Installation Manual
Shield antenna
ID ANTRW.8060-A
ID ANTRW.5040-A
(for ID RW24.ABC-A)
Delivery contents:
1 x ID ANTRW.8060-A or ID ANTRW.5040-A
4 x capping plugs 10mm
1 x Installation manual
M00102-0e-ID.doc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ID ANTRW.8060-A and is the answer not in the manual?

Questions and answers

Summary of Contents for Feig Electronic ID ANTRW.8060-A

  • Page 1 Installation Manual Shield antenna ID ANTRW.8060-A ID ANTRW.5040-A (for ID RW24.ABC-A) Delivery contents: 1 x ID ANTRW.8060-A or ID ANTRW.5040-A 4 x capping plugs 10mm 1 x Installation manual M00102-0e-ID.doc...
  • Page 2 With the long-range reader ID RW24.ABC-A, a shield antenna of the dimensions 800mm X 600mm or 500mm X 400mm may be ordered. These items are available at FEIG ELECTRONIC GmbH. 1.2 Connection of a shield antenna Picture 1.2-1 shows the structure of a shield antenna in principle.
  • Page 3 Installation Manual Shield antenna 1.4 Ranges Dependent on the environmental conditions, the following reader ranges can be obtained, if the orientation of the transponder to the antenna is parallel and central. ID ANTRW.8060-A transponder type range ID DTK.A 660 mm ID CTK.B...
  • Page 4 = protective system IP54 = inductivity 1120 µH ± 40µH = resistance 13,0 Ohm ± 0,5 Ohm = length of the supply line approx. 1 m Picture 2-1 Drilling scheme of the ID ANTRW.8060-A FEIG ELECTRONIC GmbH M00102-0e-ID.doc page 4 of 8...
  • Page 5 Identifikationssystem OBID ® Installation Manual Shield antenna Picture 2-2 Drilling FEIG ELECTRONIC GmbH M00102-0e-ID.doc page 5 of 8...
  • Page 6 = inductivity 910 µH ± 40 µH = resistance 9,4 Ohm ± 0,5 Ohm = length of supply line approx. 1m Picture 2.1-1 Drilling scheme of the ID ANTRW.5040-A Picture 2.1-2 Drilling FEIG ELECTRONIC GmbH M00102-0e-ID.doc page 6 of 8...
  • Page 7 The user is responsible for the installation, application and connecting of the appliance according to the technical standards of the installation country and other valid prescriptions. Dimensions of wires and cables, safety regulations, earthing, separation, insulation control and overcurrent protection have to be considered in particular. FEIG ELECTRONIC GmbH M00102-0e-ID.doc page 7 of 8...
  • Page 8 The information in this manual have been compiled to the best of knowledge and belief. FEIG ELECTRONIC GmbH does not guarantee the correctness of informations in this manual. Especially, FEIG ELECTRONIC GmbH is not legally responsible for damages caused by incorrect information of this manual.
