a short time, ● 10A*1 15A*1 25A*1 consult the KYMCO dealer immediately. Fuse Specifications(without ABS) 10A*1 15A*1...

  • Page 50: Tires

    MAINTENANCE Tires WARNING Tire pressure Insufficient tire pressure not only advances wear Fail to follow the instruction below may result but also affects the riding stability. Under- in an accident due to tire failure. The rider's inflated tires make turning not smooth and over- personal safety is dependent on the condition inflated tires decrease the contact area with the ground, which can lead to skid and loss of...

  • Page 51: Tires Inspection

    , do not judge control of your scooter or shorten tire life. by a visual inspection. Ask the authorized KYMCO dealer, or a qualified tire shop to perform tire repair, replacement, and balancing due to the proper tools and experience are required.
  • Page 52 MAINTENANCE Cleaning Washing your scooter 1.Rinse the scooter thoroughly with cool Clean your scooter regularly to protect water to remove any loose dirt. the surface finishes and inspect 2.Clean the scooter with a sponge or soft damage, wear, and oil, coolant or brake cloth using cool water.

  • Page 53: Crankcase Blow-By Drain

    MAINTENANCE Crankcase Blow-by Drain(125/200 Model) The air cleaner has a drain tube that is for draining the oil condensed fluid from the crankcase. When the fluid has accumulated to a certain amount in the transparent drain , drain the fluid tube, remove the clip into a container, and then reinstall in place.
  • Page 54 MAINTENANCE Crankcase Blow-by Drain(50 Model) The air cleaner has a drain tube that is for draining the oil condensed fluid from the crankcase. When the fluid has accumulated to a certain amount in the transparent drain , drain the fluid tube, remove the clip into a container, and then reinstall in place.

  • Page 55: Storage

    MAINTENANCE Removal from Storage Storage Remove cover from the vehicle ● Check the battery voltage or charge it if Take necessary steps to be in good condition ● for next use after long storage. necessary, and then install it in the vehicle. Fill the fuel tank with fuel.

  • Page 56: Emission Control

    EMISSION CONTROL Crankcase Emission Control System The scooter is equipped with a closed crankcase system. Blow-by gas is recycled into the combustion chamber via the intake system. This arrangement is to prevent blow-by gas from spreading to the atmosphere. Exhaust Emission Control System The exhaust emission from the scooter is controlled by combustion management, fuel delivery, ignition setting and exhaust system.

  • Page 57: Maintenance Record

    MAINTENANCE RECORD DATE MILEAGE SERVICE PERFORMED&NOTES...
  • Page 58 MAINTENANCE RECORD DATE MILEAGE SERVICE PERFORMED&NOTES...
  • Page 59 People S 50 SPECIFICATIONS Dimensions Chassis Overall length ......2070 mm Tire size, front......100/80–16 Overall width......... 700 mm Tire size, rear......120/80–14 Overall height ....1150 mm/1570mm Brake (front) ........DISK Wheel base......... 1425 mm Brake (rear) ........DRUM Seat height ........800 mm Electrical Dry weight........
