Level Signal; Launch Signal; Interface Signal - Endress+Hauser Levelflex FMP51 Operating Instructions Manual

Operating menu

Level signal

Navigation
Prerequisite
Description
User interface
Additional information

Launch signal

Navigation
Prerequisite
Description
User interface
Additional information

Interface signal

Navigation
Prerequisite
Description
User interface
216
 Diagnostics → Device check → Level signal
Device check has been performed.
Displays result of the device check for the level signal.
• Check not done
• Check not OK
• Check OK
For Level signal = Check not OK: Check the mounting position of the device and the
dielectric constant of the medium.
 Diagnostics → Device check → Launch signal
Device check has been performed.
Displays result of the display check for the launch signal.
• Check not done
• Check not OK
• Check OK
For Launch signal = Check not OK: Check the mounting position of the device. In non-
metallic vessels use a metal plate or a metal flange.
 Diagnostics → Device check → Interface signal
• Operating mode (→  131) = Interface or Interface with capacitance
• Device check has been performed.
Displays result of the device check for the interface signal.
• Check not done
• Check not OK
• Check OK
Levelflex FMP51, FMP52, FMP54 PROFIBUS PA
Endress+Hauser
