Contents Overview of your Extraction system (front) Overview of your Extraction system (back) Overview of the Control Panel Overview of the 3D Printing Setup Important safety notes Safety labels Unpacking and unit placement Connecting to power supply Turning extractor On Cleaning the unit Filter replacement Consumable Spares &...
Page 4
Overview Main Isolation Switch Mains Inlet Fuse Compartment Air Outlet* Air Outlet (When rear outlet closed) The air outlet can be configured to suit the user’s needs. The rear port can be blanked using the plate screwed to the underside of the unit. The air can then exit through the exposed grille under the unit. Please note that when the rear outlet is being used, the grille located on the bottom of the unit must be blanked off as shown above.
Page 6
Overview Air Inlet Plenum 3D Printer 3D PrintPRO 3 Extraction Unit Air Outlet Plenum...
Page 7
Important Safety Instructions To reduce the risk of fire, electric shock or injury: Always isolate the system from the mains power supply before removing the pump/motor access panel. 2. Use only as described in this manual. Connect the system to a properly grounded outlet. Important safety notes Concerning symbols used on the extraction unit and referred Dangers to eyes, breathing and skin...
Page 8
Serial Number Label Safety Instructions Location: Next to mains inlet. Meaning: This label contains a variety of information about the extraction unit, including. Warning and Information labels The following listing details labels used on your 3D Print Pro • Company name, Address & Contact number 3 extraction unit.
Page 9
Before Installation Packaging Removal & Unit Placement Before installation, check the extraction unit for damage. All packaging must be removed before the unit is connected to the power supply. Please read all instructions in this manual before using this extractor. 1.
Page 10
Pairing with the 3D printer System Installation The 3D PrintPRO 3 has been specially designed to be used alongside a wide spectrum of middle range 3D printers available on the market. Fume can be captured in a number of ways including nozzles and funnels and BOFA’s new 3D plenum range.
Page 11
Operation To set the airflow Press the Up arrow button to increase airflow and press the down arrow button to decrease airflow. The level of airflow is indicated by the vertical row of six blue LEDs to the right of the mains isolation switch. As the airflow increases, more blue LEDs light up and the opposite for decreasing the airflow.
Page 12
no longer removes fume efficiently. Maintenance It is recommended that a spare set of filters are kept on site to avoid prolonged unit unavailability. Part numbers for replacement filters can be found on the filters fitted in your system. To prevent overheating, units should not be run with a blocked filter condition, or with dust obstruction of Inlets / Maintenance UK Outlets.
Page 13
Maintenance To remove and replace the combined filter follow the procedure detailed below. Isolate the electrical supply to the extractor 2. Undo the clips on the sides of the unit and remove the lid. Filter Replacement Lift the filter out of the unit. Once removed it is recommend that the used filters are bagged and The 3D Print Pro 3 will alert the user when its filters need to sealed.
Page 14
Replacement Parts Filter disposal The combined filter is manufactured from non-toxic materials. Filters are not re-usable, cleaning used filters is not recommended. The method of disposal of the used filters depends on the material deposited on them. Consumable Spares For your guidance The 3D Print Pro 3 contains a pre filter pad and a combined Deposit Comment...
